Introduction
This user manual provides essential information for the safe and effective operation of your Phlizon PL2000 LED Grow Light. Please read these instructions thoroughly before installation and use to ensure optimal performance and longevity of the product.
Safety Instructions
Adherence to the following safety guidelines is crucial for preventing injury and damage to the product:
- Children aged 8 and under are not allowed to use this product.
- Individuals with decreased physical, sensory, or mental abilities or lack of experience or knowledge should not use this product under supervision and understanding of the danger.
- Place the equipment and its wires out of reach of children under 8 years old.
- When the device is connected to a power source, do not leave it unattended.
- If the power cord is damaged, the equipment should be scrapped or replaced by the manufacturer, their service agent, or similar qualified personnel to avoid danger.
- The light belongs to class I protection equipment, so the light must be well grounded.
- The power supply should be connected by professionals.
- Before use, make sure that the voltage used is not higher or lower than the specified value in the operation manual.
- For daisy chain operation, the total power cannot exceed the rated power of your timer.
- Do not touch while in operation.
- Do not look directly into lights without protective glasses.
- Only the plug is allowed to connect the power cord. Please do not pull the power cord with brute force to pull out the plug.
- Use electricity safely and operate carefully during the installation of light. Avoid touching exposed wires, or you may suffer a fatal electric shock.
- Unplug power cord on rainy days to help prevent lightning strikes. Please unplug the light when cleaning and repairing.
- Do not disassemble, repair or refit the light without the authorization of the manufacturer or non-professionals. The maximum operating temperature is 40 C. Do not operate the light above this temperature.
- Do not connect the light to other dimming devices without permission.
- Waterproof IP rate attention: The waterproof rate of the light power driver is IP67, and the waterproof rate of the power cord interface of the lamp is IP20. Therefore, please keep the lamp away from very humid environments.
Package Contents
Verify that all components are present in the package:
- Phlizon PL2000 LED Grow Light Unit
- 1x Power Cord
- 1x Rope Hangers (Adjustable Rope Ratchets)
- Steel Hanging Wires
- Daisy Chain Cable (if applicable to your model)
Image: Phlizon PL2000 LED Grow Light and included accessories.
Product Features
- Full Spectrum Design: Equipped with 540 LM281B LED chips, including 320pcs 3000K, 140pcs 6500K, 64pcs 660nm, 8pcs UV, and 8pcs IR LEDs, providing a comprehensive spectrum for all plant growth stages.
- Dimmable Functionality: Adjustable light intensity to meet the specific needs of plants during different growth phases.
- Daisy Chain Capability: Allows linking multiple light units together for expanded coverage, with the first light controlling the dimming for all connected units.
- Energy Efficiency: Actual power consumption of 200 watts, with a light efficacy of up to 2.8 umol/W, designed to be more energy-efficient than traditional HPS lights.
- Silent Operation: Fanless design ensures zero noise during operation.
- Water Resistant: Features an advanced waterproof power supply (IP67) and a sealed light board for water resistance (power cord interface IP20).
Image: Full spectrum LED light distribution and specific LED types.
Setup and Installation
Follow these steps to properly set up your Phlizon PL2000 LED Grow Light:
- Unpack: Carefully remove all components from the packaging.
- Inspect: Check the light unit and all accessories for any signs of damage. Do not use if damaged.
- Hang the Light: Attach the steel hanging wires to the corners of the light fixture. Use the provided rope hangers to suspend the light from a sturdy support structure in your grow area. Ensure the light is level and securely fastened.
- Connect Power: Plug the power cord into the light fixture, then into a grounded electrical outlet. Ensure the voltage matches the product specifications.
- Positioning: Adjust the height of the light above your plants using the rope hangers. Refer to the "Operating Instructions" section for recommended hanging heights for different growth stages.
Image: Phlizon PL2000 LED Grow Light installed in a grow tent.
Operating Instructions
Dimming Function
The Phlizon PL2000 features a dimmable knob to adjust light intensity. Rotate the knob to set the desired brightness level according to your plants' growth stage. Recommended settings are:
- Germination: 25% intensity, 12 inches hanging height, 10-12 hours per day.
