tp-link UH6120C USB Type C Hub
Product Overview
| USB-C Connector | For connecting to your host device |
| USB-C PD (Power Delivery) Port | For unidirectionally charging your host device when connected to a PD charger. PD 3.0; Up to 100W * Does not support data transfer |
| USB-C Por | USB 3.0; 5 GBps data transfer |
| HDMI Port | Up to 4K@60Hz (backward compatible) |
| Gigabit Ethernet Port | For connecting to a wired network provided by a router, modem, etc |
| USB-A Ports ×2 | USB 3.0; 5 GBps data transfer |
| Input | PD: 5V/3A, 9V/3A, 12V/3A, 15V/3A, 20V/5A USB-C Connector: 5V/3A |
| Supported System | Windows, Mac OS, iPad OS, iOS, Google Chrome OS, Linux OS, Nintendo OS, Android OS |
| Plug and Play | USB-C PD port, USB-C port, HDMI port, USB-A ports, gigabit Ethernet port.
|
Note: The ports’ actual performance may vary based on your host device specifications
Using The Hub
This hub supports the Plug and Play feature. Plug the USB-Connector into your host device, then plug in your external peripheral into the corresponding port of the hub.
Note: A PD charger (not included) is not required. If you wish to use a PD charger to charge your host device, please refer to Tips (2B).
Tips:
- When not in use, please unplug or remove the external peripherals from the hub first, and then unplug the hub from your host device
- If you need to connect a PD charger to the hub’s USB-C PD port, please:
- A) Notice that it only has the charging function and is input only.
- B) Use an original or certified PD charger to charge your host device. The output of the PD charger should meet the input specifications of the USB-C PD port.
Safety Information
- When product has power button, the power button is one of the way to shut off the product; when there is no power button, the only way to completely shut off power is to disconnect the product or the power adapter from the power source.
- Do not attempt to disassemble, repair, or modify the device. If you need service, please contact us.
- Keep the device away from water, fire, humidity or hot environments.
- This equipment can be powered only by equipments that comply with Power Source Class 2 (PS2) or Limited Power Source (LPS) defined in the standard of IEC 62368-1
Recycling
This product bears the selective sorting symbol for Waste electrical and electronic equipment (WEEE). This means that this product must be handled pursuant to European directive 2012/19/EU in order to be recycled or dismantled to minimize its impact on the environment. User has the choice to give his product to a competent recycling organization or to the retailer when he buys a new electrical or electronic equipment.
The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant provisions of directives 2014/30/EU, 2014/35/EU, 2011/65/EU and (EU)2015/863.
The original EU declaration of conformity may be found at https://www.tp-link.com/en/support/ce/
TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant provisions of the Electromagnetic Compatibility Regulations 2016 and Electrical Equipment (Safety) Regulations 2016.
The original UK declaration of conformity may be found at https://www.tp-link.com/support/ukca/
Customer Support
For technical support, replacement services, the user guide and more information, please visit
https://www.tp-link.com/support, or simply scan the QR code.
