VOX111 – Quick Start Guide
Motion Activated MP3 Message Player
VoiceOFF is a registered trademark of System Q Ltd
www.systemq.com/PDF/manual/xVOX111.pdf
The VOX111 is a motion activated voice annunciator with built in PIR. It can also play a different MP3 message by triggering its alarm input.
Powering
Power the VOX111 from 12V DC (via the input voltage terminals) on the PCB. The current consumption is 350mA maximum. A power supply is not provided.
Triggering
The built-in PIR has a 120º detection angle with a range of up to 4 meters. As the unit is ceiling mounted it is ideally designed to be placed in a ceiling tile near an entranceway to detect customers or other visitors entering a room or area.
In addition to the PIR trigger, the unit has an additional alarm input that can be used to trigger a secondary message.
Volume Control
An infra-red remote control is provided for adjusting the volume.
Connections
| No | Label | Description |
| 1 | L/R output | 3.5mm audio socket for audio output |
| 2 | Audio input | 3.5mm audio socket for audio input |
| 3 | 12V DC | 2.1mm DC socket for connecting PSU |
| 4 | USB | Micro USB socket for connecting to PC |
| 5 | COM NC TG GND | Screw terminal block for connecting alarm input and output |
Pre-recorded Messages
| SQ01.mp3 (PIR triggered message) | “Welcome face coverings are required whilst in this store thank you for helping keep us all safe.” |
| SQ02.mp3 (External alarm input”Please triggered message) | observe the social distancing measures we have in place during your visit” |
Mounting
The VOX111 is similar in design to a downlighter. For installation, you will need a recess of at least 108mm in diameter with a headroom of about 120mm.
Recording Custom Messages – Overview
- The VOX111 will only playback audio files that are MP3.
- See the table above for file naming convention.
- Plug the Micro USB socket into a PC to change the MP3 files
| IR Detection Range | Up to 4m (120 Deg) |
| Audio Inputs | 1 |
| Audio Input Connection | 3.5mm Audio Socket |
| Audio Outputs | 1 |
| Audio Output Connection | 3.5mm Audio Socket |
| Power | 12VDC |
| Input Power Connection | 2.1mm DC Socket |
| Current Consumption | Playing – 350mA/ Standby – 20mA |
| PSU | Required |
| Alarm Inputs | 1 |
| Alarm Input Connection | NC Push Terminals |
| Relay Outputs | 1 |
| Use | Internal Use Only |
| Speaker | 3 Watts / 8 Ohms |
| Mount | Ceiling |
| Cut Out Diameter | 108mm |
| Minimum Recess | 120mm |
| Case | White |
| PC Connection | Micro USB Socket |
| Memory | Built-in |
| File Format | MP3 (Bit Rate – 8-320Kbps) |
| Working Temperature | -10 ∼ 35 Deg C |
| Dimensions | Max Dia 127mm |
All spec if cations are approximate. System Q Ltd reserves the right to change product spec if cations or features without notice. Whi 1st every effort is made to ensure that these instructions are complete and accurate, System 0 Ltd cannot be held responsible for any losses, no matter how they arise, from errors or omissions in these instructions, or the performance or non-performance of the equipment referred to.
Quick Start Guide – VOX111
Copyright 2021 System Q Ltd
This symbol indicates that equipment must not be mixed with general household waste. For treatment, recovery, and recycling please return to your local designated
WEE/CG0783SS collection point as defined by your local council.
