CASIO Lineage Solar Radio Multiband6 LCW-M300DB-1AJF Watch User Manual

giriiş

This manual provides detailed instructions for the proper use and maintenance of your CASIO Lineage Solar Radio Multiband6 LCW-M300DB-1AJF watch. Please read this manual thoroughly to ensure optimal performance and longevity of your timepiece. This watch combines solar power with radio-controlled timekeeping for accuracy and convenience.

Temel Özellikler

• Dayanıklı Güneş Enerjisi: Utilizes a solar charging system that converts light into power, eliminating the need for regular battery replacement.
• Multiband 6 Radio Control: Automatically receives time calibration signals from six transmission stations worldwide (Japan, North America, Europe, and China) to maintain accurate time.
• 100 Metre Su Geçirmezlik: Yüzme ve şnorkelli dalış için uygundur ancak dalış için uygun değildir.
• Dünya Saati: Displays the current time in 48 cities (with daylight saving time setting) and Coordinated Universal Time (UTC).
• Kronometre: 1/100-second stopwatch with a 24-hour measuring capacity.
• Zamanlayıcı: Countdown timer settable in 1-minute units up to 60 minutes, with a repeat function.
• Alarmlar: Five daily alarms, including one with a snooze function, plus an hourly zaman sinyali.
• Pil Seviyesi Göstergesi: Displays the current charge level of the watch's rechargeable battery.
• Güç Tasarrufu İşlevi: Automatically enters a power-saving mode when left in the dark for a certain period to conserve energy.
• Tam Otomatik Takvim: Automatically adjusts for month lengths and leap years until the year 2099.
• 12/24 Saat Formatı: Allows switching between 12-hour and 24-hour time displays.
• Full Auto LED Light: Automatically illuminates the display when the arm is tilted in the dark, with an afterglow feature.

Kurulum ve İlk Yapılandırma

1. Initial Charging (Tough Solar)

Before initial use, expose the watch to bright light for several hours to ensure it is sufficiently charged. The watch features a solar panel that converts light into electrical energy, stored in a rechargeable battery. Regular exposure to light is essential for maintaining optimal charge.

2. Time Calibration Signal Reception (Multiband 6)

Your watch automatically receives time calibration signals. For optimal reception, place the watch near a window at night. The watch will attempt to receive the signal automatically between midnight and 5:00 AM. Manual reception can also be initiated.

• Otomatik Alım: The watch attempts to receive the signal up to six times a day.
• Manuel Alım: Refer to the "Operating" section for instructions on initiating manual signal reception.

The Multiband 6 feature ensures accurate timekeeping by receiving signals from various global locations. If signal reception is not possible, the watch operates with the accuracy of a standard quartz movement (approximately ±15 seconds per month).

3. Home City Setting

Set your Home City (time zone) to ensure correct time display and radio signal reception. This setting is crucial for the watch to automatically adjust to your local time.

1. Zaman Tutma Modunda, tuşuna basın ve basılı tutun AYARLAMAK button (usually top left) until the city code starts to flash.
2. Kullanın İLERİ Ve TERSİ buttons (usually top right and bottom right) to select your desired city code.
3. Basın AYARLAMAK Ayarlar modundan çıkmak ve onaylamak için tekrar düğmeye basın.

Saatin Çalıştırılması

Mod Değiştirme

Basın MOD button (usually bottom left) to cycle through the different modes:

• Zaman İşleyişi Modu
• Dünya Saatleri Modu
• Alarm Modu
• Kronometre Modu
• Zamanlayıcı Modu

Belirli Fonksiyonları Kullanma

Dünya Saatleri Modu

Dünya Saati Modunda, şunu kullanın: İLERİ Ve TERSİ düğmeler view the current time in different cities around the world. You can also swap your Home City time with the World Time city time.

Alarm Modu

In Alarm Mode, you can set up to five independent daily alarms. One alarm includes a snooze function. Use the AYARLAMAK button to select an alarm and the İLERİ/TERSİ buttons to set the alarm time. Press the MOD button to toggle alarms on/off.

