1. Introduction
This manual provides essential information for the safe and efficient operation, maintenance, and troubleshooting of your Maxima Planetary Mixer 10L. Please read these instructions thoroughly before using the appliance for the first time and keep this manual for future reference.
The Maxima Planetary Mixer 10L is a versatile kitchen appliance designed for various mixing tasks, including kneading dough, whipping creams, and blending batters. Its robust construction and multiple speed settings make it suitable for both home and professional use.
2. Safety Instructions
Always observe basic safety precautions when using electrical appliances to reduce the risk of fire, electric shock, and personal injury.
2.1 General Safety
- Ensure the mixer is connected to a grounded power outlet with the correct voltage (230 Volts).
- Do not operate the mixer with a damaged cord or plug. If damaged, contact qualified service personnel.
- Keep hands, hair, clothing, and utensils away from moving parts during operation to prevent injury.
- Never insert hands or objects into the mixing bowl while the mixer is operating. The stainless steel protective cage and double safety switch are designed to prevent accidents.
- Unplug the mixer from the power outlet before cleaning, assembling, or disassembling parts.
- Do not immerse the motor unit in water or other liquids.
- This appliance is not intended for use by persons (including children) with reduced physical, sensory, or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
2.2 Operational Safety
- Always ensure the mixing bowl and chosen attachment are securely installed before starting the mixer.
- Do not overload the mixer. Adhere to the maximum dough capacities specified in this manual.
- Use only original Maxima accessories and attachments.
- Place the mixer on a stable, level, and dry surface during operation.
3. Product Overview
The Maxima Planetary Mixer 10L is constructed with durable stainless steel and features a robust design for consistent performance.
3.1 Components
- Main Motor Unit
- 10-Liter Stainless Steel Mixing Bowl
- Dough Hook (for heavy doughs)
- Flat Beater (for batters and medium mixtures)
- Wire Whip (for light mixtures and whipping)
- Protective Safety Cage
- Bowl Lift Lever
- Start/Stop Buttons
- Speed Selector
3.2 Features
- Three Speed Settings: 110, 178, and 390 revolutions per minute (rpm).
- Robust transmission with metal gears for durability.
- Bowl lift mechanism with integrated safety switch.
- Stainless steel protective cage for enhanced safety.
- Separate start and stop buttons for ease of use.
- Scratch-resistant stainless steel housing for easy cleaning.
Figure 1: Front view of the Maxima Planetary Mixer 10L with bowl and safety cage.
Figure 2: Side view of the mixer, showing the bowl in the raised position.
4. Setup
4.1 Unpacking
- Carefully remove the mixer and all accessories from the packaging.
- Inspect the appliance for any signs of damage. If damaged, do not use and contact your supplier.
- Remove all packaging materials, including protective films and stickers.
4.2 Placement
- Place the mixer on a stable, level, and dry surface capable of supporting its weight.
- Ensure adequate clearance around the mixer for ventilation and safe operation.
- Keep the mixer away from heat sources, direct sunlight, and moisture.
4.3 Attaching the Mixing Bowl
- Ensure the bowl lift lever is in the lowered position.
- Align the mixing bowl with the bowl supports and rotate it clockwise until it locks securely into place.
- Use the bowl lift lever to raise the bowl into the operating position. The safety switch will engage.
Figure 3: Front view of the mixer with the mixing bowl in the lowered position, ready for attachment or removal.
4.4 Attaching Accessories
- With the mixer unplugged and the bowl in the lowered position, select the appropriate attachment (dough hook, flat beater, or wire whip).
- Slide the attachment onto the mixer shaft, aligning the pin on the shaft with the groove on the attachment.
- Rotate the attachment upwards until it clicks into place.
- Raise the bowl using the bowl lift lever.
Figure 4: Side view showing an attachment installed and the bowl in position.
5. Operation
5.1 Before First Use
Clean the mixing bowl and all attachments thoroughly with warm, soapy water before their first use. Rinse and dry completely.