- Seeding: 25% intensity, 12 inches hanging height, 12-14 hours per day.
- Vegetative Stage: 75% intensity, 12 inches hanging height, 16-18 hours per day.
- Bloom Stage: 100% intensity, 12 inches hanging height, 10-12 hours per day.
Image: Recommended dimming and hanging settings for plant growth stages.
Daisy Chain Function
The daisy chain feature allows you to connect multiple Phlizon PL2000 units to operate from a single power source and control. Up to 50 units can be linked. Connect the 'OUT' port of the first light to the 'IN' port of the next light using the daisy chain cable. The dimming knob on the first light will control the intensity of all connected lights.
Image: Daisy chain connection for multiple grow lights.
Coverage and PPFD Map
The Phlizon PL2000 is designed for optimal coverage in specific areas. The following PPFD (Photosynthetic Photon Flux Density) map illustrates light intensity at various hanging heights and coverage areas:
- Optimal coverage area: 2x2ft to 3x3ft.
- Maximum coverage area: 4x4ft.
Image: PPFD map indicating light intensity at different heights.
Specifications
| Feature | Detail |
|---|---|
| Model Number | PH-S20 |
| Input Voltage | 100-240Vac, 50/60Hz |
| Actual Power Consumption | 200 Watts |
| LED Type | LM281B LEDs (540 pcs total: 320x 3000K, 140x 6500K, 64x 660nm, 8x UV, 8x IR) |
| Light Efficacy | Up to 2.8 umol/W |
| PPFD Value (12" height) | 1273 umol/m² |
| Coverage Area | Optimal: 2x2ft to 3x3ft; Max: 4x4ft |
| Dimensions (L x W x H) | 21" x 14" x 2" (53.3cm x 35.6cm x 5.1cm) |
| Item Weight | 6.94 Pounds (3.15 kg) |
| Special Features | Dimmable, Daisy Chain Function, Fanless, Water Resistant (Driver IP67, Interface IP20) |
| Operating Temperature | Max 40°C |
Image: Phlizon PL2000 detailed product specifications.
Image: EU Energy Label for Phlizon PH-S20. For more information, visit eprel.ec.europa.eu/qr/1627411.
Maintenance
Proper maintenance ensures the longevity and performance of your grow light:
- Cleaning: Ensure the light is unplugged before cleaning. Gently wipe the LED board and housing with a soft, dry cloth to remove dust and debris. Do not use harsh chemicals or abrasive cleaners.
- Inspection: Periodically check the power cord, hanging wires, and connections for any signs of wear or damage. Replace any damaged components immediately.
- Environment: Maintain a suitable operating environment. Avoid exposing the light to excessively high temperatures or very humid conditions, as specified in the safety instructions.
Troubleshooting
If you encounter issues with your Phlizon PL2000 LED Grow Light, consider the following:
- Light Not Turning On:
- Check if the power cord is securely plugged into both the light and the electrical outlet.
- Verify that the electrical outlet is functioning correctly by testing it with another device.
- Ensure the dimmer knob is not set to the lowest (off) position.
- Dimming Malfunction:
- If using daisy chain, ensure the first light's dimmer is functioning correctly.
- Disconnect and reconnect the daisy chain cables to ensure proper connection.
- Unusual Noise or Smell:
- Immediately unplug the light from the power source.
- Contact customer support for assistance.
Warranty and Support
Phlizon is committed to providing high-quality products and customer satisfaction. Your Phlizon PL2000 LED Grow Light comes with a manufacturer's warranty. For specific warranty details, please refer to the product packaging or contact customer service.
If you have any questions, require technical assistance, or need to report an issue, please contact Phlizon customer support:
- Email: support@phlizon.net
- Manufacturer: Shenzhen Phlizon Technology Co., Ltd.
- EU Representative: E-CrossStu GmbH, Mainzer Landstr.69, 60329 Frankfurt am Main
Image: Manufacturer and support contact information.
