Bosch 13 Place Setting Dishwasher SMS66GW01I User Manual

Introduction

This manual provides essential instructions for the safe and efficient operation, installation, and maintenance of your Bosch 13 Place Setting Dishwasher, model SMS66GW01I. Designed for Indian kitchens, this appliance offers advanced cleaning features including the Intensive Kadhai Program and 70°C hot water wash for effective stain and bacteria removal. Please read this manual thoroughly before using your dishwasher to ensure optimal performance and longevity.

Image: A collage highlighting key features of the Bosch dishwasher, including 70°C hot water wash, 6 wash programs, 9.5 liters water usage, and Load & Aqua Sensor technology.

Safety Information

Always adhere to the following safety guidelines to prevent injury or damage to the appliance:

• Ensure the dishwasher is properly grounded before use.
• Do not allow children to operate or play near the dishwasher.
• Use only detergents and rinse aids specifically designed for automatic dishwashers.
• Avoid opening the door during operation, especially during hot wash cycles.
• Sharp items should be loaded with points and handles down to prevent injury.
• In areas with voltage fluctuations, a voltage stabilizer is recommended to protect the appliance.
• Do not place copper-bottom utensils, thin aluminum vessels, soft plastic items, or cheap glassware in the dishwasher, as they may be damaged.

What's in the Box

Upon unpacking, verify that all components are present:

• 1 Bosch SMS66GW01I Dishwasher Unit
• 1 Inlet Pipe
• 1 Outlet Pipe
• 1 Electrical Wire with Plug
• 1 Detergent Sample

Inspect the appliance for any shipping damage, dents, or other irregularities before installation.

Setup and Installation

Dimensions and Placement

The Bosch SMS66GW01I is a freestanding dishwasher with dimensions of 60 cm (Depth) x 60 cm (Width) x 84.5 cm (Height). Ensure adequate space for installation and proper ventilation.

Image: Bosch SMS66GW01I Dishwasher with detailed dimensions (60cm D x 60cm W x 84.5cm H) shown next to a human figure for scale.

Water and Electrical Connections

• Connect the inlet pipe to a cold water supply. The water inlet pipe is standard length; extensions may be required depending on placement.
• Position the outlet pipe for proper drainage.
• Connect the electrical wire to a grounded power outlet (220V).
• For areas with hard water, it is crucial to fill the salt dispenser. Open the salt bay cover, pour approximately 1 liter of drinking water or soft water into it, then add dishwasher salt (e.g., 80% of a 1kg packet).
• Set the water hardness level on the dishwasher according to your local water supply. A water hardness testing strip can help determine the correct setting.

First Use

Before the first wash cycle, ensure the salt dispenser is filled and the rinse aid dispenser is topped up. It is recommended to run an ECO mode cycle (approximately 1 hour 30 minutes) without dishes for the initial use to prime the system.

Operating Instructions

Loading Utensils

Proper loading is essential for effective cleaning. The Bosch SMS66GW01I is designed to accommodate various Indian utensils.

Image: Various Indian utensils, including kadhais and patilas, arranged neatly on a kitchen counter, indicating suitability for the dishwasher.

• Place larger items like kadhais and patilas in the lower rack.
• Smaller items such as plates, bowls, cups, and cutlery go in the upper rack or the dedicated cutlery box.
• Ensure items do not block the spray arms.
• Do not overload the dishwasher.

Image: Interior view of the Bosch dishwasher showing a full load of various dishes and cutlery in both upper and lower racks.

Image: Interior view of the Bosch dishwasher showing a half load of dishes, primarily in the lower rack, demonstrating the half-load option.

Image: A grey additional cutlery box with multiple compartments, designed to hold forks, spoons, and knives securely during a wash cycle.

Wash Programs

The SMS66GW01I offers 6 wash programs to suit different cleaning needs:

Image: Close-up of the Bosch dishwasher control panel, highlighting the selection buttons for the 6 wash programs: Intensive Kadhai, Auto, Express Sparkle, Eco, Quick, and Pre-rinse.

