VGR V-327 5-in-1 Electric Shaver User Manual

Model: V-327

1. Introduction

Thank you for choosing the VGR V-327 5-in-1 Electric Shaver. This versatile grooming device is designed to provide a comfortable and efficient shaving and trimming experience. Please read this manual thoroughly before first use to ensure proper operation, maintenance, and safety.

2. Safety Information

To reduce the risk of electric shock, injury, or fire, always follow these basic safety precautions:

  • Do not immerse the charging adapter in water or other liquids.
  • Keep the appliance away from children.
  • Do not use the appliance if it is damaged or malfunctioning.
  • Only use the provided charging cable and adapter.
  • Ensure hands are dry when plugging or unplugging the charger.
  • The appliance is IPX7 waterproof and can be rinsed under running water, but do not submerge it for extended periods.
  • Do not disassemble the appliance. Contact authorized service personnel for repairs.

3. Product Overview

3.1 Main Features

  • 5-in-1 Versatility: Includes rotary shaver, precision trimmer, nose/ear trimmer, facial cleansing brush, and silicone cleaning brush.
  • IPX7 Waterproof: Suitable for wet and dry use, and easy to clean under running water.
  • Powerful Motor: Up to 7500 RPM with 3-speed control.
  • Long Battery Life: 900mAh battery provides 90 minutes of use after 1.5 hours of charging.
  • Durable Blades: Stainless steel construction for long-lasting sharpness.

3.2 Included Components

The VGR V-327 package includes:

  • 1 x VGR V-327 Main Unit
  • 1 x Rotary Shaver Head (with 7 floating blades)
  • 1 x Precision Trimmer Head
  • 1 x Nose & Ear Trimmer Head
  • 1 x Facial Cleansing Brush Head
  • 1 x Silicone Facial Cleansing Brush Head
  • 3 x Guide Combs for Precision Trimmer (various lengths)
  • 1 x USB Charging Cable
  • 1 x Cleaning Brush
  • 1 x Lubricating Oil
  • 1 x User Manual
VGR V-327 shaver with all included accessories and packaging

Image 1: VGR V-327 main unit, various attachment heads, guide combs, charging cable, cleaning brush, and lubricating oil, displayed alongside its retail packaging.

VGR V-327 shaver with different heads attached: rotary shaver, precision trimmer, nose trimmer, and facial brush

Image 2: The VGR V-327 shaver body shown with four interchangeable heads: the 7-blade rotary shaver head, the precision trimmer head, the nose and ear trimmer head, and the facial cleansing brush head.

Detailed view of VGR V-327 shaver heads and their specific uses

Image 3: A visual guide demonstrating the function of each VGR V-327 attachment: rotary shaver head for bald heads, precision trimmer for hair styling, nose trimmer for ear/nose hair, facial cleaning brush for skin cleansing, and silicone cleaning brush for gentle exfoliation.

4. Setup

4.1 Charging the Shaver

  1. Ensure the shaver is turned off.
  2. Insert the small end of the USB charging cable into the charging port at the bottom of the shaver.
  3. Connect the large end of the USB cable to a compatible USB power adapter (not included) or a computer USB port.
  4. The LED display will show the charging status. A full charge takes approximately 1.5 hours.
  5. Disconnect the charger once fully charged to preserve battery life.

4.2 Attaching/Detaching Heads

  1. To attach a head, align the head with the main unit and press it down until it clicks into place.
  2. To detach a head, firmly grasp the head and pull it upwards away from the main unit.
  3. Ensure the shaver is turned off before changing heads.

5. Operating Instructions

5.1 Power On/Off and Speed Control

  • Press the power button once to turn the shaver on. The LED display will show the current speed and battery level.
  • Press the power button again to cycle through the 3 available speeds (6500, 7000, 7500 RPM).
  • Press and hold the power button for 3 seconds to turn the shaver off.

5.2 Using the Rotary Shaver Head

  • Attach the 7-blade rotary shaver head.
  • For best results, use on clean, dry skin. Can also be used with shaving foam/gel for a wet shave.
  • Move the shaver in small, circular motions over the skin, applying gentle pressure.
  • Stretch the skin with your free hand to ensure a close shave.

5.3 Using the Precision Trimmer Head

  • Attach the precision trimmer head.
  • Select the desired guide comb (if needed) and attach it to the trimmer head.
  • Use for shaping beard lines, sideburns, or trimming body hair to a specific length.
  • Move the trimmer against the direction of hair growth for an even trim.

5.4 Using the Nose & Ear Trimmer Head

  • Attach the nose & ear trimmer head.
  • Gently insert the trimmer tip into the nostril or ear canal.
  • Move the trimmer slowly to remove unwanted hair. Do not insert too deeply.

5.5 Using the Facial Cleansing Brush Heads

  • Attach either the facial cleansing brush head or the silicone facial cleansing brush head.
  • Apply your preferred facial cleanser to your face or directly to the brush head.
  • Gently move the brush in circular motions over your face to cleanse and exfoliate.
  • Rinse your face and the brush head thoroughly after use.

6. Maintenance and Cleaning

6.1 Daily Cleaning

  1. After each use, turn off the shaver and detach the head.
  2. Rinse the shaver head and the main unit (if necessary) under warm running water. The IPX7 rating allows for easy rinsing.
  3. Use the small cleaning brush to remove any stubborn hair clippings from the blades or inside the head.
  4. Shake off excess water and allow all parts to air dry completely before reattaching or storing.

6.2 Lubrication

  • Periodically, after cleaning and drying, apply 1-2 drops of the provided lubricating oil to the blades of the rotary shaver head and precision trimmer head.
  • Run the shaver for a few seconds to distribute the oil. This helps maintain blade performance and longevity.

6.3 Storage

  • Store the shaver and its accessories in a cool, dry place, away from direct sunlight and extreme temperatures.
  • Keep the protective cap on the rotary shaver head when not in use.

7. Troubleshooting

Problem Possible Cause Solution
Shaver does not turn on. Battery is depleted. Charge the shaver for 1.5 hours.
Poor shaving performance. Blades are dirty or dull; hair is too long. Clean the shaver head thoroughly. Lubricate blades. For longer hair, pre-trim with the precision trimmer.
Shaver makes unusual noise. Hair trapped in blades; lack of lubrication. Clean the shaver head. Apply lubricating oil to the blades.
Charging indicator not working. Charging cable or adapter faulty; poor connection. Check cable and adapter. Ensure secure connection. Try a different USB port or adapter.

8. Specifications

  • Model: VGR V-327
  • Body Material: ABS
  • Blade Material: Stainless Steel
  • Battery Type: Lithium-ion
  • Battery Capacity: 900 mAh
  • Power: 5W
  • Motor Speeds: 3 (6500, 7000, 7500 RPM)
  • Charging Time: Approximately 1.5 hours
  • Usage Time: Up to 90 minutes
  • Waterproof Rating: IPX7
  • Dimensions (Main Unit): 7.8 x 10.1 x 12.7 cm (approximate)
  • Weight: 296 grams (approximate)

9. Warranty and Support

VGR products are manufactured to high-quality standards. This product comes with a standard manufacturer's warranty against defects in materials and workmanship from the date of purchase. Please retain your proof of purchase for warranty claims.

For technical support, warranty service, or inquiries about replacement parts, please contact your retailer or visit the official VGR website for contact information.
