PART # IC-XP-120
INSTALLATION INSTRUCTIONS
TOUCHÉ LIGHTING CONTROLS

INTERPOSING CONTACTOR

TIPS / NOTES

1. SLC-R MODULE (INCLUDED WITH IC-XP-120)
2. IC-XP-120 ENCLOSURE IS INCLUDED (8X8X4 FOR IC-3P-120 AND 10X10X4 FOR IC-6P-120 AND IC-9P-120)
3. POLE CONTACTOR QUANTITY VARIES BASED ON MODEL NUMBER

CONTROL POWER MUST BE 120V

Touché Lighting Controls (a Product of ESI Ventures)
A: 2085 Humphrey Street, Fort Wayne, IN 46803
T: 888.841.4356
W: ToucheControls.com
