RCA RCD-108

RCA RCD-108 Bluetooth Portable Audio System User Manual

Model: RCD-108

Introduction

Thank you for purchasing the RCA RCD-108 Bluetooth Portable Audio System. This manual provides essential information for the safe and efficient operation of your device. Please read it thoroughly before use and retain it for future reference.

Safety Information

  • Power Source: Ensure the power source matches the voltage requirements specified on the unit.
  • Water and Moisture: Do not expose the unit to rain, moisture, or dripping/splashing liquids.
  • Ventilation: Do not block ventilation openings. Ensure adequate space around the unit for proper airflow.
  • Heat: Keep the unit away from heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
  • Cleaning: Unplug the unit from the wall outlet before cleaning. Use a soft, dry cloth only.
  • Servicing: Do not attempt to service this product yourself. Refer all servicing to qualified service personnel.

Product Features

  • Portable Bluetooth Audio System
  • CD/MP3/USB Playback
  • FM Radio Tuner
  • 3.5 mm Auxiliary Input
  • 2.5 W RMS x 2 Output Power

Package Contents

  • RCA RCD-108 Portable Audio System
  • AC Power Cord
  • User Manual (this document)

Setup

Powering the Unit

The RCD-108 can be powered by AC power or batteries.

AC Power

  1. Connect the supplied AC power cord to the AC IN jack on the unit.
  2. Plug the other end of the AC power cord into a standard wall outlet.

Battery Power

  1. Open the battery compartment cover located on the bottom of the unit.
  2. Insert the required number of batteries (type not specified, typically D-cell) according to the polarity markings (+/-) inside the compartment.
  3. Close the battery compartment cover securely.

Initial Power On

Press the POWER button to turn the unit on. The display will illuminate.

Operating Instructions

Controls Overview

The following image illustrates the main controls on your RCA RCD-108 unit:

Top view of the RCA RCD-108 Portable Audio System with CD lid open, showing control buttons and ports.

Image: Top view of the RCA RCD-108 Portable Audio System. The CD compartment lid is open, revealing the disc tray and a protective cardboard insert. Below the CD compartment are the main control buttons and ports. From left to right, top row: POWER button, USB JACK, FUNCTION button, TIME/PROG button. Middle row: VOLUME knob, NEXT button, BACK button, display screen, P-DN button, REP button, P-UP button. Bottom row: STANDBY indicator, STOP button, PLAY/PAUSE button. On the front-left side is a PHONES jack, and on the front-right side is an AUX IN jack.

  • POWER: Press to turn the unit on or off.
  • VOLUME: Rotate to adjust the sound output level.
  • FUNCTION: Press repeatedly to cycle through input sources: CD, USB, FM, Bluetooth, AUX.
  • NEXT (►►|): Skips to the next track/station.
  • BACK (◄◄): Skips to the previous track/station.
  • STOP (■): Stops playback of CD or USB media.
  • PLAY/PAUSE (►||): Starts or pauses playback of CD or USB media.
  • TIME/PROG: Used for programming CD/USB tracks or setting time (if applicable).
  • P-DN / P-UP: Used for navigating programmed tracks or preset radio stations.
  • REP: Activates the repeat playback function for CD or USB media.
  • USB JACK: Port for connecting a USB flash drive for MP3 playback.
  • PHONES: 3.5mm jack for connecting headphones.
  • AUX IN: 3.5mm jack for connecting external audio devices.

CD/MP3 Playback

  1. Open the CD compartment lid.
  2. Carefully place a CD or MP3 CD onto the spindle, label side up.
  3. Close the CD compartment lid.
  4. Press the FUNCTION button until 'CD' appears on the display.
  5. Press the PLAY/PAUSE button to begin playback.
  6. Use NEXT or BACK to skip tracks.
  7. Press STOP to end playback.

USB Playback

  1. Insert a USB flash drive into the USB JACK.
  2. Press the FUNCTION button until 'USB' appears on the display.
  3. The unit will automatically begin playing MP3 files from the USB drive.
  4. Use NEXT or BACK to skip tracks.
  5. Press STOP to end playback.

FM Radio Operation

  1. Press the FUNCTION button until 'FM' appears on the display.
  2. Press and hold NEXT or BACK to automatically scan for the next available station.
  3. Press NEXT or BACK briefly to manually tune the frequency step by step.
  4. Use P-DN or P-UP to navigate through preset stations (if programmed).

Bluetooth Operation

  1. Press the FUNCTION button until 'BT' or 'Bluetooth' appears on the display. The unit will enter pairing mode, indicated by a flashing Bluetooth icon or message.
  2. Enable Bluetooth on your mobile device (smartphone, tablet, etc.) and search for available devices.
  3. Select 'RCA RCD-108' from the list of found devices.
  4. Once paired, the unit will confirm the connection, and you can begin playing audio from your device.
  5. Control playback (play/pause, next/back) either from your connected device or using the unit's controls.

Auxiliary Input

  1. Connect an external audio device (e.g., MP3 player, smartphone) to the AUX IN jack using a 3.5mm audio cable (not supplied).
  2. Press the FUNCTION button until 'AUX' appears on the display.
  3. Start playback on your external device. The audio will be routed through the RCD-108 speakers.
  4. Adjust the volume using the VOLUME knob on the unit or the volume control on your external device.

Headphone Use

To listen privately, plug standard 3.5mm headphones into the PHONES jack. The speakers will automatically mute.

Maintenance

Cleaning the Unit

Wipe the exterior of the unit with a soft, dry cloth. Do not use abrasive cleaners, waxes, or solvents as they may damage the finish. Ensure the unit is unplugged before cleaning.

Disc Care

Handle discs by their edges. Keep discs clean and free of scratches. Store discs in their cases when not in use.

Battery Care

Remove batteries if the unit will not be used for an extended period to prevent leakage and corrosion.

Troubleshooting

ProblemPossible CauseSolution
No powerAC cord not connected; Batteries depleted or incorrectly inserted.Check AC cord connection; Replace batteries or ensure correct polarity.
No soundVolume too low; Incorrect function selected; Headphones connected.Increase volume; Press FUNCTION to select correct source; Disconnect headphones.
CD/USB not playingDisc/USB dirty or scratched; Incorrect format; CD lid not closed.Clean disc/USB; Ensure files are MP3 format; Close CD lid securely.
Bluetooth not pairingUnit not in pairing mode; Device too far; Bluetooth off on external device.Ensure unit is in BT function and flashing; Move device closer; Enable Bluetooth on your device.
FM radio staticWeak signal; Antenna not extended.Adjust unit position; Fully extend the telescopic antenna.

Specifications

  • Brand: RCA
  • Model: RCD-108
  • Color: Black
  • Dimensions (L x W x H): 35 x 14 x 26 cm (13.8 x 5.5 x 10.2 inches)
  • Weight: 1.8 Kilograms (3.97 lbs)
  • Power Output: 2.5 Watts RMS x 2
  • Power Source: AC Power / Battery (Batteries not included)
  • Compatible Devices: MP3 Player (via AUX/USB)
  • UPC: 044476126567
  • ASIN: B01DC4VQA8

Warranty and Support

Warranty Information

This RCA product is covered by a 1-year limited warranty from the date of original purchase. This warranty covers manufacturing defects in materials and workmanship under normal use.

Customer Support

For technical assistance, warranty claims, or product inquiries, please refer to the contact information provided with your purchase documentation or visit the official RCA support website.

© 2024 RCA. All rights reserved.
