Schonbek Refrax RE4821S Pendant Light Instruction Manual

Important Safety Information

Please read and understand all instructions before beginning installation. Failure to follow these instructions may result in electric shock, fire, or other hazards that can cause property damage, personal injury, or death.

• Electrical Safety: Always disconnect power at the main circuit breaker before installing, servicing, or cleaning this fixture. Ensure all electrical connections comply with local codes and ordinances. If you are unsure about wiring, consult a qualified electrician.
• Fixture Weight: This fixture is heavy (approximately 44 pounds). Ensure the mounting surface and electrical box can safely support the weight of the fixture. Professional installation is recommended.
• Bulb Requirements: Use only the specified bulb types and wattages: 7 x GU10 base, MR16 shape, 120V, 50W max; and 14 x G9 base, T4 shape, 120V, 40W max. Do not exceed maximum wattage.
• Indoor Use Only: This fixture is rated for indoor locations only. Do not install in damp or wet environments.
• Handling Crystals: Handle crystal components with care to avoid chipping or breakage. Wear gloves to prevent fingerprints.

Package Contents

Verify that all components are present before beginning installation:

• Lighting Fixture
• Mounting Hardware
• Instruction Sheets
• Manufacturer Warranty Certificate
• Certificate of Authenticity

Product Overview

The Schonbek Refrax RE4821S is a 14-light pendant fixture featuring a polished stainless steel frame and clear Swarovski crystals. It is designed for indoor use and provides adjustable lighting. The fixture measures 48 inches in length, 21 inches in width, and 12.5 inches in height, with a total weight of 44 pounds.

Setup and Installation

Professional installation is recommended for this fixture due to its weight and electrical requirements.

1. Prepare for Installation: Turn off power at the main circuit breaker. Ensure the mounting location is structurally sound and can support the fixture's weight (44 lbs).
2. Mounting to Electrical Box: Attach the provided mounting hardware to a standard electrical box. Ensure the electrical box is securely fastened to the building structure.
3. Adjusting Suspension: The fixture is suspended by adjustable aircraft cables from the canopy. Adjust the cable length using the cable gripper located above the frame to achieve the desired hanging height. The fixture includes 10ft of wire for a maximum suspension up to 10ft. Additional chain is sold separately if needed. This fixture can be installed on a slope ceiling up to a 45-degree angle.
4. Electrical Connections: Connect the fixture's electrical wires to the household wiring according to local electrical codes. Typically, this involves connecting the black wire to the hot wire, the white wire to the neutral wire, and the ground wire to the ground wire. Secure connections with wire nuts.
5. Install Light Bulbs: This fixture requires 7 x GU10 base, MR16 shape 120V light bulbs (50W max) and 14 x G9 base, T4 shape 120V light bulbs (40W max). These bulbs are sold separately. Carefully insert the bulbs into their respective sockets. Do not overtighten.
6. Secure Canopy: Once wiring and suspension adjustments are complete, secure the canopy to the mounting hardware, covering the electrical box.

Operating Instructions

After installation is complete and power is restored:

• Power On/Off: Operate the fixture using a standard wall switch connected to the electrical circuit.
• Dimming: The fixture supports smooth and continuous dimming when used with a compatible dimmer switch (sold separately). Ensure the dimmer switch is rated for the total wattage of the installed bulbs.

Maintenance

Regular cleaning will help maintain the appearance and performance of your Schonbek Refrax pendant light.

• Cleaning Crystals: Turn off the power to the fixture and allow it to cool. Gently wipe crystals with a soft, lint-free cloth dampened with a mild glass cleaner or distilled water. Avoid abrasive cleaners or harsh chemicals.
• Cleaning Metal Frame: For the polished stainless steel frame, use a soft, dry cloth. For stubborn spots, a slightly damp cloth with mild soap and water can be used, followed by immediate drying. Avoid abrasive materials that could scratch the finish.
• Bulb Replacement: Ensure power is off and bulbs are cool before attempting to replace them. Follow the bulb type and wattage specifications outlined in the 'Setup and Installation' section.

Troubleshooting

If you encounter issues with your fixture, refer to the following common problems and solutions:

• Light Does Not Turn On:
  • Check if the circuit breaker is tripped.
  • Ensure all electrical connections are secure.
  • Verify that bulbs are correctly installed and not burnt out.
• Lights Flicker or Dim Incorrectly:
  • Confirm that the dimmer switch is compatible with LED or incandescent bulbs, depending on what is installed.
  • Check for loose wiring connections.
• Fixture is Loose:
  • Ensure mounting hardware and canopy screws are tightened securely.
  • Verify the electrical box is firmly attached to the ceiling structure.

If problems persist, contact a qualified electrician or Schonbek customer support.

Specifications

Warranty Information

This Schonbek fixture is covered by a 5-year manufacturer's warranty. Please refer to the included Manufacturer Warranty Certificate for full terms and conditions regarding coverage and claims.

Customer Support

For technical assistance, replacement parts, or warranty claims, please contact Schonbek customer support. Refer to the contact information provided in your product packaging or visit the official Schonbek website for current support details.
