eSSL KartString بايوميٽرڪ ٽائيم اٽينڊنس مشين يوزر مينوئل

1. تعارف ۽ اوورview

The eSSL KartString Biometric Time Attendance Machine is designed to provide efficient and secure time management and access control for organizations. This device utilizes fingerprint recognition technology to accurately record employee attendance, ensuring only authorized individuals are tracked. It features a clear display, a user-friendly keypad, and robust data storage capabilities, making it an essential tool for modern workforce management.

This manual provides detailed instructions for the setup, operation, and maintenance of your eSSL KartString Biometric Time Attendance Machine.

شڪل 1: سامهون view of the eSSL KartString Biometric Time Attendance Machine, showing the display, keypad, and fingerprint sensor.

2. مصنوعات جون خاصيتون

• فنگر پرنٽ جي سڃاڻپ: Secure and accurate biometric identification for attendance.
• High Transaction Storage: Capable of storing up to 100,000 attendance records.
• Color TFT Display: A 2.8-inch color display for clear user interface and information display.
• Multiple Communication Methods: Supports TCP/IP for network connectivity and USB-host for data transfer.
• Integrated Keypad: Soft buttons for password entry and menu navigation.
• ڪمپيڪٽ ڊيزائن: Measures approximately 183 x 45 x 138 mm, suitable for various installation environments.
• Cloud-Based Software: Includes 6 months of cloud-based attendance management software by KartString for enhanced data management and reporting.

3. سيٽ اپ جون هدايتون

Follow these steps to set up your eSSL KartString Biometric Time Attendance Machine:

1. پيڪنگ کولڻ: Carefully remove the device from its packaging and ensure all components are present.
2. چڙهڻ (اختياري): Choose a suitable location for installation, typically near an entrance or exit. Secure the device to a wall using appropriate mounting hardware (not included, consult a professional if unsure).
3. پاور ڪنيڪشن: Connect the provided power adapter to the device's power input port and then plug it into a standard electrical outlet. The device will power on automatically.
4. Network Connection (TCP/IP): For network-based data management, connect an Ethernet cable from your network router or switch to the device's LAN port.
5. شروعاتي تشڪيل: Upon first power-on, the device may prompt for initial setup, such as date, time, and administrator registration. Follow the on-screen instructions.

4. آپريٽنگ هدايتون

4.1 Administrator Registration

Before employees can use the system, an administrator must be registered to manage settings and user data.

1. کي دٻايو م/ٺيڪ مين مينيو تائين رسائي حاصل ڪرڻ لاءِ بٽڻ.
2. ڏانهن وڃو استعمال ڪندڙ جو انتظام or Enroll User تير جي ڪنجي کي استعمال ڪندي.
3. چونڊيو Register Admin or similar option.
4. Follow the on-screen prompts to scan the administrator's fingerprint multiple times for accurate registration.
5. Assign administrator privileges as required.

4.2 Employee Fingerprint Enrollment

Each employee needs to register their fingerprint(s) to use the attendance system.

1. Access the main menu as an administrator.
2. ڏانهن وڃو استعمال ڪندڙ جو انتظام or Enroll User.
3. چونڊيو نئون استعمال ڪندڙ or فنگر پرنٽ داخل ڪريو.
4. Enter the employee ID (if prompted) and then instruct the employee to place their finger on the sensor.
5. The device will prompt the employee to lift and place their finger several times for a complete scan.
6. Confirm successful enrollment.

4.3 حاضري رڪارڊ ڪرڻ

Employees can record their attendance by simply placing their registered finger on the sensor.

1. پڪ ڪريو ته ڊوائيس هلندڙ آهي ۽ اسٽينڊ بائي موڊ ۾.
2. The employee places their registered finger firmly on the fingerprint sensor.
3. Upon successful recognition, the device will display a confirmation message (e.g., "Thank You" or "Punch In/Out Successful") and an audible prompt.

4.4 ڊيٽا جو انتظام

Attendance data can be retrieved via TCP/IP network or USB-host.

• Via TCP/IP: Connect the device to your network. Use the provided cloud-based attendance management software or compatible third-party software to connect to the device and download attendance logs. Refer to the software's documentation for specific instructions.
• Via USB-Host: Insert a USB flash drive into the device's USB-host port. Navigate to ڊيٽا جو انتظام or ڊائون لوڊ ڊيٽا in the menu. Select the desired data (e.g., attendance logs, user data) and initiate the transfer to the USB drive.

5. سار سنڀال

باقاعده سار سنڀال توهان جي ڊوائيس جي بهترين ڪارڪردگي ۽ ڊگهي عمر کي يقيني بڻائي ٿي.

• سينسر جي صفائي: Gently wipe the fingerprint sensor with a soft, dry, lint-free cloth. Avoid using abrasive materials or liquid cleaners directly on the sensor.
• ڊوائيس صاف ڪرڻ: ھڪڙو نرم استعمال ڪريو، ٿورڙو ڊيamp cloth to clean the exterior of the device. Do not allow water or cleaning solutions to enter the device.
• ڊيٽا بيڪ اپ: Regularly back up attendance data to an external storage device (USB) or through the network software to prevent data loss.
• سافٽ ويئر اپڊيٽ: Check the eSSL website or contact support for any available firmware or software updates to ensure your device operates with the latest features and security enhancements.

6. مسئلا حل ڪرڻ

هي حصو عام مسئلن کي حل ڪري ٿو جيڪي توهان کي منهن ڏئي سگهن ٿا.

• ڊوائيس تي طاقت نه آهي:
  • پڪ ڪريو ته پاور اڊاپٽر ڊوائيس ۽ ڪم ڪندڙ برقي آئوٽليٽ ٻنهي سان محفوظ طور تي ڳنڍيل آهي.
  • ٻئي ڊوائيس ۾ پلگ ان ڪندي پڪ ڪريو ته پاور آئوٽليٽ ڪم ڪري رهيو آهي.
• آڱرين جي نشان جي سڃاڻپ نه ٿي:
  • پڪ ڪريو ته آڱر صاف ۽ سڪل آهي.
  • Place the entire pad of the registered finger firmly on the sensor.
  • Try re-enrolling the fingerprint if recognition issues persist.
  • Clean the fingerprint sensor as described in the Maintenance section.
• Cannot Connect to Network (TCP/IP):
  • Verify the Ethernet cable is properly connected to both the device and the network router/switch.
  • Check network settings on the device to ensure correct IP address, subnet mask, and gateway.
  • Ensure your network router is functioning correctly.
• USB ڊيٽا منتقلي ۾ ناڪامي:
  • Ensure the USB flash drive is properly inserted and formatted to a compatible file سسٽم (مثال طور، FAT32).
  • Try a different USB flash drive.
  • Verify there is sufficient space on the USB drive.

If you encounter issues not covered here, please refer to the support section.

7. وضاحتون

8. وارنٽي ۽ سپورٽ

The eSSL KartString Biometric Time Attendance Machine comes with standard manufacturer warranty. Please refer to your purchase documentation for specific warranty terms and conditions.

For technical assistance, troubleshooting, or inquiries regarding the included 6-month cloud-based attendance management software by KartString, please contact eSSL customer support or your authorized dealer. Contact information can typically be found on the eSSL official webسائيٽ تي يا توهان جي پراڊڪٽ پيڪنگنگ تي.

When contacting support, please have your product model (KartString Biomax K 21) and any relevant purchase details ready.
