Introduction
This Clymer repair manual provides comprehensive instructions for the maintenance, troubleshooting, and repair of Honda XL75 motorcycles manufactured between 1977 and 1979. It is designed for both the do-it-yourselfer and experienced mechanics, offering detailed guidance through every procedure.
Each section includes original photographs and illustrations derived from the complete disassembly and assembly of the covered machine, ensuring accuracy and clarity for all repair tasks.
Applicable Models and Years
This manual specifically covers the Honda XL75 motorcycle models produced during the years 1977, 1978, and 1979. For a broader range of models covered by Clymer manuals, please refer to the fitment guide image below.
Image Description: The cover of the Clymer Repair Manual. It features a red Honda motorcycle in a natural setting. The title "CLYMER MANUALS" is prominently displayed at the top, along with "HONDA XL/XR75, XL/XR80 & XL/XR100 • 1975-1991 MAINTENANCE • TROUBLESHOOTING • REPAIR" at the bottom. This image represents the general scope of Clymer manuals for this series.
Image Description: A detailed fitment guide indicating which Honda motorcycle models and years are covered by Clymer manuals. It lists models such as Honda XL100S (1979-1985), Honda XL100 (1975-1978), Honda XR100 (1981-1984), Honda XL80 (1980-1981), Honda XL75 (1977-1979), Honda XR100R (1985-1991), Honda XL80S (1982-1985), Honda XR75 (1975-1978), Honda XR80 (1979-1989), and Honda XR80R (1990-1991).
Manual Contents Overview
This manual is structured to guide users through various aspects of motorcycle care and repair. Key areas covered include:
- Maintenance: Routine service procedures to keep your Honda XL75 in optimal condition.
- Troubleshooting: Diagnostic steps to identify and resolve common issues.
- Repair: Detailed instructions for disassembling, inspecting, repairing, and reassembling components.
- Wiring Diagrams: Color-coded diagrams to assist with electrical system diagnosis and repair.
Using This Manual
To effectively use this manual, it is recommended to:
- Read through the relevant section completely before beginning any procedure.
- Gather all necessary tools and replacement parts beforehand.
- Pay close attention to all safety warnings and precautions.
- Refer to the detailed photographs and illustrations for visual guidance.
Specifications (Manual Product)
| Attribute | Detail |
|---|---|
| Manufacturer | Clymer |
| Item Weight | 1 pound |
| Product Dimensions | 10 x 7 x 0.5 inches |
| ASIN | B079MGVRWK |
| Date First Available | February 6, 2018 |
Important Safety Information
Proposition 65 Warning:
This product may contain chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. Always exercise caution and follow all safety guidelines when performing maintenance or repairs on your vehicle.
Manufacturer Information
This manual is published by Clymer, a reputable provider of automotive and motorcycle repair manuals. For further assistance or inquiries regarding Clymer products, please refer to their official resources.
Manufacturer: Clymer
