Dimplex BF Series 4-Piece Trim Kit Instruction Manual

1. Introduction

This manual provides essential information for the proper installation, operation, and maintenance of your Dimplex BF Series 4-Piece Trim Kit, Model BF4TRIM39. This trim kit is designed to complement and frame the Dimplex BF39DXP electric firebox, providing a finished appearance for your fireplace installation.

2. Safety Information

Please read and understand all instructions before installing or using this product. Failure to follow these instructions may result in property damage or injury.

• Ensure the electric firebox is turned off and disconnected from power before installation.
• Handle all components with care to prevent scratches or damage.
• Keep small parts away from children.
• This trim kit is for decorative framing purposes only and does not affect the electrical or heating functions of the firebox.

3. Package Contents

Verify that all components are present before beginning installation:

• Four (4) metal trim pieces (two long, two short)
• Mounting hardware (screws)

Figure 1: All four pieces of the Dimplex BF Series Trim Kit.

4. Installation

This trim kit is designed for use with the Dimplex BF39DXP firebox. It can be installed to provide a finished look whether the firebox is installed with or without a mantle.

4.1. Preparing for Installation

1. Ensure the firebox is securely installed in its desired location.
2. Clean the area around the firebox opening to ensure a smooth surface for the trim.

4.2. Attaching the Trim Pieces

1. Identify the top, bottom, and side trim pieces. The longer pieces are typically for the horizontal sections (top and bottom), and the shorter pieces for the vertical sides.
2. Align the first trim piece with the edge of the firebox opening.
3. Using the provided mounting hardware, secure the trim piece to the firebox flange or surrounding structure. Ensure the screws are tightened sufficiently to hold the trim firmly in place without overtightening.
4. Repeat the process for the remaining three trim pieces, ensuring they meet at the corners to form a continuous frame.
5. Verify that all trim pieces are flush and securely attached.

Figure 2: The 4-piece trim kit installed around a firebox.

4.3. Visual Guide to Trim Kit Installation

5. Operation

The Dimplex BF Series 4-Piece Trim Kit is a passive accessory and does not require any operational steps. Once installed, it serves to aesthetically frame your electric firebox. Refer to your Dimplex BF39DXP firebox manual for its specific operating instructions.

6. Maintenance

To maintain the appearance of your trim kit:

• Wipe surfaces with a soft, damp cloth.
• Avoid using abrasive cleaners or solvents, as these may damage the finish.
• Regularly check the mounting screws for tightness and re-tighten if necessary.

7. Troubleshooting

Issues related to the trim kit are typically minor and can be resolved with simple adjustments:

• Loose Trim: If a trim piece becomes loose, re-tighten the mounting screws.
• Scratches/Dents: Minor imperfections can sometimes be touched up with a suitable black metal paint. For significant damage, replacement of the affected piece may be necessary.
• Uneven Gaps: Ensure the firebox is installed squarely and the trim pieces are aligned correctly before tightening. Adjust as needed.

For issues related to the electric firebox itself, consult the firebox's instruction manual or contact Dimplex customer support.

8. Specifications

Figure 3: Dimensional diagram of the trim kit.

9. Warranty and Support

This Dimplex BF Series 4-Piece Trim Kit comes with a 1-year limited warranty. For warranty claims or technical support, please contact Dimplex customer service. Keep your proof of purchase for warranty validation.

For further assistance, visit the official Dimplex website or contact their customer support line.
