TECKNET TK-MS024 Wireless Bluetooth Mouse User Manual

1. Úvod

Thank you for choosing the TECKNET TK-MS024 Wireless Bluetooth Mouse. This manual provides detailed instructions for setting up, operating, and maintaining your new mouse. Please read this guide thoroughly to ensure optimal performance and longevity of your device.

2. Produkt skončilview

The TECKNET TK-MS024 is a versatile wireless mouse designed for comfort and efficiency. It features multiple connectivity options, adjustable DPI, and an ergonomic design suitable for various computing tasks.

Kľúčové vlastnosti:

• Three-Mode Wireless Connection: Supports Bluetooth 5.0, Bluetooth 3.0, and 2.4 GHz wireless via USB-A receiver.
• 4-smerné rolovacie koliesko: Enables both vertical and horizontal scrolling for enhanced navigation.
• Nastaviteľné DPI: Six sensitivity levels (800/1200/1600/2400/3200/4800 DPI) with an indicator light.
• Tichá prevádzka: Up to 90% quieter clicks compared to conventional mice.
• Ergonomický dizajn: Full-size shape with natural curvature for reduced wrist strain and comfort.
• Dlhá výdrž batérie: Up to 24 months with intelligent auto-sleep mode.

The mouse features an ergonomic, full-size design with a natural curvature and integrated wrist rest, suitable for both left and right-handed users, ensuring comfort during long work sessions.

Designed for quiet operation, the mouse's silent clicks reduce noise by up to 90%, promoting better concentration in various environments.

3. Nastavenie

3.1 Inštalácia batérie

1. Otvorte kryt priehradky na batérie, ktorý sa nachádza na spodnej strane myši.
2. Insert two AAA batteries (not included) according to the polarity indicators (+/-).
3. Bezpečne zatvorte kryt priestoru pre batérie.

This image shows the mouse's automatic sleep mode feature, which conserves battery life, and indicates that it requires 2 AAA batteries (not included).

3.2 Režimy pripojenia

The mouse supports three connection modes: 2.4 GHz wireless (via USB receiver), Bluetooth 5.0, and Bluetooth 3.0. You can connect to up to three devices simultaneously and switch between them.

Bezdrôtové pripojenie 2.4 GHz:

1. Locate the USB-A receiver stored in the battery compartment of the mouse.
2. Zapojte prijímač USB-A do voľného portu USB na počítači.
3. Turn on the mouse. The mouse should automatically connect.

Bluetooth Connection (BT 5.0 / BT 3.0):

1. Zapnite myš.
2. Press the mode switch button on the underside of the mouse to select either BT1 or BT2 mode. The corresponding indicator light will flash.
3. On your device (laptop, PC, Mac, tablet), go to Bluetooth settings and search for new devices.
4. Select "TECKNET Mouse" from the list of available devices to pair.
5. Once paired, the indicator light will stop flashing and remain solid for a few seconds.

The mouse offers versatile connectivity with 2.4 GHz wireless, Bluetooth 5.0, and Bluetooth 3.0 modes, allowing connection to up to three devices simultaneously.

4. Návod na obsluhu

4.1 Úprava DPI

The mouse features 6 adjustable DPI levels to suit various tasks and preferences. Press the DPI button, located behind the scroll wheel, to cycle through the settings:

• 800 DPI
• 1200 DPI
• 1600 DPI
• 2400 DPI
• 3200 DPI
• 4800 DPI

An indicator light will signal the current DPI level. The mouse includes a memory function that saves your last DPI setting.

This image illustrates the mouse's intelligent sensitivity with 6 adjustable DPI levels (800, 1200, 1600, 2400, 3200, 4800) for precise control, indicated by an LED.

4.2 4-Way Scrolling

The intelligent metal scroll wheel allows for both vertical and horizontal scrolling. Tilt the scroll wheel left or right to perform horizontal scrolling, which is particularly useful for navigating wide spreadsheets or large artboards.

The mouse features an intelligent metal scroll wheel that supports both vertical and horizontal scrolling, enhancing navigation in wide documents and spreadsheets.

4.3 Prepínanie viacerých zariadení

To switch between connected devices (2.4G, BT1, BT2), simply press the mode switch button on the underside of the mouse. The corresponding indicator light will illuminate to show the active connection.

5. Údržba

• Čistenie: Na čistenie myši použite mäkkú, suchú handričku. Na odolnú špinu použite mierneamp Môžete použiť handričku, ale dbajte na to, aby sa do zariadenia nedostala vlhkosť.
• Výmena batérie: Replace AAA batteries when the mouse's performance degrades or the low battery indicator (if present) illuminates.
• Ukladací priestor: When not in use for extended periods, remove the batteries to prevent leakage. Store the mouse in a cool, dry place.

6. Riešenie problémov

Myš nereaguje:

• Uistite sa, že je myš zapnutá.
• Skontrolujte stav batérie a v prípade potreby ju vymeňte.
• V prípade pripojenia s frekvenciou 2.4 GHz sa uistite, že je USB prijímač bezpečne zapojený do funkčného USB portu. Skúste iný USB port.
• For Bluetooth connection, ensure Bluetooth is enabled on your device and the mouse is correctly paired. Try re-pairing the mouse.
• Uistite sa, že myš je v efektívnom prevádzkovom dosahu (do 15 metrov).

Prerušované pripojenie:

• Presuňte myš bližšie k zariadeniu.
• Nepoužívajte myš na kovových povrchoch, ktoré môžu rušiť bezdrôtové signály.
• Minimize interference from other wireless devices operating on the same frequency.

Cursor Movement is Erratic:

• Vyčistite optický senzor na spodnej strane myši.
• Používajte myš na čistom, nereflexnom povrchu alebo na podložke pod myš.
• Ak je kurzor príliš citlivý, upravte nastavenie DPI na nižšiu úroveň.

7. Špecifikácie

8. Záruka a podpora

TECKNET ponúka 36-mesačná záruka for registered users of this product. If you encounter any issues or have questions regarding your TECKNET TK-MS024 Wireless Bluetooth Mouse, please contact TECKNET customer service for assistance. Please refer to the official TECKNET website or your purchase documentation for specific contact details and warranty registration information.
