ANCEL BD200 Bluetooth 5.0 Scanner Code Reader and App

DOWNLOAD APP

1. Scan the QR code below to download the software for Android and iOS.
2. iOS can be downloaded from the App Store by searching for the keyword ” ANCEL “.
3. Android can be downloaded from Google Play by searching for the keyword “ANCEL”.

OBD INTERFACE POSITIONS
For different vehicles, the position of the DLC may be different, please refer to the following possible positions:

OPERATION DIAGRAM

BLUETOOTH CONNECTION

Turn on Bluetooth -Start the app -Automatic device connection-Connected.
Image 1 is not connected, image 2 is connected.

START USING YOUR DEVICE

After Bluetooth connection, the diagnostic software will be launched if your vehicle supports it. You can use all functions of the device, e.g. the standard OBDII function and other functions.

FEEDBACK

You can send us feedback if you encounter any problems while using it. To do so, fill out and submit the feedback form.

SOFTWARE UPGRADE AND FIRMWARE UPGRADE

1. B0200-APP Software Upgrade:
   Delete the program APP directly, and then download the latest software again.(View the latest software version: Open app—settings–about us).
2. 8D200-APP Firmware update:
   1. Open the app-settings–device-settings–firmware-up­grade-currently the latest version •-(no update required).
   2. Open the app-settings–device-settings–firmware-up­ grade–current version and ask for the latest version—- click the menu button ‘Upgrade’– firmware upgrade is successful (update required).

Product parameters

• Operating voltage: DC8-18V
• Operating current: <24mA@DC12V
• Bluetooth frequency: 2.4GHz
• Bluetooth version: Bluetooth 5.0
• Dimensions: 77mmx23mmx4 7mm
• Weight: NW: 0.04kg (0.088Ib)
• Working temperature: -30t:-70t: (-221 ~1581)
• Storage temperature: -40″C-85t: (-401~1851)

Warranty

1. This warranty is limited to the person purchasing ANCEL products.
2. ANCEL products are warranted against defects in materials and workmanship for a period of one year (12 months) from the date of shipment to the user.
