iLC TD3C001 8W LED Recessed Ceiling Lights Instruction Manual

1. Important Safety Information

Please read all instructions carefully before installation and use. Retain this manual for future reference.

Electrical Safety: Installation should be performed by a qualified electrician in accordance with local electrical codes. Ensure power is disconnected at the circuit breaker before installation or maintenance.
Dimmer Switch Incompatibility: These lights are NOT compatible with dimmer switches. Attempting to use them with a dimmer switch may cause damage or malfunction.
Indoor Use Only: This product is designed for indoor use in dry locations.
Operating Voltage: The lights can operate directly on 85-265V voltage due to a built-in transformer.
IP Rating: The product has an IP44 rating, indicating protection against solid objects larger than 1mm and splashing water from any direction.

2. Package Contents

Verify that all components are present before proceeding with installation:

iLC 8W LED Recessed Ceiling Lights (Quantity as purchased, e.g., 4 pieces)
Remote Control (requires 2 CR2032 batteries, not included)
Instruction Manual

3. Product Specifications

Specification	Value
Model Number	TD3C001
Power	8W LED (equivalent to 60W incandescent)
Luminous Flux	800 Lumens
Color Temperature	2700K Warm White + RGB
Color Rendering Index (CRI)	>85Ra
Input Voltage	85-265V AC
Material	Aluminum
Color	White
Light Fixture Form	Recessed
Product Dimensions (Diameter x Height)	90mm (3.54 inches) x 40mm (1.57 inches)
Recommended Cutout Size	6.47 - 8.48 cm (2.55 - 3.34 inches)
IP Rating	IP44
Energy Efficiency Class	E

For detailed energy information, please refer to the EU EPREL database: https://eprel.ec.europa.eu/qr/1673597

4. Installation

These recessed ceiling lights are designed for easy installation. Always ensure power is off before beginning.

4.1 Dimensions and Cutout

The light fixture has a diameter of 90mm (3.54 inches) and a height of 40mm (1.57 inches). A ceiling cutout of 6.47 - 8.48 cm (2.55 - 3.34 inches) is required for proper installation.

Diagram showing the dimensions of the recessed LED light and the required ceiling cutout size.

Image: Diagram illustrating the product dimensions and the recommended ceiling cutout size for installation.

4.2 Installation Steps

Turn off Power: Ensure the main power supply to the installation area is switched off at the circuit breaker.
Prepare Ceiling: Cut a circular hole in the ceiling with a diameter between 6.47 cm and 8.48 cm (2.55 - 3.34 inches).
Connect Wiring: Connect the light's wiring to your household electrical wiring. Ensure all connections are secure and insulated. The lights are wired electric and operate on 85-265V.
Insert Light: Gently push the light fixture into the cutout. The spring clips on the sides will hold the light securely in place.
Restore Power: Once the light is securely installed, restore power at the circuit breaker.

5. Operating Instructions

The iLC LED Recessed Ceiling Lights are controlled using the included remote control.

5.1 Remote Control Overview

The remote control allows you to manage all functions of the lights, including power, color, brightness, and special modes.

Image of the remote control with buttons for On/Off, color selection, brightness, and timing functions.

Image: The remote control for the iLC LED Recessed Ceiling Lights, showing various buttons for color, brightness, and mode selection.

On/Off Buttons: Power the lights on or off.
Color Selection: Choose from 12 preset colors or select Warm White (2700K).
Brightness Adjustment: Adjust brightness to 100% (daily lighting), 30% (night auxiliary lighting), or 10% (sleep mode).
Mode Buttons: Activate Flash or Smooth color-changing modes.
Timing Buttons: Set the lights to turn off automatically after a set period (e.g., 1 hour, 2 hours).

5.2 Color and Brightness Adjustment

The lights offer both warm white illumination and a spectrum of colors.

Warm White (2700K): Provides bright, daily illumination at 800 lumens.
12 RGB Colors: Select from 12 distinct colors to create various atmospheres.
Brightness Levels: Adjust the intensity for different needs: 100% for general lighting, 30% for ambient night light, and 10% for a soft sleep mode.

Graphic showing 60W equivalent, 8W LED, 800 Lumens, and 2700K Warm White specifications.

Image: Key specifications of the iLC LED light, highlighting its 8W power, 800 lumens output, and 2700K warm white color.

5.3 Special Modes: Flash and Smooth

Enhance your environment with dynamic lighting effects.

Flash Mode: Provides a theatrical effect, suitable for music or entertainment.
Smooth Mode: Cycles automatically through a gradual change of colors, ideal for creating a relaxing and comfortable ambiance.

5.4 Memory Function

The lights remember the last color or mode setting used, so they will power on with your preferred setting.

5.5 Timing Function

Set the lights to automatically turn off after a specified duration or on a daily cycle.

Auto-Off: Use the remote control to set the lights to turn off after a few hours.
24-Hour Cycle: Program the lights to turn on and off at specific times daily, useful for bedrooms, living rooms, hallways, or closets.

6. Usage Scenarios

These versatile lights are suitable for various indoor applications, allowing you to customize the lighting to suit any mood or activity.

Room illuminated with purple and blue RGB lighting from recessed ceiling lights.

Image: A modern living space showcasing the vibrant RGB lighting capabilities of the iLC recessed lights.

Collage of rooms showing recessed lights in a living room, kitchen, bathroom, and bedroom.

Image: Examples of iLC recessed lights installed in various home settings, including living rooms, kitchens, bathrooms, and bedrooms.

The high CRI (>85Ra) ensures that colors appear true and vibrant, without any ripple effect, making them suitable for photography and video environments.

Comparison showing high CRI lighting on the left with true colors and no ripples, versus low CRI lighting on the right with duller colors and visible ripples.

Image: A visual comparison demonstrating the superior color rendering (High CRI > 85Ra) and absence of ripple effect with iLC lights compared to standard lights.

7. Maintenance

To ensure the longevity and optimal performance of your iLC LED Recessed Ceiling Lights, follow these simple maintenance guidelines:

Cleaning: Disconnect power before cleaning. Use a soft, dry cloth to wipe the surface of the lights. Avoid abrasive cleaners or solvents that could damage the finish.
Inspection: Periodically check for any loose connections or signs of damage. If any issues are found, consult a qualified electrician.

8. Troubleshooting

If you encounter any issues with your iLC LED Recessed Ceiling Lights, refer to the following common troubleshooting steps:

Lights Not Turning On:
- Check if the power supply to the lights is active.
- Ensure the remote control batteries are not depleted and are inserted correctly.
- Verify that the wiring connections are secure.
Remote Control Not Responding:
- Replace the CR2032 batteries in the remote control.
- Ensure there are no obstructions between the remote control and the lights.
Lights Flickering or Malfunctioning:
- Confirm that the lights are not connected to a dimmer switch. These lights are not compatible with dimmers.
- Ensure the input voltage is within the specified range (85-265V).
- If the issue persists, disconnect power and recheck all wiring connections.

If these steps do not resolve the issue, please contact customer support for further assistance.

9. Warranty and Support

For warranty information or technical support, please refer to the product packaging or contact the retailer where the product was purchased. Keep your purchase receipt as proof of purchase.
