LIGE Smartwatch Bw1290c User Manual

1. Product Overview

The LIGE Smartwatch Bw1290c is a versatile wearable device designed to integrate with your daily life, offering communication, health monitoring, and fitness tracking features. It is compatible with both Android and iOS smartphones.

Image: LIGE Smartwatch Bw1290c, showcasing its main display and design.

2. What's in the Box

• 1 x LIGE Silicone double band Watch
• 1 x LIGE Smart watch instructions (this manual)
• 1 x Fashion Packing (packaging box)
• 1 x High Quality Microfiber Cleaning Cloth
• 1 x Charger Cable

3. Setup Guide

3.1 Initial Charging

Before first use, fully charge your smartwatch. Connect the provided charger cable to the charging contacts on the back of the watch and to a USB power source. A full charge typically takes approximately 2 hours.

3.2 App Installation and Pairing

1. Power On: Long press the side button of the watch for 3-5 seconds to turn it on.
2. Download App: On the watch's settings page, locate and scan the QR code displayed to download the 'Da Fit' APP. Alternatively, search for 'Da Fit' in your smartphone's app store (Google Play Store for Android, Apple App Store for iOS).
3. Enable Bluetooth & Location: Ensure your smartphone's Bluetooth and location services are turned on. Verify that the smartwatch is not currently paired with any other device.
4. Open Da Fit APP: Launch the 'Da Fit' APP on your smartphone. Complete the personal information setup within the app.
5. Bind Device: Navigate to the "Device" interface within the app and select "Bind device".
6. Identify Watch: On the smartwatch's main dial interface, swipe right to view the Bluetooth MAC address. Use this MAC address to identify your specific device in the app's search results.
7. Pair: Select the correct device name and MAC address from the list in the app and click "Pair". The smartwatch will then connect successfully.

3.3 Compatibility

The LIGE Smartwatch Bw1290c is compatible with devices running iOS 8.0 and above, and Android 4.0 and above.

4. Operating Instructions

4.1 Bluetooth Calling

The smartwatch supports Bluetooth calling, allowing you to make and receive calls directly from your wrist. It also enables music playback control from your smartphone.

Image: Demonstrates answering a call directly from the smartwatch.

4.2 Message Notifications

Receive and view SMS messages and notifications from various social media applications such as WhatsApp, Twitter, Facebook, and Instagram directly on your smartwatch. This ensures you stay informed without needing to check your phone constantly.

Image: Smartwatch displaying a message notification.

4.3 Custom Watch Faces

The 1.32-inch full-touch screen offers a resolution of 360x360 pixels. You can personalize your smartwatch by choosing from over 100 watch faces available in the "Da Fit" app or by setting your favorite images as a custom dial.

Image: Customizing the smartwatch dial with a personal photo.

4.4 Health Monitoring

The smartwatch features built-in motion sensors and a high-performance monitor to track various health metrics in real-time. Data is automatically synced to the "Da Fit" app for review.

• Heart Rate Monitoring: Continuously tracks your heart rate.
• Blood Pressure Monitoring: Provides blood pressure readings.
• Blood Oxygen Saturation (SpO2) Monitoring: Measures blood oxygen levels.
• Sleep Monitoring: Records different stages of sleep (deep sleep, light sleep, awake sleep) to help you understand and improve your sleep habits.

Important Note: The measurement data from the smartwatch for blood pressure, heart rate, and blood oxygen are for reference only and should not be used as medical data or for diagnostic purposes.

Image: 24-hour health monitoring features.

Image: Sleep monitoring display on the smartwatch.

4.5 Sports Modes

The smartwatch offers 10 sports modes to track your physical activity. These modes help record data such as steps, distance, calories burned, and heart rate during exercise.

• Walking
• Running
• Cycling
• Badminton
• Basketball
• Football
• Skiing
• Free Training
• And more...

Image: Multiple sports modes tracking activity data.

4.6 Additional Functions

• Remote Camera Control: Use your watch to remotely trigger your smartphone's camera.
• Music Control: Play, pause, skip tracks, and adjust volume for music playing on your smartphone.
• Weather Forecast: Get real-time weather updates directly on your watch.
• Breath Training: Guided breathing exercises for relaxation.
• Alarm Clock: Set alarms for reminders.
• Stopwatch & Timer: Basic timekeeping functions.
• Sedentary Reminder: Alerts you to move if you've been inactive for too long.

5. Maintenance

5.1 Battery Life

The built-in battery provides approximately 7 days of typical use and up to 20 days in standby mode. Actual battery life may vary based on usage patterns and settings.

5.2 Water Resistance (IP67)

The smartwatch is rated IP67 waterproof, meaning it is resistant to dust and can withstand immersion in water up to 1 meter for 30 minutes. It is suitable for daily use, such as hand washing or light rain.

Caution: Do not use the watch in hot water, such as during a hot bath or sauna. High temperatures and steam can penetrate the watch's seals, potentially causing internal damage and short circuits, which are not covered under warranty.

5.3 Cleaning

Use the provided microfiber cleaning cloth to gently wipe the screen and watch body. Avoid using harsh chemicals or abrasive materials that could damage the device.

6. Troubleshooting

6.1 Connection Issues

• Watch not pairing with app: Ensure Bluetooth and location services are enabled on your phone. Restart both the watch and your phone. Check if the watch is already paired with another device. Follow the pairing steps in Section 3.2 carefully.
• Charging difficulties: Ensure the charging cable is securely connected to both the watch's charging contacts and the USB power source. Clean the charging contacts on the watch and cable if necessary.

6.2 Health Data Discrepancies

• Blood pressure readings differ from sphygmomanometer: The smartwatch measures blood pressure from the arterioles, while a sphygmomanometer measures from the brachial artery. Due to this difference, there may be variations in readings. Smartwatch data is for reference only and not for medical diagnosis.
• Inaccurate heart rate/step count: Ensure the watch is worn snugly on your wrist, not too loose or too tight. Movement during activities can affect sensor accuracy. For best results, ensure the sensor area on the back of the watch is clean and in direct contact with your skin.

6.3 General Performance

• Watch unresponsive: Try restarting the watch by long-pressing the side button. If unresponsive, allow the battery to fully drain and then recharge it.
• Notifications not appearing: Check app permissions on your smartphone to ensure the 'Da Fit' app has access to notifications. Verify that notifications are enabled within the 'Da Fit' app settings for the desired applications.

7. Specifications

8. Warranty and Support

Your LIGE Smartwatch Bw1290c comes with a 12-month warranty from the date of purchase.

If you encounter any quality problems with your smartwatch, please contact LIGE customer support through the Amazon platform. We offer replacement, return, and quality maintenance services as per our warranty policy.
