RGBlink Q16 Pro Multi-Window Splicing Processor for LCD and LED Video Wall
Specification
| Model | Q16pro 2U (preliminary) | Q16pro 4U | Q16pro 8U (preliminary | Q16pro 14U (preliminary) | |||
| Specification | 2U | 4U | 8U | 14U | |||
| Input Slots | 3 | 4 | 10 | 20 | |||
| Output Slots | 2 | 4 | 10 | 20 | |||
| Shared Slots | nonsupport | Output slot No.1~No.4 | Output slot No.1~No.8 | Output slot No.1~No.18 | |||
| Physical | Net Weight | 6.0kg | 8.5kg | 15.0kg | 20.0kg | ||
| Package Weight | 9.7kg | 12kg | 15.0kg | 20.0kg | |||
| Net Dimension | 483.4x377x89mm | 630mm x 585mm x 250mm | 4665×525×495mm | 665×525×495mm | |||
| Physical | Input Connectors | Optional | DVI (preliminary) | 4×DVI-I（Compatible HDMI/DVI/VGA/YPbPr/CVBS） | SDI (SD/HD/3G) (preliminary) | 8×BNC(4 In |4 Loop) | |
| DVI (preliminary) | 4×DVI-I | HDBaseT (preliminary) | 4xRJ45 | ||||
| HDMI 1.3 | 4×HDMI-A | H.265 (preliminary) | 2×RJ45 | ||||
| DP1.2 | HDMI2.0 (preliminary) | 2×DP | 2×HDMI-A | ||||||
| Output Connectors | Optional | DVI (preliminary) | 4×DVI-I （Compatible VGA） | HDMI2.0 (preliminary) | 2×HDMI-A | ||
| HDMI1.3 | 4×HDMI-A | HDBaseT (preliminary) | 4×RJ45 | ||||
| SDI (preliminary) | 4×BNC | ||||||
| Communication | Optional | Genlock | 2×BNC（1 In | 1 Loop) | LAN | 1×RJ45 | ||
| Connectors | RS232 | 1×RJ11 | PVW | 1×HDMI-A | |||
| PVW Connectors | Optional | HDMI | 2×HDMI-A | Dante | 1xRJ45 | ||
| Dante Backup | 1xRJ45 | ||||||
| Connectors | Input | Select from below or configure customized | |||||
| Resolutions | HDBaseT | ||||||
| SMPTE | 720p@50/60|1080p@30/50/60 | ||||||
| VESA | 800×600@60 | 1024×768@60 | 1280×768@60 | 1280×1024@60 | 1600×1200@60 | 1920×1080@60 | ||||||
| H.264/H.265 | |||||||
| SMPTE | 720p@50/60|1080p@30/50/60|2160p@30 | ||||||
| DVI | HDMI 1.3 | |||||||
| SMPTE | 720p@50/60|1080p@30/50/60 | ||||||
| VESA | 800×600@60 | 1024×768@60 | 1280×720@60 | 1280×800@60 | 1280×1024@60 | 1360×768@60 | 1366×768@60 | 1440×900@60 | 1400×1050@60 | 1600×1200@60 | 1680×1050@60 | 1920×1080@60 |
||||||
| SDI (SD/HD/3G) | |||||||
| SMPTE | 720p@50/60 | 1080p@23.94/24.97/25/30/50/60| 1080i@50/60 | ||||||
| DP 1.2 | HDMI 2.0 | |||||||
| SMPTE | 720p@50/60|1080p@30/50/60|2160p@60 | ||||||
| VESA | 800×600@60 | 1024×768@60 | 1280×720@60 | 1280×800@60 | 1280×1024@60 | 1360×768@60 | 1366×768@60 | 1440×900@60 | 1400×1050@60 | 1600×1200@60 | 1680×1050@60 | 1920×1080@60 | 1920×1200@60 | 3840×2160@30/60 |
||||||
| Output | Select from below or configure customized | ||||||
| Resolutions | DVI | HDMI1.3 | ||||||
| SMPTE | 720p@50/60 | 1080p@30/50/60 | ||||||
| VESA | 1024×768@60 |1280×1024@60 | 1920×1080@25/30/50/59.94/60 | ||||||
| SDI (SD/HD/3G) | |||||||
| SMPTE | 720p@50/60 | 1080p@23.98/29.97/25/30/50/59.94/60 | 1080i@50/59.94/60 | ||||||
| HDMI2.0 | |||||||
| SMPTE | 720p@50/60 | 1080p@30/50/60 | 2160p@30/60 | ||||||
| VESA | 1024×768@60 | 1280×720@60 | 1280×768@60 | 1280×800@60 | 1280×1024@60 | 1360×768@60 | 1440×900@60 | 1920×1200@60 | 3840×570@60 | 2560×1600@60/120 | 3840×2160@30/60 |
||||||
| Supported | SDI | 3G | H.265 | H.265 | DVI | DVI-1.0 | |
| Standard | HDMI | 2.0 | HDBaseT | 1.0 | DP | 1.2 | |
| Power | Input Voltage | AC 100V-240V, 50/60Hz ( 2U supports single power supply module, 4U and above supports double power supply module.) | |||||
| Working | Temperature | 0℃～45℃ | |||||
| Environment | Humidity | 15%~85%, RH | |||||
| Working | Temperature | 0℃～55℃ | |||||
| Environment | Humidity | 5%~85%, RH | |||||
Order Codes
| Product Code | Item |
| 710-1002-06-0 | Q16pro 2U (preliminary) |
| 710-1002-01-1 | Q16pro 4U (Communication Module Included) |
| 710-1002-01-0 | Q16pro 4U (Communication Module with PVW Included) |
| 710-1002-07-0 | Q16pro 8U (preliminary) |
| 710-1002-08-0 | Q16pro 14U (preliminary) |
| 790-1002-01-0 | Q Series Quad HDMI 1.3 Input Module |
| 790-1002-02-0 | Q Series Single IP Input Module (preliminary) |
| 790-1002-03-0 | Q Series Quad HDMI 2.0 & DP 1.2 Input Module (preliminary) |
| 790-1002-04-0 | Q Series Quad 3G SDI (LOOP) Input Module (preliminary) |
| 790-1002-05-0 | Q Series Quad DVI Input Module (preliminary) |
| Product Code | Item |
