PGST A519W-EU-H Wireless Home Alarm System Instruction Manual

1. บทนำ

This manual provides detailed instructions for the installation, operation, and maintenance of your PGST A519W-EU-H Wireless Home Alarm System. This system is designed to enhance your home security with real-time monitoring and alerts, offering peace of mind through its comprehensive features and smart home compatibility.

2. เนื้อหาบรรจุภัณฑ์

โปรดตรวจสอบว่าส่วนประกอบทั้งหมดมีอยู่ในแพ็คเกจของคุณ:

• 1 x PGST A519W-EU-H Alarm Host (Siren)
• เซ็นเซอร์ประตู/หน้าต่าง 8 ตัว
• 2 x Motion Detectors
• รีโมทคอนโทรล 2 อัน
• Mounting Accessories (adhesive tape, screws)
• Power Adapter for Alarm Host

ภาพ: เหนือview of the PGST A519W-EU-H Wireless Home Alarm System components, including the siren, motion sensors, door/window sensors, and remote controls.

3. ส่วนประกอบของระบบ

3.1 Alarm Host (Siren)

The alarm host serves as the central unit of your security system. It connects to your Wi-Fi network, emits a loud siren when triggered, and sends notifications to your mobile application. It features a built-in backup battery for continuous operation during power outagใช่

Image: Close-up of the PGST siren with icons indicating its features: >100dB volume, real-time alarm, quick response, built-in backup battery.

Image: Diagram showing the internal structure of the siren with its backup battery, emphasizing 24-hour protection during power cuts.

3.2 Door/Window Sensors

These two-part sensors detect when a door or window is opened. When the two parts separate by more than 1 cm, an alarm is triggered, and a notification is sent to your phone.

3.3 Motion Detectors

Motion detectors use infrared technology to sense movement within their detection range. They are ideal for securing larger areas or entry points.

Image: A motion detector mounted in a hallway, detecting a person, illustrating its wide-range detection capability.

3.4 รีโมทคอนโทรล

The remote controls allow for convenient arming, disarming, and an emergency SOS function with a single press.

4. คู่มือการติดตั้ง

4.1 Powering the Alarm Host

1. Connect the provided power adapter to the alarm host.
2. Plug the adapter into a standard wall outlet. The host will power on automatically.

4.2 การเชื่อมต่อกับ Wi-Fi และแอป

1. ดาวน์โหลด ชีวิตที่ชาญฉลาด or ตุยย่า สมาร์ท app from your mobile app store (iOS or Android).
2. ลงทะเบียนหรือเข้าสู่ระบบบัญชีของคุณ
3. Follow the in-app instructions to add a new device. Select 'Security & Sensor' > 'Alarm (Wi-Fi)'.
4. Ensure your mobile device is connected to a 2.4 GHz Wi-Fi network. The alarm host only supports 2.4 GHz Wi-Fi.
5. ป้อนรหัสผ่าน Wi-Fi ของคุณเมื่อได้รับแจ้ง
6. The app will guide you through the pairing process. Once connected, the host's indicator light will confirm successful pairing.

Image: The PGST siren mounted on a wall next to a Wi-Fi router, indicating instant Wi-Fi connectivity for remote access.

4.3 การจับคู่เซ็นเซอร์และรีโมท

Sensors and remote controls are typically pre-paired with the alarm host. If re-pairing is needed or if you add new accessories:

1. Open the Smart Life/Tuya Smart app and navigate to your alarm system.
2. Select the option to 'Add Accessory' or 'Add Sensor'.
3. Follow the on-screen prompts, which usually involve triggering the sensor (e.g., separating door sensor parts, waving in front of motion detector) or pressing a button on the remote control.

4.4 Mounting Sensors

Use the provided adhesive tape or screws for installation.

• เซ็นเซอร์ประตู/หน้าต่าง: Mount the two parts on the door/window frame and the moving part, ensuring they are aligned and within 1 cm of each other when closed.
• เครื่องตรวจจับความเคลื่อนไหว: Install in a corner or on a wall where it can cover the desired area without obstructions. Avoid direct sunlight or heat sources.

Image: Three images demonstrating multi-scenario installation of door/window sensors on a door, a store entrance, and drawers.

