Clymer Repair Manual for Harley-Davidson Dyna Models 1999-2005

Introduction and Overview

This Clymer repair manual provides comprehensive service, repair, and maintenance information for Harley-Davidson Dyna motorcycles manufactured between 1999 and 2005. It is designed to assist both the do-it-yourselfer and the experienced mechanic in understanding and performing various tasks on their motorcycle.

Each manual contains hundreds of original photographs and illustrations, derived from the complete disassembly and assembly of the covered machines, ensuring accuracy and clarity in instructions.

Covered Models

This manual specifically covers the following Harley-Davidson Dyna models for the years 1999-2005:

• Harley-Davidson CVO Wide Glide FXDWGSE (2001-2002)
• Harley-Davidson Dyna Glide CONV (1999-2000)
• Harley-Davidson Dyna Glide FXD/C/I (1999-2005)
• Harley-Davidson Dyna Low Rider FXDL (1999-2005)
• Harley-Davidson Dyna Super Glide FXD (1999-2005)
• Harley-Davidson Dyna Super Glide Sport FXDX (1999-2005)
• Harley-Davidson Dyna Super Glide T Sport FXDXT (2000-2003)
• Harley-Davidson Dyna Wide Glide FXDWG/I (1999-2005)

Image: A detailed list of Harley-Davidson Dyna models and their respective years of coverage by this Clymer repair manual.

Using Your Clymer Manual: Setup

Before beginning any repair or maintenance task, ensure you have a clean, well-lit workspace. Gather all necessary tools and safety equipment. Familiarize yourself with the manual's layout, including chapter organization and safety warnings. It is recommended to read through the entire procedure before starting work to understand the steps involved and anticipate any required parts or specialized tools.

Operating Instructions for Effective Use

To effectively use this manual:

1. Identify Your Model: Confirm your specific Harley-Davidson Dyna model and year fall within the covered range (1999-2005) as listed in the "Covered Models" section.
2. Consult the Index: Use the comprehensive index at the back of the manual to quickly locate specific topics, components, or procedures.
3. Read Thoroughly: Always read the entire procedure from start to finish before beginning any work. Pay close attention to safety warnings, cautions, and notes.
4. Understand Diagrams and Illustrations: Refer to the numerous photographs and diagrams provided. These visual aids are crucial for understanding component locations, assembly sequences, and wiring.
5. Follow Step-by-Step Instructions: Perform tasks sequentially as outlined. Do not skip steps unless explicitly instructed.
6. Torque Specifications: Always adhere to the specified torque values for fasteners to prevent damage or component failure.

Maintenance Procedures

This manual details routine maintenance tasks essential for the longevity and performance of your Harley-Davidson Dyna. Regular maintenance includes:

• Fluid checks and changes (engine oil, transmission fluid, primary chaincase lubricant, brake fluid)
• Filter replacement (oil filter, air filter)
• Spark plug inspection and replacement
• Brake system inspection and adjustment
• Tire inspection and pressure checks
• Cable and chain adjustments
• General fastener torque checks

Refer to the specific maintenance schedule and procedures outlined in the manual for your model year.

Troubleshooting Guide

The manual includes dedicated sections to assist in diagnosing common problems. When troubleshooting, follow these general steps:

1. Identify Symptoms: Clearly define the issue your motorcycle is experiencing.
2. Consult Troubleshooting Charts: Locate the relevant troubleshooting chart in the manual, which typically lists symptoms and potential causes.
3. Perform Checks: Systematically check the components and systems suggested by the chart, starting with the simplest and most common causes.
4. Isolate the Problem: Through elimination, narrow down the potential source of the malfunction.
5. Refer to Repair Procedures: Once the problem is identified, navigate to the specific repair procedure in the manual to address it.

Always prioritize safety and consult a qualified mechanic if you are unsure about any repair or diagnosis.

Product Specifications

Important Safety Information

Always wear appropriate personal protective equipment (PPE) when performing maintenance or repairs. Disconnect the battery before working on electrical components. Ensure the motorcycle is stable and secure before lifting or working underneath it. Be aware of hot surfaces and moving parts. This product may contain chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. Always follow local regulations for disposal of fluids and parts.

Manual Cover Image

Image: The front cover of the Clymer Repair Manual, displaying a Harley-Davidson Dyna motorcycle and indicating its coverage for FXD Twin Cam 88 models from 1999 to 2005.
