WhatsGPS R56L GPS Positioning Terminal
Statement
Hello! Thank you very much for using the R56L car terminal (mobile user terminal) product . Please read this manual carefully before using it . Please pay attention to all the precautions and warnings mentioned in the manual. Please keep this manual properly for reference.
This manual, as well as the description of the software, may be directly used or reproduced subject to the receipt of a license, only in accordance with such authority.
The contents of this brochure are for informational use, are subject to change without notice, and should not be construed as a commitment by SEEWORLD Corporation. SEEWORLD Corporation assumes no responsibility or legal liability for any deviations that may appear in this book.
SEEWORLD Corporation reserves the right to make changes to specifications at any time without prior notice. SEEWORLD Corporation believes this manual to be accurate and reliable, however, SEEWORLD Corporation assumes no responsibility for its use, or for infringement of patents or other rights of third parties resulting from its use. No license will be given to any patent or patent rights belonging to Swader Corporation
Product Introduction
The R56L positioning terminal is an OBD positioning terminal with rich functions and a wide range of applications. The device adopts AT6558R chip and supports GPS and Beidou satellite system. In addition to satellite positioning, the device also supports single base station and multi-base station positioning. Rich extension functions, please refer to the following description about extension functions. The self-developed hardware monitoring circuit is integrated to make the equipment work reliably and stably for a long time, and it can automatically recover when an abnormality occurs.
Product Features
- Built-in GSM/GPS antenna;
- Built-in 4G CATI chip, compatible with 2G/4G network communication ;
- Built-in high-power surge protection circuit;
- Built-in hardware moniloring circuit, aulomatic recovery of abnormal status;
- Built-in battery switching circuit, support power failure alarm;
- Built-in vibration sensor. support vibration alarm;
- Supports all deployed and upcoming global navigation satellite systems (GNSS)
- Support global multi-base station and satellite positioning mode;
- Support voltage input 9-36V
- Support OTA remote upgrade;
- Adopt IP65 waterproof design;
Specification
| Project | Specifications | Remark |
| Operating Voltage | DC 9V-36V | |
| Working current | 30mA 12V | |
| Static current | Quiescent current 5 mA | When not
charging |
| Targeting | GPS-lmS-1,llS | |
| Positioning error | < 10M | |
| Communication network | 2G/4G | |
| Communication frequency band | C:B1/B1/B5/IJ8/IB4/B38/B39/B40/B41 EU: B1/B3/B7/B8/B20 SA: B1/B2/B3/B4/B5/B7/B8/B28/B66 |
Select the applicable version according to the region |
| Way of communication | TCP | |
| Range or working temperature | – 30 + 80 cc | |
| Working humidity | 35% – 80% | |
| Standard sizes | l ,5 4rnrn*\V34rnrn*I132rnrn | |
| Backup battery working time |
About0.5h | |
| Warranty period | 1 year |
Appearance diagram
By looking at the status indicator, you can understand the working condition of the device. The status of the indicator is as follows:
| LED Color |
LED light status |
Description |
| Yellow | Slow flash | GSM initialization |
| Always on | GSM/GPRS online | |
| Not bright | No GSM signal/no card inserted / shut down | |
| Blue | Slow flash | BD/ GPS signal search |
| Always on | BD/ GPS positioning success | |
| Not bright | GPS sleep/not working /shut down |
Installation Notes
Installation Tutorial
Installation: first open the back cover, into the SIM card (middle card), then close the back cover. (as shown in the figure below)
- The thumb of the left hand is in the direction of the arrow The right thumb is opened in the direction of the arrow
- Open the cover and see the SIM card holder in the direction of the arrow
- SIM card holder opens in the direction of the arrow
- SIM Install SIM card Buckle back the SIM card cover
- Buckle back the SIM card cover
Installation Precautions
The installation method of the terminal is hidden installation, It is recommend to be installed under the guidance of professional and technical personnel designated by the dealer , and pay attention to the fallowing items:
* In order to avoid damage by thieves, the location of the equipment should be as concealed as possible;
* Avoid putting it together with the emission source, such as reversing radar, anti-theft device and other vehicle communication equipment;
* The device has a built-in GSM antenna and GPS
antenna. When installing, make sure that the front is facing up, and there is no metal object blocking the shielding above.
Installation Diagram
OBD common installation location
Area A: some models of Audi, GM, Honda and other brands
Area B: Volkswagen, BMW, Ford, Hyundai, Mercedes-Benz, etc.
Area C: a small number of models such as Tour an and Lexus
Area D: Peugeot, Citroen, Chang an, Renault and other models
The vast majority of car OBD installations are located under the steering wheel
Instruction of Comnon Commands
Common Commands setting
| Command func tion | Command format | Remark |
| Set online | SERVER, [ mode ] , [ Domain Name/JP ] , [port],0# SERVER,I ,gps. what’s gps.com,6801,0# SERVER,0,47.56.208. 182,680 1,0# |
mode = I use domain name setting mode = 0 use IP settings |
| Set APN | APN, [apnname]# APN, cmiot# | APN varies accordi ng to different local telecom operators |
| Set upload interval | TTMER,[TI]# TIMER.10# |
T I : 5- I8000 seconds, motion upload interval, the device defaults to 10s; |
| Heartbeat interval setting | HBT,[T]# HBT,3# |
TI: 60-360S,default I80s |
| Set time zone | GMT,[A],[b],[C)# GMT,E,0,0# | A=EJW, representing the Eastern Time Zone and Western Time Zone respectively; B:0-12, represen ting the time zone; C: 0, 15, 30, 45, means half time zone, the default is 0. |
Common query commands
| Command function | Command format | Remark |
| Query parameters | PARAM# | Query the para1neters currently set by the device |
| Query status | FACTORY# | Query the current working status of the device |
| Device restart | RESET # |
Commonly used control commands
| Command function | Comma11d format | Remark |
| Vibration alarm | SENALM,[A][,M]# SENALM, ON, 1# SENALM,OFF# SENALM# | A=ON/OFF, default is OFF; M=0/1/2/3, Alarm mode: 0 only GPRS 1:SMS+GPRS, 2:GPRS+SMS+PHONE 3:GPRS+PHONEThe default alarm mode is 1 SENALM# query vibration alarm settings |
| Power failure alarm | POWERALM, [A](,M]# POWERALM, ON,1# POWERALM, OFF# POWERALM# | A=ON/OFF, the default is ON; M=0/1/2/3, Alarm mode : 0 : only GPRS,
|
Troubleshooting
When operating the terminal, if you feel that the device is abnormal, please refer to the following problems and solutions. If the problem still cannot be solved, please contact the seller or service provider.
| Common Problem | Reason | Solution |
| Poor signal reception | Use the terminal in areas with poor signal reception such as near tall buildings or in basements, where radio waves cannot effectively communicate | Use the tensional in a location with good signal |
| Unable to connect to the network | SIM card not installed Dirt on the metal surface of the SIM card | Check the SIM card Wipe with a clean cloth |
| SIM card invalid | Internet service provider | |
| Out of GSM service area | Please move to the ISP service area | |
| weak signal | Please move to a place with strong signal and try again | |
| Switch off | Make sure the device is turned on | Tum on the device battery switch |
| Please check if the SIM is installed | Please install the SIM card | |
| poor contact | Check if the plug is connected |
Warranty card
| Maintenance record | |
| Maintenance shop | |
| Sending date | |
| Fault description | |
| Maintenance situation | |
| IMEI number | |
| Maintenance person | |
FCC Warning:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipmentoff and on, the user is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body.
