NET0007 Power Strip 4-Way
Instructions
Product information
Power strip 4-way
With this SCHWAIGER® socket strip, you can easily extend a standard household wall socket to 4 Schuko sockets. This way, up to 4 electrical appliances can be supplied with power at the same time. The power strip also has an illuminated on/off switch that allows you to easily avoid unnecessary power consumption of devices in standby mode. The visually appealing flat plug disappears completely into the socket without protruding and can easily be removed again thanks to the ring-shaped plug handle.
FEATURES (NET0007)
- For connecting up to 4 electrical appliances simultaneously
- With a ring-shaped plug handle for easy removal from the socket outlet
- With increased contact protection
- Available in the colors black, red, and matt gold
- with a power-saving toggle switch for switching on and off
- convenient flat plug
- for extending a 230 V socket
- Scope of delivery: power strip
TECHNICAL DATA
| Connections | 1x Schuko plug (type F) 4x Schuko socket (type F) |
| Power supply | 250 V AC, 50 Hz |
| Output current | 16 A |
| Output power | (max.) 3680 W |
| Point of use | indoor use |
| Protection class | IP20 |
| Form of cable | H05VV-F 3G 1.5 mm² |
| Cable length | 1.5 m |
| Colour | White/Golden |
| Weight (set) | 420 g |
| Dimensions (width) | 270 mm |
| Dimensions (height) | 42 mm |
| Dimensions (depth) | 52 mm |
| Packaging | shrink foil |
Schwaiger GmbH Würzburger Str. 17 90579 Langenzenn
Tel. +49 (09101) 702-0
Fax +49 (09101) 702-196
www.schwaiger.de
info@schwaiger.de
Errors, variations, and changes concerning technical data and illustrations are subject to change.
Our General Terms and Conditions for the Supply of Goods and Services apply.