5. คู่มือการใช้งาน

5.1 อาวุธและปลดอาวุธ

You can arm or disarm your system using the mobile app or the remote controls.

• แขน: Activates all sensors. Any triggered sensor will sound the siren and send an alert.
• ปลดอาวุธ: Deactivates all sensors, allowing free movement without triggering the alarm.
• แขนบ้าน: Activates perimeter sensors (e.g., door/window sensors) while allowing movement within the home (motion detectors may be excluded, depending on configuration).

5.2 ฟังก์ชัน SOS ฉุกเฉิน

In an emergency, press the SOS button on your remote control. This will immediately trigger the siren and send emergency notifications to linked contacts via the app.

Image: An elderly person holding a remote control with a prominent SOS button, demonstrating the one-button emergency function.

5.3 Real-time Alerts

When a sensor is triggered, the system sends instant notifications to your smartphone via the Smart Life/Tuya Smart app, providing details about the triggered sensor and its location.

Image: A smartphone displaying the Smart Life app with real-time alarm notifications, showing the exact location of triggered sensors.

5.4 การรวมระบบบ้านอัจฉริยะ

The PGST A519W-EU-H system is compatible with Amazon Alexa and Google Assistant. You can integrate your alarm system into your smart home routines for voice control and automation.

• Enable the Smart Life/Tuya Smart skill/action in your Alexa or Google Home app.
• เชื่อมต่อบัญชี Smart Life/Tuya Smart ของคุณ
• ใช้คำสั่งเสียง เช่น "Alexa เปิดใช้งานระบบรักษาความปลอดภัยในบ้านของฉัน" หรือ "Hey Google ปิดใช้งานระบบเตือนภัย"

Image: A woman and child entering a home, with smart speakers (Alexa and Google Assistant) visible, illustrating compatibility and voice control.

5.5 Scheduled Arm/Disarm

Set up schedules within the Smart Life/Tuya Smart app to automatically arm or disarm your system at specific times, optimizing convenience and security.

Image: Four images depicting scheduled arming and disarming scenarios: disarming upon waking, arming when going out, disarming upon returning home, and arming at night.

6. การบำรุงรักษา

6.1 การเปลี่ยนแบตเตอรี่

• Siren (Alarm Host): The host has a built-in backup battery that automatically charges when connected to power. It provides continuous operation for up to 24 hours during power cuts. No user replacement is typically required for this internal battery.
• Door/Window Sensors & Motion Detectors: These accessories are battery-powered. When the battery is low, the app will notify you. Replace batteries with the specified type (e.g., CR2032 for sensors, AA for motion detectors, refer to individual sensor manuals for exact type).
• รีโมทคอนโทรล: These also use small button-cell batteries. Replace when the indicator light fails to illuminate or range decreases.

6.2 การทำความสะอาด

Wipe all components with a soft, dry cloth. Avoid using liquid cleaners or abrasive materials.

7 การแก้ไขปัญหา

• Alarm Host not connecting to Wi-Fi:
  Ensure your Wi-Fi network is 2.4 GHz. Check Wi-Fi password. Move the host closer to the router. Restart the host and your router.
• เซ็นเซอร์ไม่ส่งสัญญาณเตือน:
  Check sensor battery levels in the app. Ensure sensors are properly paired. For door/window sensors, verify the two parts are aligned and separate by more than 1 cm when opened. For motion detectors, ensure no obstructions are blocking its field of view.
• ไม่มีการแจ้งเตือนจากแอป:
  Check your phone's notification settings for the Smart Life/Tuya Smart app. Ensure the app has permission to send notifications. Verify your phone has an active internet connection.
• Siren not sounding:
  Ensure the alarm host is powered on and connected. Check the volume settings in the app.

8. ข้อมูลจำเพาะทางเทคนิค

9. การรับประกันและการสนับสนุน

Your PGST A519W-EU-H Wireless Home Alarm System comes with a รับประกัน 1 ปี ตั้งแต่วันที่ซื้อสินค้า

For technical assistance, troubleshooting, or warranty claims, please contact PGST customer support. We aim to provide a response within 24 hours.

Please refer to the contact information provided with your purchase or visit the official PGST webเว็บไซต์สำหรับรายละเอียดการสนับสนุน