5.2 Mixing Process
- Ensure the mixer is properly set up with the bowl and desired attachment.
- Add ingredients to the mixing bowl.
- Plug the mixer into a suitable power outlet.
- Select the desired speed using the speed selector. The available speeds are 110 rpm, 178 rpm, and 390 rpm.
- Press the green START button to begin mixing.
- Monitor the mixing process. If necessary, stop the mixer by pressing the red STOP button to scrape down the sides of the bowl or add more ingredients.
- Once mixing is complete, press the red STOP button.
- Unplug the mixer from the power outlet.
- Lower the mixing bowl using the bowl lift lever and carefully remove the attachment and bowl.
5.3 Recommended Usage
- Dough Hook: Ideal for heavy mixtures such as bread dough and pizza dough. Maximum capacity: 5 kg pizza dough, 3.5 kg bread dough. Minimum recommended bread dough: 1 kg.
- Flat Beater: Suitable for medium-heavy mixtures like cake batters, cookie dough, and mashed potatoes.
- Wire Whip: Best for light mixtures such as whipping cream, egg whites, and light batters.
6. Maintenance and Cleaning
Regular cleaning and maintenance will ensure the longevity and optimal performance of your Maxima Planetary Mixer.
6.1 Daily Cleaning
- Always unplug the mixer before cleaning.
- Remove the mixing bowl and attachment. Wash them immediately after use with warm, soapy water. Rinse thoroughly and dry completely.
- Wipe down the exterior of the mixer with a damp cloth. For stubborn stains, use a mild detergent.
- Ensure all parts are dry before reassembling or storing the mixer.
6.2 Important Cleaning Notes
- The mixing bowl and attachments are not dishwasher safe. Hand wash only.
- Do not use abrasive cleaners, scouring pads, or harsh chemicals, as these can damage the stainless steel finish.
- Never spray water directly onto the motor unit or immerse it in water.
6.3 Storage
Store the mixer in a clean, dry place when not in use. Ensure all components are clean and dry before storage.
7. Troubleshooting
If you encounter issues with your Maxima Planetary Mixer, refer to the following common problems and solutions:
| Problem | Possible Cause | Solution |
|---|---|---|
| Mixer does not start | Not plugged in; Power outage; Safety switch not engaged; Damaged power cord. | Check power connection; Verify power supply; Ensure bowl is raised and locked; Contact service if cord is damaged. |
| Unusual noise during operation | Overload; Improper attachment installation; Internal mechanical issue. | Reduce load; Reinstall attachment correctly; Discontinue use and contact service. |
| Poor mixing results | Incorrect attachment for task; Insufficient or excessive ingredients; Incorrect speed setting. | Use appropriate attachment; Adjust ingredient quantities; Select correct speed. |
| Mixer stops unexpectedly | Overload protection activated; Power interruption. | Reduce load and restart after a cool-down period; Check power supply. |
If the problem persists after attempting these solutions, please contact customer support or a qualified technician.
8. Specifications
Technical details for the Maxima Planetary Mixer 10L:
| Specification | Value |
|---|---|
| Brand | Maxima |
| Model Number | 09300160 |
| Power | 550.00 Watts |
| Voltage | 230 Volts |
| Capacity | 10 Liters (mixing bowl) |
| Number of Speeds | 3 (110, 178, 390 rpm) |
| Material | Stainless Steel |
| Product Dimensions (L x W x H) | 73 x 55 x 50 cm |
| Item Weight | 66 Grams (Note: This value may be a unit error, actual weight for such equipment is typically higher.) |
| Controls Type | Buttons |
9. Warranty and Support
For warranty information, please refer to the documentation provided with your purchase or visit the official Maxima Kitchen Equipment website. Warranty terms and conditions may vary by region and retailer.
If you require technical assistance, spare parts, or have any questions not covered in this manual, please contact Maxima Kitchen Equipment customer support. Contact details can typically be found on the manufacturer's website or your purchase invoice.