| 790-1002-21-0 | Q Series Quad HDMI 1.3 Output Module |
| 790-1002-22-0 | Q Series Communication Module with PVW |
| 790-1002-23-0 | Q Series Dual HDMI 2.0 Output Module (preliminary) |
| 790-1002-24-0 | Q Series Communication Module |
| 790-1002-25-0 | Q Series Quad 3G SDI Output Module (preliminary) |
| 790-1002-26-0 | Q Series Quad DVI Output Module (preliminary) |
| 790-1002-27-0 | Q Series Single IP Output Module (preliminary) |
| 790-1002-30-0 | Q Series PVW Module with Dante (preliminary) |
| 950-0014-01-0 | Q Series 250W Redundant Power Module |
Dimensions
Proudly designed and manufactured in Xiamen Hi Technology Zone, China
WEB: www.rgblink.com
EMAIL: sales@rgblink.com
PHONE: +86 592 5771197
Q16pro is a high-performance video image processing system and high-performance video splicing server using pure hardware and leading-edge FPGA processing architecture. Offering a range of input and output signals via a card-based structure, and supporting hot swap of modules, and options including redundant power supplies, Q16pro is a stable high-performance platform that can be deployed in varied applications including corporate and visual messaging as well in retail and digital signage applications The Q16pro models allow connection of 4K video sources as well as output to 4K, with outputs offering multi-screen and multi-layer capabilities. A host of features are built in to Q16pro, including EDID management, 3D image processing, and highly configurable OSD features at high-definition.
Multi- Layer Multi-Window
Q16pro offers up to 8 2K windows or four 4K windows per output slot. Layer resources able to be freely used across any of the outputs within a slot for maximum availability and efficiency, including combinations of both 2K and 4K layer windows. Q16pro layering allows multi-window applications for large scale and spanning multiple display outputs.
Frame Sizes for Every Scale
Q16pro models range from the compact 2U through to 14U with up to 80 inputs and 80 outputs with common modules across the range. Q16pro is truly scalable for even the largest applications .
Take Control
Configure and control Q16pro devices from the acclaimed RGBlink XPOSE apps for laptop/desktop and mobile devices.
Input and output preview
Equipped with 2 high-definition multi-screen monitoring output interfaces, it can monitor 16 input or 16 output at the same time. Among them, 16 input source preview supports 4/9/16 screen division.
Dual network communication
Supports dual network communication: it has 1 local communication network port and 1 remote control port. In addition to remote control, the remote control port also has H.265 media remote control and monitoring functions.
OSD Dynamic Titles
Customised text in almost any format can be overlayed on output displays. The facility supports static and dynamic arrangements including scrolling messaging.
3D stitching
Scale and deliver 3D signals for 120Hz interpolated signals with internal frame-lock synchronization. Segmentation and fusion are completely seamless. Single key switching is available to transition between 2D and 3D on demand.
Dante volume monitoring
Dante audio technology integrates the media and control of your entire system into a standard network, and realizes real-time volume monitoring of 16 channels and 32 channels. Eliminates bulky and expensive analog wiring and replaces it with cheap and very common CAT5e, CAT6 wires for a simple, lightweight and economical solution
High Performance Lossless 4K Processing
Q16pro not only supports HDMI 2.0 and DisplayPort 1.2 4K@60 signals and is engineered end-to-end to maintain and enhance fidelity with full 4:4:4 maintained throughout. Utilizing advanced processing engine developed RGBlink.
Modular Hybrid Modules
The processor offers a range of input and output modules, with signals able to be mixed-and-matched to meet requirement without in incurring overhead. Modules are easily user-fit lowering TCO and simplifying operations of Q16pro based installations.
Configurable Audio Delivery
Both embedded and external/insert audio sources may be embedded to any output as well as be switched a part of video presets.
