ABKO EC10 Active Noise Cancelling True Wireless Earbuds User Manual

Isingeniso

The ABKO EC10 Active Noise Cancelling True Wireless Earbuds are designed to provide an immersive audio experience with advanced noise cancellation and clear communication features. This manual provides detailed instructions for setup, operation, maintenance, and troubleshooting to ensure optimal performance of your earbuds.

Yini EseBhokisini

• 1 x EC10 Earbud Set (Left and Right)
• 1 x USB-C Type Charging Cable
• 4 x Ear Tips (various sizes)
• 1 x Incwadi Yomsebenzisi (le dokhumenti)

Image: The ABKO EC10 earbuds shown inside their charging case, with the USB-C charging cable and extra ear tips.

Setha

1. Ukushaja ama-Earbud nekesi

Before first use, fully charge the earbuds and the charging case. The case supports both USB-C wired charging and wireless charging.

• Ukushaja Ngezintambo: Connect the provided USB-C cable to the charging port on the case and to a USB power source.
• Ukushaja okungenantambo: Beka ikesi lokushaja kuphedi yokushaja okungenantambo ehambisanayo.

The charging time for both the cradle and earbuds is approximately 1.5 hours.

Image: The ABKO EC10 charging case placed on a wireless charging pad, illustrating its wireless charging capability.

2. Ukumatanisa Nedivayisi Yakho

The EC10 earbuds feature fast auto-pairing for convenience.

1. Qinisekisa ukuthi i-Bluetooth yedivayisi yakho ivuliwe.
2. Vula ikesi lokushaja. Ama-earbud azongena ngokuzenzakalelayo kumodi yokumatanisa.
3. On your device, search for Bluetooth devices and select "ABKO EC10" from the list.
4. Uma usuxhunyiwe, uzozwa isiqinisekiso esizwakalayo.

The earbuds use Bluetooth Version 5.0 and have an operation distance of up to 10 meters.

Video: An official product video demonstrating the features and usage of the ABKO Wireless ANC Earbuds EC10, including pairing and various modes.

Isebenzisa ama-Earbuds

Ukukhanselwa Kwemisindo Esebenzayo (ANC)

The EC10 earbuds feature Active Noise Cancellation (ANC) technology, which analyzes surrounding noise and generates a "counter-noise" to cancel it, reducing ambient noise by up to 28 dB. They also offer Passive Noise Cancelling through ergonomically designed ear tips for a secure fit.

Image: Visual representation of the Active Noise Cancellation feature, showing how external noise is detected and counter-noise is generated to cancel it.

Imodi esobala

Activate Transparency Mode by touching the button on the left earbud for 1.5 seconds. This mode allows you to hear your surroundings without removing the earbuds, which is useful for interacting with people or being aware of traffic.

Image: Two individuals interacting while wearing the earbuds, illustrating the use of Transparency Mode to hear ambient sounds.

Izingcingo Zezwi Ezicacile

Each earbud is equipped with MEMS dual microphones. One microphone senses and cancels ambient noise, while the other picks up and isolates your voice, ensuring clear calls even in noisy environments.

Image: A person on a phone call with the earbuds, showing the microphone noise cancelling technology at work to deliver clear voice.

Ikhwalithi Yomsindo

The EC10 earbuds feature a 10mm large dynamic driver for deep bass and support AAC/SBC codecs for high-quality audio decoding, providing well-balanced sound for all types of music.

Isithombe: Kuqhume view of the earbud highlighting the 10mm large dynamic driver, emphasizing its role in delivering clear sound and rich bass.

Izilawuli

The earbuds feature touch controls for media playback and call management. Refer to the quick start guide included in the box for specific touch commands.

Isondlo

Ukuhlanza

Hlanza njalo ama-earbud akho kanye nebhokisi lokushaja ukuze ugcine ukusebenza kahle kanye nokuhlanzeka. Sebenzisa indwangu ethambile, eyomile, engenazinti. Ukuze uthole izindlebe, zisuse bese uzihlanza ngensipho namanzi athambile, bese womisa kahle ngaphambi kokuzinamathisela kabusha.

Ukumelana Namanzi (IPX5)

The EC10 earbuds are IPX5 waterproof, meaning they are resistant to sweat and light splashes of water. They are not designed for submersion in water. Ensure earbuds are dry before placing them back in the charging case.

Image: A person exercising with the earbuds, illustrating their resistance to rain and sweat due to IPX5 waterproof rating.

Ukuxazulula inkinga

• Earbuds not pairing/only one earbud working:

  Ensure both earbuds are charged. Place both earbuds back into the charging case, close the lid, wait a few seconds, then open the lid again to re-initiate pairing. If issues persist, try resetting the earbuds (refer to the quick start guide for specific reset instructions).
• Awukho umsindo:

  Check the volume level on your connected device. Ensure the earbuds are properly paired and connected. Try disconnecting and re-pairing the earbuds.

• Izinkinga zokushaja:

  Ensure the charging cable is securely connected and the power source is active. For wireless charging, ensure the case is correctly positioned on the charging pad. Clean the charging contacts on both the earbuds and the case.

• Ikhwalithi yomsindo engeyinhle:

  Ensure the ear tips provide a good seal in your ear. Try different sized ear tips. Clean any debris from the earbud speakers. Move closer to your connected device to avoid interference.

Imininingwane

Iwaranti kanye Nokusekela

For warranty information and customer support, please refer to the warranty card included in your product packaging or visit the official ABKO webindawo. Gcina ubufakazi bakho bokuthenga ngezimangalo zewaranti.

Umkhiqizi: ABKO
