User Guide
51381CR Display Module
ABB-Welcome IP
5138 CR
http://new.abb.com/products/ABB2TMA130160N0010
- Go to the online webpage by scanning the QR code.
- Click on the “Downloads” tab to find the documents.
Service
Find your individual country contact here.
http://new.abb.com/contact-centers
Display module
Connection
| 1 | Program button |
| 2 | Connector for previous module |
| 3 | Connector for device software update |
| 4 | Connector for Wiegand output It supports 26 bits and 34 bits |
| 5 | Connector for next module |
Technical data
| Rating voltage | 24 V ⎓ |
| Operating voltage range | 20-27 V ⎓ |
| Rating current | 27 V ⎓, 145 mA 24 V ⎓, 160 mA |
| Operating temperature | -40 °C…+55 °C |
| Frequency range (ID) | 125KHz |
| Maximum power (ID) | ≤-3.19 dBμA/m @ 3m |
| Frequency range (IC) | 13.56MHz |
| Maximum power (IC) | ≤-4.75 dBμA/m @ 3m |
FCC ID: 2AEBL-51381CR
FCC ID: 2AEBL-51382CR
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules.
The complete of FCC information is available at the package shipped with the product.
EU declaration of conformity (simplified)
ABB Xiamen Smart Technology Co., Ltd., herewith declares that Display module, 51381CR and 51382CR conform to directive 2014/53/EU.
The complete of the EU declaration of conformity is available by scanning the QR code.
