Maxcio Mini Digital Programmable Timer Plug ETF-68A User Manual

1. Introduction

Thank you for choosing the Maxcio Mini Digital Programmable Timer Plug, Model ETF-68A. This device is designed to automate the power supply to your electronic appliances, helping you save energy and simplify daily tasks. Please read this manual carefully before use to ensure proper operation and to maximize the benefits of your timer plug.

Image 1: Maxcio Mini Digital Programmable Timer Plug highlighting its features.

Key Features:

• Up to 16 ON/OFF programs per day.
• Two countdown ON/OFF programs with second-level precision.
• 24-hour/7-day programmable cycles.
• Anti-theft random function.
• Automatic Daylight Saving Time (DST) adjustment.
• Integrated Ni-MH battery for programming without being plugged in.

2. Safety Information

• Do not exceed the maximum load of 3680W (16A at 230V).
• This device is for indoor use only.
• Do not immerse in water or expose to excessive moisture.
• Keep out of reach of children.
• Do not disassemble or attempt to repair the device.
• Ensure the appliance connected to the timer plug is suitable for automatic operation.

3. Product Overview

Familiarize yourself with the components of your Maxcio Digital Programmable Timer Plug.

Image 2: Close-up view of the timer plug's digital display and control buttons.

Controls and Display:

• CLOCK Button: Used to set the current time and day.
• TIMER Button: Used to set ON/OFF programs.
• ON/AUTO/OFF Button: Cycles through manual ON, automatic, and manual OFF modes.
• WEEK Button: Selects the day(s) of the week for programming.
• HOUR Button: Adjusts the hour.
• MINUTE Button: Adjusts the minute.
• RCL/RANDOM Button: Recalls programs or activates the random function.
• RESET Button: Clears all settings and resets the device.
• DST Button: Activates/deactivates Daylight Saving Time.
• Digital Display: Shows current time, day, and program status.

4. Setup

4.1 Initial Charging

The timer plug contains an integrated Ni-MH battery. Before first use, or if the display is blank, plug the timer into a live wall socket for at least 30 minutes to charge the internal battery. This allows you to program the device even when it's not connected to an appliance or a live socket, and retains settings for up to 2 months during power outages or when unplugged.

4.2 Resetting the Device

To clear all previous settings and start fresh, insert a small, non-metallic pointed object (like a pen tip) into the RESET hole and press firmly. The display will show '0:00' and all settings will be erased.

4.3 Setting Current Time and Day

1. Press and hold the CLOCK button.
2. While holding CLOCK, press the WEEK button repeatedly to set the current day of the week (MO, TU, WE, TH, FR, SA, SU).
3. While holding CLOCK, press the HOUR button repeatedly to set the current hour (12 or 24-hour format).
4. While holding CLOCK, press the MINUTE button repeatedly to set the current minute.
5. Release the CLOCK button. The time is now set.

4.4 Daylight Saving Time (DST) Adjustment

To activate or deactivate Daylight Saving Time:

Image 3: Visual representation of Standard Time versus Daylight Saving Time.

1. Press the DST button once. The display will show 'SUMMER' and the time will advance by one hour.
2. Press the DST button again to revert to standard time. The display will show 'WINTER' and the time will go back by one hour.

5. Operating Modes

5.1 Manual ON/AUTO/OFF Mode

Press the ON/AUTO/OFF button to cycle through the operating modes:

• ON: The connected appliance is continuously ON.
• OFF: The connected appliance is continuously OFF.
• AUTO: The connected appliance operates according to the programmed ON/OFF cycles.

5.2 Programming ON/OFF Cycles (Up to 16 Programs)

You can set up to 16 different ON/OFF programs for various days or combinations of days.

Image 4: Example of setting an ON/OFF program for a light fixture.

1. Press the TIMER button once. The display will show '1 ON'. This is your first ON program.
2. Press the WEEK button to select the desired day(s) for this program (e.g., MO, TU, WE, TH, FR, SA, SU, MO-FR, SA-SU, MO-SA, etc.).
3. Press the HOUR button to set the desired ON hour.
4. Press the MINUTE button to set the desired ON minute.
5. Press the TIMER button again. The display will show '1 OFF'. This is your first OFF program.
6. Repeat steps 2-4 to set the desired OFF day(s), hour, and minute for this program.
7. Continue pressing the TIMER button to cycle through and set up to 16 ON/OFF programs (2 ON/OFF settings per program number).
8. After setting all desired programs, press the CLOCK button to return to the current time display. Ensure the timer is in AUTO mode for programs to execute.

5.3 Countdown Function

The timer plug offers two countdown programs, allowing precise timing down to the second. Note that the countdown function operates once and does not automatically repeat.

Image 5: Icons illustrating various timer modes and time format conversions.

1. Press the TIMER button until 'CD 1 ON' or 'CD 1 OFF' appears.
2. Use the HOUR, MINUTE, and SECOND buttons to set the desired countdown duration (1-99 hours, 1-59 minutes, 1-59 seconds).
3. Press the ON/AUTO/OFF button to select whether the appliance should turn ON or OFF at the end of the countdown.
4. Press the TIMER button to start the countdown. The display will show the remaining time.
5. To stop the countdown, press the TIMER button again.

5.4 Random Function (Anti-theft)

The random function can be used to deter intruders by making it appear as if someone is home. When activated, the timer will randomly turn the connected appliance ON and OFF within a specific time window (e.g., 6 PM to 6 AM).

1. Ensure the timer is in AUTO mode.
2. Press the RCL/RANDOM button once. 'RANDOM' will appear on the display.
3. The appliance will now turn ON and OFF randomly during the evening and night hours.
4. To deactivate, press the RCL/RANDOM button again. 'RANDOM' will disappear.

6. Maintenance

To ensure the longevity and proper functioning of your Maxcio timer plug, follow these simple maintenance guidelines:

• Clean the device with a dry, soft cloth. Do not use liquid cleaners or abrasive materials.
• Store the timer plug in a cool, dry place when not in use.
• Avoid exposing the device to extreme temperatures or direct sunlight.

7. Troubleshooting

If you encounter issues with your timer plug, refer to the following common problems and solutions:

• Display is blank: The internal battery may be depleted. Plug the timer into a live wall socket for at least 30 minutes to charge it.
• Programs are not executing:
  • Ensure the timer is in AUTO mode. Press the ON/AUTO/OFF button until 'AUTO' is displayed.
  • Verify that the current time and day are set correctly.
  • Check that your ON/OFF programs are correctly entered and enabled for the desired days.
• Difficulty with programming: The display can be small. Ensure you are in a well-lit area and have clear vision. If issues persist, perform a RESET and re-enter all settings carefully.
• Countdown function does not repeat: The countdown function is designed for single-use operation and does not automatically renew. For recurring schedules, use the standard ON/OFF programs.
• Device stays ON in AUTO mode: This indicates a programming error or the device is not correctly set to AUTO. Perform a RESET and re-program, ensuring the device is in AUTO mode after programming.

8. Specifications

Technical details for the Maxcio Mini Digital Programmable Timer Plug ETF-68A:

Image 6: Overview of the product's technical specifications.

9. Warranty and Support

Maxcio products are designed for reliability and performance. For warranty information or technical support, please refer to the contact details provided with your purchase or visit the official Maxcio website. If you have questions or require assistance, do not hesitate to contact the seller.
