Maxell SR626SW 377 1.55V Silver Oxide Watch Battery Instruction Manual

1. Product Overview

The Maxell SR626SW 377 is a 1.55V silver oxide button cell battery designed for reliable power in various small electronic devices. Maxell is a pioneer in button-type silver oxide batteries, ensuring quality and performance. This battery is engineered with a focus on environmental responsibility, featuring a 0% mercury composition.

Image: Maxell SR626SW 377 1.55V Silver Oxide Button Cell Watch Battery in its original blister packaging.

Key Features:

• Model: SR626SW (also known as 377)
• Voltage: 1.55V Nominal
• Chemistry: Silver Oxide
• Mercury Content: 0% Mercury
• Design: Leakage Resistance Design for enhanced reliability.
• Energy Density: Lightweight with high-energy density.
• Discharge: Stable discharge characteristics.

Image: Visual representation of Maxell SR626SW battery features, highlighting 100% leakage resistance, low-drain type, and mercury-free composition.

Recommended Applications:

These batteries are commonly used as a power source for a variety of small electronic devices requiring a compact and stable power supply.

• Quartz Watches
• Medical Devices
• Keyless Remote Entry Systems
• Calculators
• Cameras

Image: Maxell silver oxide batteries shown in context with a blood glucose monitor and a watch, illustrating their use in medical devices and watches.

2. Installation Instructions

Follow these steps carefully when replacing or installing a new battery in your device. Always refer to your device's specific instruction manual for detailed battery replacement procedures.

1. Prepare Your Workspace: Ensure you have a clean, dry, and well-lit area. Use non-metallic tweezers to handle the battery to avoid short-circuiting or damaging the battery.
2. Open Device Battery Compartment: Carefully open the battery compartment of your watch or electronic device. This often requires a small screwdriver or a specialized tool.
3. Remove Old Battery (if applicable): If replacing an old battery, gently remove it. Note its orientation (positive (+) and negative (-) terminals) before removal.
4. Clean Contacts: Lightly wipe the battery contacts in the device with a dry, clean cloth to ensure good electrical connection.
5. Insert New Battery: Insert the new Maxell SR626SW battery with the correct polarity. The positive (+) side is usually marked on the battery and should align with the positive terminal in the device.
6. Secure Compartment: Close the battery compartment securely.
7. Test Device: Verify that your device is functioning correctly.

Important: Do not force the battery into the compartment. If it does not fit easily, recheck the battery size and orientation.

3. Operation

Once correctly installed, the Maxell SR626SW battery will provide consistent and stable power to your compatible electronic device. These silver oxide batteries are known for their stable discharge voltage, which is crucial for devices requiring precise power delivery, such as watches.

4. Care and Storage

• Storage: Store unused batteries in their original packaging in a cool, dry place, away from direct sunlight and extreme temperatures. Avoid storing batteries loosely or with metal objects, which can cause short circuits.
• Handling: Handle batteries with clean, dry hands. Avoid touching the battery terminals with bare fingers, as oils from the skin can affect conductivity.
• Disposal: Dispose of used batteries according to local regulations. Do not throw batteries into fire or incinerate them. Many communities offer battery recycling programs.
• Avoid Damage: Do not puncture, deform, or disassemble the battery.

5. Troubleshooting

If your device is not functioning after battery installation, consider the following:

• Incorrect Polarity: Ensure the battery is inserted with the correct positive (+) and negative (-) orientation.
• Poor Contact: Check if the battery is seated properly and making firm contact with the device's terminals. Clean contacts if necessary.
• Device Malfunction: If the battery is correctly installed and the device still does not work, the issue may lie with the device itself, not the battery.
• Battery Condition: Although new, ensure the battery is not damaged or depleted.

6. Technical Specifications

7. Important Safety Information

Please read and follow these safety precautions to prevent injury or damage:

• Keep Away From Children: Button cell batteries can be swallowed and cause serious injury or death. Keep new and used batteries out of reach of children. If swallowed, seek immediate medical attention.
• Do Not Recharge: These batteries are not rechargeable. Attempting to recharge them may cause leakage, fire, or explosion.
• Do Not Disassemble: Do not open, puncture, or modify the battery.
• Avoid Short Circuits: Do not allow metal objects to contact both terminals of the battery simultaneously.
• Extreme Temperatures: Do not expose batteries to excessive heat (e.g., fire, direct sunlight) or extreme cold.
• Proper Disposal: Dispose of used batteries promptly and responsibly according to local regulations.
• Leakage: If battery leakage occurs, avoid contact with skin and eyes. If contact occurs, flush with water immediately and seek medical attention.

8. Warranty and Support

Maxell batteries are manufactured to high-quality standards. For specific warranty information or technical support regarding your Maxell SR626SW batteries, please refer to the official Maxell website or contact Maxell customer service directly. Keep your purchase receipt as proof of purchase.

You can typically find contact information for Maxell on their official brand website or through the retailer where the product was purchased.
