Introduction
Thank you for choosing the doona Infant Car Seat & Stroller. This innovative product is designed to provide a safe and convenient mobility solution for your infant, functioning as a rear-facing car seat, a stroller, and a reclining cot. Please read this manual carefully before use to ensure proper installation, operation, and maintenance, and to maximize the safety and comfort of your child.
Safety Information
Important Safety Warnings:
- Always ensure your child is properly secured in the 5-point harness.
- Never leave your child unattended in the doona.
- This product is suitable for infants from birth up to 13 kg (approximately 0-12 months).
- Always use the doona in a rear-facing position when installed in a vehicle.
- Ensure all locking mechanisms are engaged before placing your child in the stroller or car seat.
- Do not use accessories or replacement parts other than those approved by doona.
- Regularly inspect the product for any signs of wear, damage, or malfunction. Discontinue use if any issues are found.
The doona Infant Car Seat & Stroller complies with the highest EU and US safety standards, including ECE R44, EN1888, EN12790, and TUV certifications.
Setup and Initial Use
Unpacking and First Inspection
Carefully remove all components from the packaging. Inspect the doona for any damage that may have occurred during shipping. If any damage is found, do not use the product and contact customer service immediately.
Infant Insert Installation
The doona comes with an ergonomically designed infant insert, developed with medical professionals, to provide a comfortable and natural posture for newborns. This insert should be used for infants from birth until they reach approximately 5 kg or 3 months of age. After this, the insert can be removed.
Car Seat Installation (Rear-Facing Only)
The doona can be installed in a vehicle using either the vehicle's seatbelt or an ISOFIX base (sold separately).
Using the Vehicle Seatbelt:
- Place the doona on the vehicle seat in a rear-facing position.
- Route the vehicle's 3-point seatbelt through the blue belt guides on the doona.
- Buckle the seatbelt and pull it tight to remove any slack.
- Ensure the doona is securely installed and does not move more than 1 inch in any direction at the belt path.
Using the ISOFIX Base:
- Attach the ISOFIX base to your vehicle's ISOFIX anchor points according to the base's instruction manual.
- Ensure the indicators on the ISOFIX base show a secure connection.
- Place the doona car seat onto the ISOFIX base until it clicks securely into place.
- Verify that the car seat is firmly attached to the base.
Operating Modes
The doona is a unique 3-in-1 mobility solution, seamlessly transitioning between a car seat, a stroller, and a reclining cot.
Car Seat Mode
In car seat mode, the wheels are folded underneath the unit, making it compact for vehicle travel. This mode is suitable for cars, taxis, and even approved for use on aircraft seats.
Stroller Mode (Sidewalk Mode)
To convert to stroller mode, simply extend the wheels and handle. This mode is ideal for navigating narrow spaces like shopping aisles, cafes, or elevators, and for general outings with your baby.
Reclining Cot Mode (Bouncer Mode)
The doona can also function as a reclining cot, providing a comfortable resting space for your infant outside of the car or while stationary. This mode meets the EN12790 safety standard for bouncers.
Harness Adjustment
The 5-point harness should always be adjusted snugly against your child's body. The shoulder straps should be at or just below your child's shoulders when rear-facing. Refer to the labels on the harness for specific adjustment instructions.
Maintenance and Care
Cleaning Instructions
- Fabric Covers: All fabric covers are removable and washable. Please refer to the care label attached to the fabric for specific washing instructions (e.g., machine wash cold, gentle cycle, air dry).
- Frame and Plastic Parts: Wipe clean with a damp cloth and mild soap. Do not use abrasive cleaners or solvents.
- Harness: Wipe the harness straps with a damp cloth. Do not immerse the harness buckle in water.
Storage
When not in use, store the doona in a clean, dry place away from direct sunlight and extreme temperatures. Ensure the wheels are locked if storing in stroller mode.
Regular Inspection
Periodically check all parts for wear and tear, especially the wheels, harness, buckles, and locking mechanisms. Ensure all screws and fasteners are tight. If any part is damaged or missing, contact customer service for replacement parts. Do not use the product if it is damaged.
Troubleshooting
| Problem | Possible Cause | Solution |
|---|---|---|
| Wheels not extending/retracting smoothly | Dirt or debris in the mechanism; lack of lubrication. | Clean the wheel mechanisms. Apply a silicone-based lubricant if necessary. |
| Harness too tight/loose | Incorrect adjustment. | Refer to the harness adjustment section in this manual to properly adjust the straps. |
| Car seat not securing tightly in vehicle | Incorrect belt routing; seatbelt not tightened enough; ISOFIX connectors not fully engaged. | Re-read the car seat installation instructions. Ensure the seatbelt is routed correctly and pulled tight, or that ISOFIX connectors are fully engaged and indicators are green. |
| Product feels unstable in stroller mode | Wheels not fully extended and locked. | Ensure all wheels are fully extended and locked into position before use. |
If you encounter a problem not listed here or if the suggested solutions do not resolve the issue, please contact doona customer service for assistance.
Product Specifications
- Model Number: 758011
- Brand: doona (Grandoir International)
- Color: Royal Blue
- Recommended Age: 0 months ~ (Newborn to approximately 12 months)
- Maximum Recommended Weight: 13 kg (28.6 lbs)
- Product Weight: 7 kg (15.4 lbs)
- Harness Type: 5-point harness
- Installation Type: ISOFIX, Seatbelt
- Orientation: Rear-facing only
- Safety Standards: ECE R44, EN1888, EN12790, TUV, FMVSS-213 (US standard)
- Dimensions (Stroller Mode): 44 x 82 x 99 cm (Width x Length x Height)
- Dimensions (Car Seat Mode): 44 x 66 x 60 cm (Width x Length x Height)
- Package Size: 73 x 46.5 x 41 cm
Warranty and Support
Warranty Information
The doona Infant Car Seat & Stroller comes with a 2-year warranty from the date of purchase. This warranty covers manufacturing defects in materials and workmanship under normal use. It does not cover damage caused by misuse, accidents, unauthorized modifications, or normal wear and tear.
Please retain your proof of purchase for warranty claims.
Customer Support
For any questions, inquiries, or warranty claims regarding your doona product, please contact Grandoir International Customer Service directly:
Email: customer@grandoir.com
Please provide your model number (758011) and a detailed description of your issue when contacting support.
