Wolo (4005) 100 Watt Siren Speaker
Specifications
- Product Dimensions
8 x 7.25 x 4 inc - Item Weight
3 pounds - Watt
100 - Ohm
8 - Brand
Wolo
Introduction
The Wolo 4005 is a 100-watt compact siren speaker that uses a heavy-duty steel mounting base plate for simple installation. The speaker is made to withstand the harshest circumstances using durable ABS plastic and corrosion-resistant metal that has been coated black.
Your purchase of a WOLO product is a perfect choice to compliment your vehicle. Our products are manufactured with the finest of materials. Each speaker is bench tested before it is packaged to assure workmanship and quality, so you receive years of reliable service. If you need help with installation or in using your new Wolo speaker, our technicians are available to answer your questions, Monday thru Friday, from 9 AM to 4 PM EST at 1-888-550-4676.
MOUNTING SPEAKER
Select a mounting location in the vehicle’s engine compartment that is dry and safe from the heat produced from the engine’s exhaust manifold. To ensure the siren functions to maximum loudness, make sure the front of the speaker is not blocked. When possible, position the speaker facing downward which will help prevent water from entering the front of the speaker.
IMPORTANT
Before drilling any surface for mounting speaker or for routing wires, carefully inspect the desired location to ensure that there are no components, wires and or any other vehicle part that could be damaged by drilling. Also, wire routing must be out of the deployment path of vehicle airbags.
- Using the speaker’s mounting bracket as a template, mark the desired hole location on each side of the mounting bracket and drill to size 5/16″.
- Secure the speaker to the mounting surface using the hardware provided.
WIRING
Connect either of the siren’s audio output wires to one of the speaker’s wires. Then connect the remaining siren audio output wire to the other speaker wire. If you need to route the wires or harness through the vehicle’s firewall or roof, depending on the speaker’s mounting location, make sure that the hole the wires are being passed through does not have sharp edges. It is recommended that a rubber grommet be installed into the hole to protect the wires.
IMPORTANT
Make sure all connections are taped and wires are secured.
WARRANTY
Wolo Manufacturing Corporation (“Wolo”) warranties to the original purchaser, for three months from the date of purchase, that this product is free from defects in workmanship and materials. If there is such a proven defect, Wolo, at its option, will either repair or replace the item free of charge, if it is returned to Wolo within three months from the date of purchase together with proof of purchase as described below. Wolo reserves the right to inspect any defect prior to settling any warranty claim by repair or replacement. This warranty is limited as above provided and Wolo will not be responsible for fire or other casualties or accidents, due to neglect, abuse, abnormal use, modifications, faulty installation of this product, or natural causes.
ANY EXPRESSED WARRANTY NOT PROVIDED HEREIN IS EXCLUDED AND DISCLAIMED. THE IMPLIED WARRANTIES OF MERCHANTABILITY AND OF FITNESS FOR A PARTICULAR PURPOSE ARE EXPRESSLY LIMITED TO A TERM OF THREE (3) MONTHS. UNDER NO CIRCUMSTANCES SHALL WOLO BE LIABLE TO PURCHASER OR ANY OTHER PERSON FOR ANY SPECIAL OR CONSEQUENTIAL DAMAGES, WHETHER ARISING OUT OF BREACH OF WARRANTY OR OTHERWISE
To obtain warranty service in the Unites States, return the product prepaid, and include the original bill of sale showing the date of purchase. Provide with the return a brief description of the problem. Also, include with the return a check or money order in the amount of $10.00 to cover return shipping.
Mail to
Wolo Manufacturing Corp.
- One Saxwood Street, Deer Park, NY 11729 Attn: Warranty Service E-mail: tech@wolo-mfg.com
Frequently Asked Questions
The two speaker leads must be connected to the speaker cord of the electronic siren in order to connect one speaker. Two speakers must be connected in phase in order to function. Connect one lead of the speaker line from the electronic siren to the two red speaker leads.
Not sure where it was made. I have it on my truck for over 4 years and it works great
Siren speakers are 100-watt speakers that may be connected to any police siren or fireman siren that is 100 watt or 200 watt in power. The device that mounts externally to alert approaching drivers and pedestrians of the vehicle’s approach is the siren speaker, often known as the siren or the amplifier.
With the Smart Siren, voice prompts can be used to support the standard siren functionality, saving consumers from having to memorize patterns for various alarms. Important tasks like notifications and action confirmation can be carried out using voice prompts.
A guest speaker might take on a variety of functions. In addition to supporting the event themes, they can energize an audience, motivate them, give value by giving insider information, provide a fresh viewpoint, break up the more routine portions of the event, and entertain.
The kit uses pre-existing holes in a vehicle frame member to attach the speaker behind the driver-side headlight. When a Rumbler system is placed in the vehicle, this kit functions.
The two speaker leads must be connected to the speaker cord of the electronic siren in order to connect one speaker. Two speakers must be connected in phase in order to function. Connect one lead of the speaker line from the electronic siren to the two red speaker leads.
The siren is louder the higher the wattage. Police sirens are only sold by LED Equipped in 100 or 200-watt models. These are the most typical, and police departments all around the nation employ them.
Even while these sirens often have higher power, a 100 Watt siren is undoubtedly loud enough to be heard by other drivers quite some distance from your car.