Kronometre Modu

The stopwatch measures elapsed time, split times, and two finishes. Press the BAŞLAT/DURDUR button (usually top right) to start and stop the measurement. Press the SIFIRLAMA button (usually bottom right) to reset the stopwatch.

Zamanlayıcı Modu

The countdown timer can be set from 1 minute up to 60 minutes. Use the AYARLAMAK button to set the countdown time and the BAŞLAT/DURDUR button to begin the countdown. An alarm will sound when the timer reaches zero.

Full Auto LED Light

The watch features an automatic LED backlight. When the auto light switch is enabled, tilting your wrist towards your face in a dark environment will automatically illuminate the display. This function can be enabled or disabled in Timekeeping Mode by holding the IŞIK button (usually bottom right) for a few seconds.

Bakım

Charging the Watch (Tough Solar)

To ensure continuous operation, expose the watch to light regularly. The watch charges most efficiently under direct sunlight. Indoor fluorescent lighting also charges the watch, but at a slower rate. Avoid prolonged storage in dark places, as this can deplete the rechargeable battery.

• Şarj Yönergeleri: Saati, ön yüzü ışığa maruz kalacak şekilde yerleştirin.
• Pil Seviyesi Göstergesi: Monitor the battery level indicator to ensure sufficient charge.
• Güç tasarrufu: The watch will enter Power Saving mode when left in the dark for an extended period to conserve charge.

Suya Dayanıklılık

The watch is rated for 100-meter water resistance. This means it is suitable for everyday use, swimming, and snorkeling. However, it is not designed for scuba diving. Avoid operating buttons while the watch is wet or submerged to prevent water ingress.

• Düğmeleri su altında çalıştırmayın.
• Avoid exposing the watch to hot water or steam (e.g., showers, saunas) as this can compromise seals.
• Tuzlu suya maruz kaldıktan sonra saati tatlı suyla durulayın ve kurulayın.

Temizlik

Wipe the watch and band with a soft, dry cloth to remove dirt and moisture. For stubborn dirt, use a soft brush with mild soap and water, then rinse thoroughly and dry. Avoid using chemical cleaners or solvents.

Sorun giderme

Time is Incorrect

• Sinyal Alımını Kontrol Edin: Ensure the watch is in a location conducive to radio signal reception (e.g., near a window, away from electronic interference). Try initiating manual reception.
• Ana Şehir Konumu: Verify that your Home City is correctly set for your current time zone.
• Manuel Zaman Ayarı: If automatic reception consistently fails, you can manually set the time. Refer to the full instruction manual for detailed steps on manual time adjustment.

Watch Stops or Display is Blank

• Yetersiz Şarj: The watch may not have enough power. Expose it to bright light for several hours to charge the solar battery.
• Enerji tasarrufu modu: The watch might be in Power Saving mode. Move it to a well-lit area or press any button to wake it up.

Buttons Do Not Respond

• Suya Maruz Kalma: Ensure the watch is completely dry if it has been exposed to water.
• Düşük Pil: A very low battery charge can sometimes affect button responsiveness. Charge the watch fully.

Özellikler

Ürün Videosu Tanıtımı

Görsel bir açıklama için bu videoyu izleyinview of the CASIO Lineage LCW-M300DB-1AJF watch, showcasinTasarımı ve özellikleri.

Garanti ve Destek

Your CASIO Lineage watch is covered by a manufacturer's warranty. Please refer to the warranty card included with your purchase for specific terms and conditions, including warranty period and coverage details.

Müşteri Desteği

For technical assistance, repairs, or further inquiries, please contact CASIO customer support. Contact information can typically be found on the official CASIO webSitede veya garanti belgelerinizde.

• Çevrimiçi Kaynaklar: Visit the official CASIO webSıkça sorulan sorular, ek kılavuzlar ve destek iletişim bilgileri için site.
• Servis Merkezleri: Information on authorized service centers can be found on the CASIO webalan.
