Introduction
This manual provides detailed instructions for the safe and proper installation, operation, and maintenance of the Peerless-AV SmartMount SFP680 Universal Portrait Flat Wall Mount. Please read all instructions carefully before installation to ensure optimal performance and safety.
Important Safety Information
WARNING: Failure to read, understand, and follow all instructions can result in serious personal injury, property damage, or voiding of the warranty. It is the installer's responsibility to ensure all components are properly assembled and installed.
CAUTION: This product is designed to be installed by qualified installation professionals only. If you do not understand these instructions, or have doubts about the safety of the installation, contact a qualified installer or Peerless-AV customer service.
- Verify the mounting surface can safely support the combined weight of the mount and the display.
- Do not exceed the maximum weight capacity of 350 lbs (158.7 kg).
- Use only the mounting hardware provided or specified by Peerless-AV.
- Ensure all fasteners are securely tightened but do not overtighten.
- Keep children and pets away during installation.
Package Contents
Verify that all components are present and undamaged before proceeding with installation.
- Universal Portrait Flat Wall Mount
- Installation Instructions
- Wall and Display Installation Hardware (including M10 fasteners)
- All necessary mounting and display attachment hardware
Image: All components of the Peerless-AV SmartMount SFP680 Universal Portrait Flat Wall Mount, including the wall plate and display adapter rails.
Setup and Installation
Follow these steps for proper installation of your Peerless-AV SmartMount SFP680.
1. Prepare the Wall Plate
The easy-hang wall plate design allows for a bolt to be pre-installed, simplifying the initial wall plate mounting process. Ensure the wall plate is level before securing all fasteners.
Image: The Peerless-AV SmartMount SFP680 wall plate securely mounted to a wall, ready for display attachment.
2. Attach Display Adapter Rails
Attach the display adapter rails to the back of your display using the appropriate M10 fasteners from the included hardware pack. The universal mount fits displays with mounting patterns up to 494 x 650mm (19.45" W x 25.59" H).
Image: A side profile view of the Peerless-AV SmartMount SFP680, highlighting its low-profile design when installed.
3. Mount the Display
Carefully lift the display and hook the adapter rails onto the wall plate. The auto-latching adaptor rails will automatically secure the display without the need for additional tools. The mount's built-in kickstand can hold the display safely from the wall during cable routing and management.
4. Adjustments
The mount allows for both horizontal and vertical display adjustment. Lateral display adjustment is possible up to 3.38" (85.9mm). Additionally, 1" of post-installation vertical adjustment provides flexibility for fine-tuning the display's position.
Operating Instructions
Once installed, the Peerless-AV SmartMount SFP680 is designed for a fixed, flat portrait display. Adjustments for fine-tuning the display's position can be made as described in the "Setup and Installation" section.
- Lateral Adjustment: Slide the display horizontally along the wall plate to achieve the desired centering, up to 3.38 inches (85.9mm) in total.
- Vertical Adjustment: Utilize the 1 inch of post-installation vertical adjustment to fine-tune the display's height.
- Cable Management: The open wall plate design facilitates easy access for routing and managing cables behind the display.
Maintenance
Regular maintenance ensures the longevity and safe operation of your wall mount.
- Periodically check all mounting screws and fasteners to ensure they remain securely tightened.
- Clean the mount with a soft, dry cloth. Avoid abrasive cleaners or solvents.
- Inspect the mount for any signs of wear or damage. If damage is observed, contact Peerless-AV customer service for assistance.
Troubleshooting
If you encounter issues during or after installation, refer to the following common problems and solutions:
- Display is not level:
Ensure the wall plate was installed level. Use the 1 inch of post-installation vertical adjustment to make minor corrections if needed. Re-check wall plate installation if significant leveling issues persist.
- Display feels unstable:
Verify all wall and display fasteners are securely tightened. Ensure the display weight does not exceed the mount's capacity (350 lbs). Confirm the wall structure is adequate to support the load.
- Difficulty attaching display to wall plate:
Ensure the display adapter rails are correctly aligned with the wall plate hooks. The auto-latching mechanism should engage smoothly. Do not force the display; re-align and try again.
Specifications
| Feature | Detail |
|---|---|
| Model Number | SFP680 |
| Brand | Peerless-AV |
| Mounting Type | Wall Mount |
| Movement Type | Fixed (Portrait Flat) |
| Material | Metal (Powder Coated) |
| Color | Black |
| Maximum Weight Capacity | 350 lbs (158.7 kg) |
| Mounting Pattern (Max) | 494 x 650mm (19.45" W x 25.59" H) |
| Profile from Wall | 1.70" (43mm) |
| Lateral Adjustment | Up to 3.38" (85.9mm) |
| Vertical Adjustment (Post-Installation) | 1" |
| Product Dimensions | 32 x 18 x 4 inches (packaging) |
| Item Weight | 16.55 pounds |
| Included Components | Mount, Instructions, Hardware Pack |
| UPC | 735029314202 |
Warranty and Support
For warranty information or technical support, please contact Peerless-AV customer service. Refer to the official Peerless-AV website for the most current warranty terms and contact details.
