Introduction
This manual provides essential information for the safe and efficient operation, installation, and maintenance of your Havells Adonia Spin 10 Litre Storage Water Heater. Please read these instructions carefully before using the appliance and retain them for future reference.
The Havells Adonia Spin 10 Litre Storage Water Heater is designed to provide efficient hot water for your household needs. It features a temperature sensing LED knob, a Feroglas coated anti-rust tank, and is compatible with high-rise buildings due to its high-pressure rating.
Product Features
- Capacity: 10 Litres, suitable for small to medium households.
- Wattage: 2000 Watts for efficient heating.
- Pressure Rating: 8 Bars, ideal for high-rise buildings.
- Energy Efficiency: 5-Star BEE rating for energy savings.
- Waterproof Degree: IPX-4 protection for enhanced product life.
- Temperature Sensing LED Knob: Changes color to indicate real-time water hotness.
- Feroglas Technology: Ultra-thick superior steel tank with single weld design for superior corrosion resistance and anti-rust properties.
- Heating Element: Incoloy glass-coated heating element for high performance and resistance to oxidation, carbonization, and corrosion in hard water conditions.
- Anode Rod: Stainless steel core anode rod protects the tank from corrosive elements, prolonging the water heater's life.
- Shock Safe Plug: Integrated plug designed to prevent electric shocks by cutting off power immediately in case of current leakage.
- PUF Insulation: BEE, CFC-free thicker PUF insulation minimizes radiant heat loss, reducing energy consumption.
- Whirlflow Technology: Prevents direct contact between cold and hot water flow for faster heating and optimized energy saving, resulting in 20% more hot water output.
Image: Havells Adonia Spin Water Heater highlighting features like faster heating, safer operations, and electricity savings, indicating it's engineered for hard water.
Image: Close-up of the Havells Adonia Spin Water Heater emphasizing its Incoloy Heating Element for high performance and quick heating.
Image: Diagram illustrating the safety features of the Havells Adonia Spin Water Heater, including fire retardant power cord, high working pressure, high precision thermostat and cutout, dual safety adapter, and IPX4 protection.
Image: Visual representation of the Feroglas coated inner container and the heavy-duty protective anode rod, highlighting their role in corrosion resistance and product longevity.
What's in the Box
Upon unpacking, please ensure all the following components are present and undamaged:
- 1 N Havells Adonia Spin Water Heater Unit
- 1 N Power Cord with 3-pin plug
- 1 N User Manual (this document)
- 1 N Wall Mounting Accessory Kit (screws, hooks, mounting bracket reference sticker)
- 1 N Shock Safe Plug
- 2 N Flexi Pipes for water connections
Video: An overview of the Havells Adonia Spin 10 Litre Water Heater, showcasing its design, features, and the contents typically included in the package. This video is provided by the seller.
Setup and Installation
Warning: Installation should only be performed by a qualified plumber or electrician to ensure safety and proper functioning. Incorrect installation can lead to electric shock, water leakage, or damage to the appliance.
- Site Selection: Choose a suitable location for the water heater. Ensure there is sufficient space around the unit for maintenance and servicing (e.g., 50 cm from sides, 1.8 m from the ground). The wall must be strong enough to support the weight of the water heater when full.
- Mounting:
- Use the provided mounting bracket reference sticker to mark the drilling points on the wall. Ensure the sticker is perfectly leveled vertically before marking.
- Drill two holes using a 10 mm concrete drill bit to a depth of 70 mm to 75 mm.
- Insert the wall mounting accessories (hooks/screws) into the drilled holes and secure them firmly.
- Carefully hang the water heater unit onto the secured wall mounts.
- Water Connections:
- Connect the cold water inlet (usually marked blue) to your cold water supply using one of the provided flexi pipes.
- Connect the hot water outlet (usually marked red) to your hot water tap using the other flexi pipe.
- Ensure all connections are tight and leak-free.
- Filling the Tank: Before connecting to power, open a hot water tap in your bathroom to allow air to escape and the tank to fill with water. Once water flows steadily from the hot water tap, close the tap.
- Electrical Connection:
- Plug the water heater's power cord into a suitable electrical outlet.
- Ensure the Shock Safe Plug is properly connected and functioning. Test the Shock Safe Plug as per its instructions before initial use.
Operating Instructions
- Power On: Ensure the water heater is properly installed and filled with water. Switch on the main power supply to the appliance.
- Set Temperature: Use the temperature sensing LED knob on the front panel to set your desired water temperature. Rotate the knob to adjust. The LED ring will change color to indicate the current water temperature:
- Blue: Cold/Warm water
- Green: Moderately warm water
- Red: Hot water
- Heating Process: The water heater will begin heating the water to the set temperature. The LED indicator will reflect the heating status.
- Hot Water Usage: Once the desired temperature is reached, the water heater will maintain it. You can now draw hot water from your taps.
- Power Off: When hot water is no longer needed, switch off the power supply to the water heater.
Maintenance
Caution: Always disconnect the power supply before performing any maintenance or cleaning.
- Anode Rod Inspection/Replacement: The anode rod protects the tank from corrosion. It is recommended to inspect and replace the anode rod annually, especially in areas with hard water, to ensure the longevity of the water heater. This procedure should be performed by a qualified technician.
- Draining the Tank: If the water heater will not be used for an extended period or if there is a risk of freezing, drain the tank completely. Refer to the detailed instructions in the full user manual for the draining procedure.
- Cleaning: Clean the exterior of the water heater with a soft, damp cloth. Do not use abrasive cleaners or solvents.
- Safety Valve: Periodically check the pressure relief valve (safety valve) to ensure it is not blocked and is functioning correctly.
Troubleshooting
This section provides basic troubleshooting steps for common issues. For more complex problems, please contact customer support or a qualified technician.
| Problem | Possible Cause | Solution |
|---|---|---|
| No hot water / Water not heating |
|
|
| Water is not hot enough |
|
|
| Water leakage |
|
|
Specifications
| Feature | Detail |
|---|---|
| Brand | Havells |
| Model | Adonia Spin 2024 |
| Type | Storage Water Heater (Geyser) |
| Capacity | 10 Litres |
| Wattage | 2000 Watts |
| Pressure Rating | 8 Bars |
| BEE Rating | 5 Star |
| Waterproof Degree | IPX-4 |
| Inner Container Material | Feroglas Coated Ultra-thick Steel |
| Heating Element | Incoloy Glass Coated |
| Color | White Blue |
| Product Dimensions (L x W x H) | 39.1 cm x 29.9 cm x 39.1 cm |
Image: A table showing the length, width, and height dimensions for different capacities (10L, 15L, 25L) of the Havells Adonia Spin Water Heater. For the 10L model, dimensions are 391mm (L) x 299mm (W) x 391mm (H).
Image: The BEE (Bureau of Energy Efficiency) Power Savings Guide label for the Havells Adonia Spin 10 Litre Water Heater, indicating its 5-star rating and standing loss of 0.332 kWh/24hr.
Warranty and Support
Your Havells Adonia Spin Water Heater comes with a comprehensive warranty to ensure peace of mind:
- Inner Container: 7 Years Warranty
- Heating Element: 4 Years Warranty
- Comprehensive Warranty: 2 Years on the entire product
For any installation assistance, service requests, or warranty claims, please contact Havells customer support or the retailer from whom you purchased the product. For products purchased via Amazon, installation coordination can be arranged within 48 hours of delivery in select cities.
Image: Visual representation of the warranty details for the Havells Adonia Spin Water Heater, showing 4 years on heating element, 7 years product replacement warranty on inner container, and 2 years comprehensive warranty.
