QUICK START
POLY ATA 402
CONTENTS
LED
Off: No Power
Solid green: Powered on and working
Flashing green: Searching for a OHCP IP address
Flashing orange: Upgrading (Do not unplug power.)
Solid red: Not operational
Flashing green (fast blinking): Data activity on the LAN Ethernet port
Flashing green (fast blinking): Data activity on the PC Ethernet port
Off: Port service not available Solid green: Phone ready (standby) Flashing green: Phone in use
YOU WILL NEED
- Touch-tone phone
- Active Internet connection
- Access to the Internet via an Ethernet port on your router or modem
- (Optional) Internet phone service subscription
- (Optional) To wall-mount the ATA 402 device, two 5 mm (3/16 in.) screws and anchors (not supplied)
ATA system web interface
- From a phone attached to the ATA device, dial *** to access the ATA config attendant.
- Choose 1 to hear the IP address of the ATA device.
- Enter the ATA device IP address in a local PC web browser.
- When prompted, enter admin for the user name and admin for the password.
CABLING
poly.com/support/ata-402
HP EU
HP Deutschland, GmbH, HQ-Technical Regulations
Schickardstr. 32, 71025 Boeblingen, Germany
HP Inc UK Ltd.
Regulatory Enquiries, Earley West,
300 Thames Valley Park Drive,
Reading, RG6 1PT, England
Recyclable where facilities exist
© 2023 Poly. All trademarks are the property of their respective owners.
