EASYmaxx Window Mosquito Net with Magic Click Instruction Manual

1. Introduction

Thank you for choosing the EASYmaxx Window Mosquito Net with Magic Click. This product provides effective protection against mosquitoes, wasps, and other unwanted insects, allowing you to enjoy fresh air indoors without pests. Its innovative magnetic attachment system ensures easy installation without drilling or screwing, and it can be custom-fitted to most standard window sizes.

2. Package Contents

Please check that all items are present in your package:

• 1x Mosquito Net (approx. 130 x 150 cm)
• 12x Magnet Kits (magnetic strips and counter-magnets)

3. Specifications

4. Setup and Installation

Follow these steps for a quick and easy installation of your EASYmaxx mosquito net:

1. Prepare Your Window: Ensure the window frame is clean, dry, and free of dust or grease. The magnetic system is compatible with PVC, wood, and aluminum frames. Your window frame should have a minimum width of 9mm for proper attachment.

This image shows compatible window frame materials (PVC, wood, aluminum) and indicates a minimum frame width of 9mm required for installation.
2. Measure and Cut the Net: Hold the mosquito net against your window frame and measure the desired size. Using scissors, carefully cut the net to fit your window opening, leaving a small overlap for the magnetic strips.


The mosquito net can be easily trimmed with scissors to perfectly match the dimensions of your window frame, ensuring a custom fit.

3. Attach Magnetic Strips to the Frame: Peel the protective film from one side of the adhesive magnetic strips. Carefully apply these strips to the clean, dry window frame, ensuring they are evenly spaced around the perimeter where the net will attach. Press firmly for good adhesion.
4. Attach Counter-Magnets to the Net: Take the counter-magnets (the smaller, non-adhesive parts) and place them onto the magnetic strips already on the window frame. Then, align the cut mosquito net over the window opening. Carefully press the net onto the exposed adhesive side of the counter-magnets. This ensures perfect alignment.

This image illustrates the simple 'Magic Click' magnetic attachment system. The net is easily secured to the window frame using the provided magnetic clips, requiring no drilling or screws.
5. Secure the Net: Once the net is attached to the counter-magnets, gently pull the net away from the frame. The counter-magnets should now be firmly attached to the net. Re-attach the net to the magnetic strips on the frame. The 'Magic Click' system will hold it securely in place.


This image highlights the 'EASY-KLICK' magnetic system, demonstrating how the net clicks into place for a strong and secure hold without permanent fixtures.



A visual guide to the quick and easy installation process: unpack the components, cut the net to size, attach the magnets, and enjoy your insect-free window.

5. Operating Instructions

The EASYmaxx mosquito net is designed for convenience and effective insect protection:

• Insect Protection: The fine mesh effectively blocks mosquitoes, wasps, flies, and other insects from entering your home, while allowing fresh air to circulate.


The fine mesh of the EASYmaxx mosquito net effectively keeps out a variety of insects, including mosquitoes, wasps, and spiders, ensuring a pest-free indoor environment.

• Clear View and Airflow: The semi-transparent black material ensures a clear view outside and maintains good airflow, preventing your room from feeling stuffy.

The EASYmaxx net offers superior transparency and reliable airflow compared to standard fabrics, allowing fresh air in while maintaining a clear view outside.
• Window Operation: You can still open and close your window completely with the mosquito net installed. The magnetic attachment allows for easy temporary removal if needed, for example, to water plants or clean the window.

6. Maintenance

To ensure the longevity and effectiveness of your mosquito net:

• Cleaning: The net can be easily cleaned. Gently wash it with water and a mild detergent if necessary. Allow it to air dry completely before re-installing.
• Seasonal Storage: At the end of the insect season, the net can be easily detached from the magnets without leaving residue. The magnetic strips can also be removed from the window frame without leaving adhesive marks. Store the net in a clean, dry place until next use.

7. Troubleshooting

• Net not staying attached:
  • Ensure the window frame surface was clean and dry before applying the magnetic strips.
  • Press the adhesive strips firmly onto the frame for optimal adhesion.
  • Verify that all 12 magnet kits are used and evenly distributed around the net's perimeter.
  • In very hot weather, adhesive strength can be affected. Ensure the adhesive has fully cured before exposing to extreme temperatures.
  • Strong winds might dislodge the net if not properly secured or if the adhesive has weakened. Re-apply or reinforce if necessary.
• Window not closing properly:
  • Ensure the mosquito net and its magnetic attachments do not obstruct the window's closing mechanism. Trim any excess net material that might interfere.
  • The thickness of the magnetic attachments should not prevent the window from closing. If this occurs, consider adjusting the placement of the magnets or the net.

8. Warranty

Warranty information for the EASYmaxx Window Mosquito Net with Magic Click is not available in the provided product details. Please refer to your purchase receipt or the retailer's website for specific warranty terms and conditions.

9. Support

Customer support contact information for the EASYmaxx Window Mosquito Net with Magic Click is not available in the provided product details. For assistance, please contact the retailer from whom you purchased the product or visit the official EASYmaxx website.