1. Intensive Kadhai 70°C: Specifically designed for heavily soiled Indian utensils, removing oily masala stains with 70°C hot water.
2. Auto 45-65°C: Automatically adjusts temperature and water usage based on soil level detected by sensors.
3. Express Sparkle 65°C: For quick cleaning and drying of moderately soiled dishes.
4. Eco 50°C: Energy and water-efficient program for normally soiled dishes.
5. Quick 45°C: A shorter cycle for lightly soiled dishes and glassware.
6. Pre-rinse: A short rinse cycle to remove loose food particles before a main wash, using cold water.

Image: A stainless steel kadhai being cleaned by powerful water jets, illustrating the effectiveness of the Intensive Kadhai Program on oily masala stains.

Special Features

• Eco Silence Drive: A powerful and durable motor ensuring low power consumption and high cleaning efficiency with reduced noise.


Image: A cutaway diagram of the Ecosilence Drive motor, showcasing its internal components and design for quiet and efficient operation.

• Glass Protection Technology: Gentle on delicate glassware, ensuring brilliant cleaning results without damage.


Image: The upper rack of the dishwasher filled with various glasses and white plates, demonstrating the Glass Protection Technology in action.

• Half Load Option: Allows for washing smaller loads efficiently, saving water and energy.
• Dosage Assist: Ensures optimal dissolution of detergent tablets for thorough cleaning.
• Extra Dry: Provides enhanced drying performance for perfectly dry dishes.
• Hygienic Wash: The 70°C hot water wash kills 99.9% of bacteria, ensuring hygienic results.


Image: A split image comparing a hand-washed sipper (left, showing bacteria) with a dishwasher-cleaned sipper (right, showing cleanliness and bacteria removal at 70°C).

Maintenance and Care

Consumables

• Dishwasher Detergent: Use only automatic dishwasher detergent. Check the detergent dispenser regularly and refill as needed.
• Dishwasher Salt: The salt indicator light on the control panel will illuminate when a refill is required. Regular refilling of salt is crucial for water softening, especially in hard water areas.
• Rinse Aid: The rinse aid indicator light will signal when a refill is needed. Rinse aid helps prevent water spots and improves drying performance.

Cleaning Filters

Regularly clean the filter system at the bottom of the dishwasher to ensure optimal cleaning performance and prevent blockages. Refer to the detailed instructions in the full user manual for filter removal and cleaning procedures.

Exterior Cleaning

Wipe the exterior surfaces of the dishwasher with a soft, damp cloth. Avoid abrasive cleaners or solvents.

Troubleshooting

If you encounter issues with your dishwasher, consult the following common troubleshooting tips:

• Dishes not clean:
  • Ensure proper loading, avoiding obstruction of spray arms.
  • Check detergent levels and ensure the correct program is selected for the soil level.
  • Verify that the water hardness setting is appropriate and the salt dispenser is filled.
  • Clean the filters at the bottom of the dishwasher.
• Dishwasher not starting or displaying error:
  • Check power supply and ensure the door is fully closed.
  • If experiencing voltage fluctuations, ensure a voltage stabilizer is in use.
  • Refer to the full user manual for specific error codes and their solutions.
• Water spots or poor drying:
  • Refill the rinse aid dispenser.
  • Adjust the rinse aid dosage setting if necessary.
  • Ensure the "Extra Dry" option is selected if desired.

For persistent issues, contact customer support.

Technical Specifications

Warranty and Support

Warranty Information

Your Bosch SMS66GW01I Dishwasher comes with a 2-year comprehensive warranty on the product and a 10-year warranty against rust. The warranty can be availed using your Amazon invoice as proof of purchase.

Customer Support

For service, technical assistance, or to access the full user manual, please contact Bosch customer support or visit the official brand website. Only authorized service centers should perform repairs.

Manufacturer: BSH Household Appliances Manufacturing Pvt Ltd. Arena House, 2Nd Floor, Main Building, Plot No- 103, Road No-12, MIDC, Andheri (East), Mumbai- 400093, Phone- 022- 67518000

You can also visit the Bosch Store on Amazon for more product information.
