1. Introduction
The Rossmax NA100 Piston Nebulizer is a medical device designed to efficiently deliver prescribed medication to the bronchial passages and lungs. It converts liquid medication into a fine mist, allowing for easy inhalation. This device is suitable for the treatment of various respiratory conditions in children, adolescents, and adults.
Please read this instruction manual thoroughly before using the device for the first time. Keep this manual for future reference.
2. Important Safety Information
- Always read and understand all instructions before operating the nebulizer.
- This device is intended for use with prescribed medication only. Consult your physician or pharmacist for proper medication and dosage.
- Do not immerse the compressor unit in water or any other liquid.
- Keep the device out of reach of children and pets.
- Unplug the device from the electrical outlet immediately after use and before cleaning.
- Do not operate the device if it has a damaged cord or plug, if it is not working properly, or if it has been dropped or damaged.
- Ensure proper ventilation during operation to prevent overheating.
- Use only original Rossmax accessories and replacement parts.
3. Package Contents
Carefully unpack the box and ensure all the following items are present:
- Rossmax NA100 Compressor Unit
- Nebulizer Cup
- Air Tube
- Adult Mask
- Child Mask
- Mouthpiece
- Pacifier for Babies
- Power Adapter
- Instruction Manual (this document)
4. Product Overview
The Rossmax NA100 Piston Nebulizer is a compact and efficient system for aerosol therapy. Below is an image illustrating the main components of the device.
Image of the Rossmax NA100 Piston Nebulizer with its lid open, showing the compressor unit, nebulizer cup, mouthpiece, and air tube connected.
The main unit houses the piston compressor. The nebulizer cup is where the liquid medication is placed and converted into mist. The air tube connects the compressor to the nebulizer cup, delivering compressed air for nebulization. Various accessories are provided for different user needs.
5. Setup
Follow these steps to set up your Rossmax NA100 Nebulizer for use:
- Place the compressor unit on a clean, stable, and flat surface, ensuring it is within reach of an electrical outlet.
- Ensure the power switch on the compressor unit is in the 'OFF' (O) position.
- Connect one end of the air tube to the air outlet connector on the compressor unit.
- Open the nebulizer cup by twisting its top counter-clockwise.
- Pour the prescribed amount of medication into the nebulizer cup. Do not overfill. The maximum capacity is 5 ml.
- Securely close the nebulizer cup by twisting its top clockwise until it clicks into place.
- Connect the other end of the air tube to the air inlet on the bottom of the nebulizer cup.
- Attach the desired accessory (mouthpiece, adult mask, child mask, or pacifier) to the top of the nebulizer cup.
- Plug the power adapter into a suitable electrical outlet.
Image showing a close-up of the Rossmax nebulizer cup with the mouthpiece attached, ready for use.
6. Operating Instructions
Once the nebulizer is set up, follow these steps for treatment:
- Sit in an upright, comfortable position.
- If using the mouthpiece, place it between your teeth and seal your lips around it. If using a mask, place it securely over your nose and mouth. For infants, ensure the pacifier is properly positioned.
- Press the power switch to the 'ON' (I) position. The compressor will start, and a fine mist will begin to emerge from the nebulizer cup.
- Breathe normally and deeply through the mouthpiece or mask. Continue breathing until the medication is fully nebulized, which typically takes 5 to 15 minutes, or until no more mist is produced.
- Once the treatment is complete, press the power switch to the 'OFF' (O) position and unplug the device from the electrical outlet.
7. Cleaning and Maintenance
Regular cleaning and maintenance are crucial for the proper functioning and longevity of your nebulizer. Always clean the device after each use.
Daily Cleaning (After Each Use)
- Disconnect the nebulizer cup, mouthpiece/mask, and air tube from the compressor unit.
- Disassemble the nebulizer cup into its individual components.
- Wash all components (nebulizer cup parts, mouthpiece, masks, pacifier) with warm water and a mild detergent.
- Rinse thoroughly with clean water to remove all soap residue.
- Air dry all components completely on a clean paper towel or cloth. Do not use a towel to dry, as lint may clog the parts.
- The air tube should not be washed. If moisture is present inside the tube, run the compressor with the tube attached for a few minutes to dry it out.
Disinfection (Weekly or as Recommended)
- After daily cleaning, disinfect the nebulizer cup, mouthpiece, masks, and pacifier by soaking them in a solution of one part white vinegar to three parts distilled water for 30 minutes. Alternatively, use a medical disinfectant solution as per its manufacturer's instructions.
- Rinse all components thoroughly with sterile water.
- Air dry completely on a clean, lint-free surface.
Compressor Unit Care
- Wipe the exterior of the compressor unit with a clean, damp cloth. Do not use abrasive cleaners or submerge the unit in water.
- Regularly check the air filter. Replace it if it appears dirty, discolored, or after approximately 30 hours of use, or as recommended by your healthcare provider.
8. Troubleshooting
If you encounter issues with your Rossmax NA100 Nebulizer, refer to the following common problems and solutions:
| Problem | Possible Cause | Solution |
|---|---|---|
| No mist production | Power cord not plugged in; Power switch OFF; Air tube disconnected or kinked; Nebulizer cup clogged or improperly assembled; No medication in cup. | Ensure power cord is securely plugged in; Turn power switch ON; Check air tube connections and ensure no kinks; Disassemble and clean nebulizer cup, then reassemble correctly; Add prescribed medication. |
| Weak mist production | Air tube partially blocked or kinked; Nebulizer cup components dirty or worn; Air filter dirty. | Check air tube for blockages or kinks; Clean nebulizer cup components thoroughly; Replace air filter. |
| Unusual noise from compressor | Unit not on a stable surface; Internal component issue. | Place unit on a flat, stable surface; If noise persists and is excessive, contact customer support. |
If the problem persists after attempting these solutions, please contact Rossmax customer support or your authorized dealer.
9. Specifications
| Feature | Specification |
|---|---|
| Model Number | NEB100 |
| Power Supply | AC 230 V / 50 Hz or AC 220 V / 60 Hz |
| Operating Pressure Range | >0.10 MPa (15 psi) |
| Air Flow | >3.5 Liters/min |
| Medication Capacity | 5 ml (cc) |
| Particle Size (MMAD) | 0.5 to 10 µm (85%) |
| MMAD (0.9% Saline) | 0.4 ml/min |
| Dimensions (L x W x H) | 280 mm x 190 mm x 100 mm |
| Weight (without accessories) | 1.8 Kg |
| Operating Humidity | 10-90% RH |
| Storage Temperature | -20°C to 60°C (-4°F to 140°F) |
| Storage Humidity | 10-90% RH |
10. Warranty and Support
The Rossmax NA100 Piston Nebulizer is backed by a 3-year warranty from the date of purchase, ensuring quality and reliability.
Image of the Rossmax NA100 Nebulizer packaging, prominently displaying a '3 Year Warranty' badge.
For warranty claims, technical support, or to inquire about replacement parts, please contact Rossmax customer service or your authorized dealer. Please retain your purchase receipt as proof of purchase for warranty validation.
Manufacturer: Rossmax
