1. Introduction
This manual provides essential information for the safe and effective use of your GEARit 14 AWG 100 Foot SJTW Outdoor Extension Cord. Please read these instructions carefully before use and retain them for future reference. This extension cord is designed for both indoor and outdoor applications, providing reliable power for various tools and appliances.
2. Safety Information
WARNING: Failure to follow these safety instructions may result in fire, electric shock, or serious injury.
- Inspect Before Use: Always inspect the extension cord for any damage (cuts, fraying, exposed wires) before each use. Do not use a damaged cord.
- Proper Rating: Ensure the cord's amperage and wattage ratings are suitable for the appliance or tool being powered. Overloading can cause overheating and fire. This 14 AWG cord is rated for 13 Amp, 125 Volt, 1625 Watt.
- Grounding: This is a 3-prong grounded cord. Always plug it into a properly grounded 3-prong outlet. Never remove the grounding prong.
- Outdoor Use: This cord is SJTW rated for outdoor use. However, avoid submerging it in water or using it in excessively wet conditions unless specifically designed for such environments. Keep connections dry.
- Avoid Overheating: Do not cover the cord with rugs, furniture, or other materials that could prevent heat dissipation. Uncoil the cord fully before use to prevent heat buildup.
- Children and Pets: Keep extension cords out of reach of children and pets.
- Disconnect When Not in Use: Always unplug the cord from the power source and disconnect appliances when not in use.
- Pull from Plug: Always pull the plug, not the cord, when disconnecting from an outlet.
3. Product Features
The GEARit 14 AWG 100 Foot SJTW Outdoor Extension Cord is engineered for durability and performance.
- Heavy-Duty Construction: Features 14 AWG (American Wire Gauge) wire with 3 conductors, ensuring efficient and consistent power delivery.
- SJTW Rated: The Service, Junior, Thermoplastic, Weather (SJTW) jacket provides resistance to moisture, abrasion, and extreme temperatures, making it suitable for various weather conditions from -40°F to 130°F (-40°C to 54°C).
- High Power Capacity: Capable of carrying 13 Amp, 125 Volt, 1625 Watt over its 100-foot length.
- LED Power Indicator: Built-in LED lights on the 3-prong connectors illuminate when power is flowing, providing a visual confirmation of active power.
- High Visibility: The bright yellow jacket enhances visibility, reducing tripping hazards in outdoor environments.
Figure 3.1: Internal construction of the extension cord, highlighting 14 AWG wire, oxygen-free copper, and SJTW insulation.
Figure 3.2: SJTW rating indicating the cord's temperature resistance for outdoor use.
Figure 3.3: Illuminated LED power indicator light on the cord's receptacle.
4. Setup and Installation
- Uncoil the Cord: Fully uncoil the extension cord before use to prevent overheating.
- Connect to Power Source: Plug the male end of the extension cord into a standard 3-prong, 125V grounded electrical outlet.
- Verify Power: Check the LED indicator light on the female end of the extension cord. If it is illuminated, power is flowing through the cord.
- Connect Appliance: Plug your appliance or tool into the female end of the extension cord. Ensure the appliance's power requirements do not exceed the cord's rating (13 Amp, 1625 Watt).
Figure 4.1: Extension cord in use with an outdoor appliance.
5. Operating Instructions
This extension cord is suitable for a wide range of applications, including:
- Powering lawn and garden equipment (e.g., lawnmowers, leaf blowers, trimmers).
- Supplying power to power tools (e.g., drills, belt sanders).
- General household and workshop use where extended reach is required.
Always ensure the cord is placed in a manner that minimizes tripping hazards and protects it from damage by sharp objects or heavy equipment. The bright yellow color aids in visibility.
Figure 5.1: Examples of tools compatible with a 14 AWG extension cord.
Figure 5.2: Guide for selecting the appropriate cord gauge based on application and length.
6. Maintenance
- Regular Inspection: Periodically inspect the cord for any signs of wear, cuts, cracks, or damage to the insulation or plugs. Discontinue use immediately if damage is found.
- Cleaning: Wipe the cord with a dry or slightly damp cloth to remove dirt and debris. Ensure the cord is unplugged and dry before cleaning. Do not use harsh chemicals or abrasive cleaners.
- Storage: When not in use, coil the cord neatly and store it in a dry location, away from direct sunlight, extreme temperatures, and corrosive materials. Avoid kinking or tightly bending the cord.
7. Troubleshooting
| Problem | Possible Cause | Solution |
|---|---|---|
| No power to appliance (LED indicator off) |
|
|
| Cord feels warm during use |
|
|
8. Specifications
| Feature | Detail |
|---|---|
| Model Number | LA004I/LA005G |
| Wire Gauge | 14 AWG |
| Length | 100 Feet |
| Amperage Rating | 13 Amp |
| Voltage Rating | 125 Volts |
| Wattage Rating | 1625 Watts |
| Jacket Type | SJTW (Service, Junior, Thermoplastic, Weather) |
| Plug Type | 3-Prong Grounded (Type B) |
| Color | Yellow |
| Product Dimensions | 8 x 5 x 2 inches |
| Item Weight | 9.17 pounds |
9. Warranty and Support
For warranty information or technical support, please refer to the product packaging or contact GEARit customer service directly. Contact details can typically be found on the manufacturer's official website or through your point of purchase.
