VOLIBeL A32B Bluetooth Smart Door Lock User Manual

1. Introduction

This manual provides detailed instructions for the installation, operation, and maintenance of your VOLIBeL A32B Bluetooth Smart Door Lock. Please read this manual thoroughly before installation and use to ensure proper function and safety. This smart lock offers multiple access methods for enhanced security and convenience.

2. Safety Information

• The VOLIBeL A32B lock is designed for interior doors only. It is not suitable for outdoor use and is not waterproof. Exposure to outdoor elements or water can damage the device and void the warranty.
• Ensure all components are handled carefully during installation to prevent damage.
• Use only the specified AA batteries (4x, not included). Do not mix old and new batteries or different types of batteries.
• Keep mechanical keys in a safe, accessible location outside the secured area.

3. Package Contents

Verify that all items listed below are present in your package:

• 1x VOLIBeL A32B Smart Door Lock (complete set)
• 2x Mechanical Keys
• 2x RFID Key Fobs (Tags)
• 1x User Manual (this document)

Note: 4x AA batteries are not included and must be purchased separately.

4. Setup and Installation

The VOLIBeL A32B smart lock is designed for easy installation on standard single latch doors. Detailed installation instructions are provided in the included manual. Please follow them carefully.

4.1 Door Compatibility

• Door Thickness: 1.38 inches to 2.17 inches (35 mm - 55 mm)
• Adjustable Backset: 2-3/8 inches or 2-3/4 inches
• The lock fits standard door holes, eliminating the need for extra drilling.

Figure 4.1: Door dimensions and measurements for proper installation of the VOLIBeL A32B smart lock.

4.2 Handle Reversibility

The lever handle is reversible, making it suitable for both left-handed and right-handed doors. Adjust the handle direction during installation as required for your door.

Figure 4.2: Illustration of the reversible handle mechanism, allowing adaptation for left or right-handed door configurations.

4.3 Battery Installation

The lock requires 4x AA batteries (not included). Install them into the battery compartment located on the interior side of the lock. Ensure correct polarity.

Figure 4.3: View of the battery compartment, indicating where to insert the 4x AA batteries.

4.4 RFID Key Fob Programming

The included RFID key fobs must be programmed to the lock by the user. Refer to the programming manual for specific steps on how to add and manage RFID cards.

5. Operating Instructions

The VOLIBeL A32B smart lock offers 5-in-1 unlocking methods for flexible access control.

5.1 Unlocking Methods

• App Control: Use the "TinyLock" application on your smartphone to unlock the door remotely via Bluetooth.
• Fingerprint: Register your fingerprints for quick and secure access. The fingerprint sensor is located on the exterior unit.
• RFID Card/Tag: Present a programmed RFID key fob to the sensor on the exterior unit to unlock.
• Codes: Enter a valid numerical code on the backlight digital touchscreen keypad.
• Mechanical Key: In case of emergency or battery depletion, use the physical mechanical key to unlock the door via the hidden keyhole.

Figure 5.1: The exterior unit of the smart lock with its digital touchscreen keypad and fingerprint sensor.

5.2 User Management

The lock supports one administrator and up to 100 guest users for each unlocking method (Fingerprint, RFID Card, Code). Refer to the programming manual for instructions on adding and deleting users.

5.3 Code Protection

• Garbled Code Input: You can enter random digits before or after your true code to prevent others from guessing your code. For example, if your code is 123456, you can enter 987123456098.
• Temporary Lockout: The keypad will temporarily lock for 1 minute after 10 consecutive incorrect code inputs to prevent unauthorized access attempts.

6. Maintenance

• Cleaning: Wipe the lock's surface with a soft, dry cloth. Avoid using abrasive cleaners or solvents, which can damage the finish or electronic components.
• Battery Replacement: The lock will provide a low battery alarm when power is running low. Replace all four AA batteries promptly to ensure continuous operation. Batteries can last approximately 10 to 15 months under normal use.
• Regular Checks: Periodically check that all screws are tight and the lock operates smoothly.

7. Troubleshooting

• Lock Not Responding: Check battery levels. If the batteries are depleted, use the mechanical key for access and replace the batteries immediately.
• Keypad Locked: If the keypad is unresponsive, it may be in a temporary lockout state due to multiple incorrect code entries. Wait for 1 minute for it to reset.
• Fingerprint/RFID Not Recognized: Ensure your finger is clean and dry, or the RFID card is correctly presented. Re-register if issues persist.
• App Connectivity Issues: Ensure Bluetooth is enabled on your phone and you are within range of the lock. Restart the app or your phone if necessary.
• Installation Problems: If you encounter difficulties during installation, refer to the detailed installation instructions provided in the package or contact customer support.

8. Specifications

9. Support

For any questions regarding installation, programming, or operation of your VOLIBeL A32B Smart Door Lock, please refer to the detailed programming manual included in your package. If you require further assistance, do not hesitate to contact VOLIBeL customer support.
