Introduction
This manual provides essential information for the proper installation, operation, and maintenance of the JUNG A 5585 BF WW Frame 5-Way. This product is a high-quality, glossy black, 5-compartment frame designed for various electrical installations.
This image displays the JUNG A 5585 BF WW 5-Way Frame, showing its five rectangular openings arranged vertically within a white, polished plastic frame. Note: The actual product color is glossy black as per description, the image might represent a different color variant for illustrative purposes of the frame structure.
Product Overview
The JUNG A 5585 BF WW Frame is designed to accommodate five electrical units, providing a clean and organized appearance for your installations. Key features include:
- Designed for five units.
- Supports both horizontal and vertical mounting directions.
- Suitable for flush-mounted installations.
- Constructed from durable plastic with a polished finish.
- Part of the JUNG A series, ensuring compatibility with other JUNG components.
Setup and Installation
The JUNG A 5585 BF WW Frame is designed for straightforward screw-in installation. Ensure all power is disconnected before beginning any electrical work.
Installation Steps:
- Preparation: Ensure the electrical box is properly installed and all wiring is safely terminated.
- Mounting: Align the frame with the electrical box. The frame supports both horizontal and vertical orientations.
- Securing: Use appropriate screws to secure the frame to the wall or electrical box. Do not overtighten.
- Component Insertion: Carefully insert the desired electrical components (e.g., switches, outlets) into the five compartments of the frame.
- Final Check: Ensure all components are securely seated and the frame is flush with the wall surface.
Note: Installation should be performed by a qualified electrician if you are unsure about any steps.
Operation
The JUNG A 5585 BF WW Frame serves as a decorative and functional housing for electrical components. Once installed, its primary function is to provide a finished appearance and secure mounting for up to five decorator-style devices. There are no operational controls on the frame itself; operation pertains to the devices installed within it.
Care and Maintenance
To maintain the appearance and longevity of your JUNG A 5585 BF WW Frame, follow these simple care instructions:
- Cleaning: Wipe the frame with a soft, damp cloth. Avoid abrasive cleaners, solvents, or harsh chemicals, as these can damage the polished plastic finish.
- Dusting: Regularly dust the frame to prevent buildup.
- Inspection: Periodically check for any loose screws or signs of damage. Address any issues promptly to ensure continued safety and aesthetics.
Troubleshooting
Most issues related to the frame are installation-dependent. If you encounter problems, consider the following:
- Frame Not Flush: Ensure the electrical box is properly recessed and the mounting screws are tightened evenly. Check for any obstructions behind the frame.
- Components Don't Fit: Verify that the components you are installing are compatible with decorator-style openings and that they are correctly aligned before attempting to secure them.
- Scratches/Damage: While the polished finish is durable, avoid sharp objects or rough handling during installation and cleaning. Minor scratches may be buffed out with specialized plastic polish, but severe damage may require replacement.
If problems persist, consult a qualified electrician or contact JUNG customer support.
Technical Specifications
| Feature | Specification |
|---|---|
| Model Number | A 5585 BF WW |
| Brand | JUNG |
| Configuration | Fivefold (5 units) |
| Material | Plastic |
| Color | Schwarz Glänzend (Glossy Black) |
| Finish Type | Polished |
| Mounting Direction | Horizontal / Vertical |
| Installation Type | Screw-In |
| Item Weight | 2.82 ounces |
| Product Dimensions | 3.19 x 14.53 x 0.39 inches |
| Item Package Quantity | 1 |
| Batteries Required? | No |
| ASIN | B07RHW214J |
| Date First Available | April 16, 2025 |
Warranty and Support Information
JUNG products are manufactured to high quality standards. For specific warranty details, please refer to the documentation included with your purchase or visit the official JUNG website. Keep your proof of purchase for warranty claims.
For technical support or inquiries, please contact JUNG customer service through their official channels. Contact information can typically be found on the manufacturer's website or product packaging.
