1. Konfiguracja
1.1 Rozpakowanie i początkowe rozmieszczenie
Upon receiving your KNKA D032 Dehumidifier, carefully remove it from its packaging. Ważny: Before first use, allow the dehumidifier to stand upright for 24 hours. This ensures the internal components, particularly the refrigerant, settle correctly for optimal performance and reliability.
1.2 Połączenie zasilania
Connect the power cord to a suitable electrical outlet. Ensure the voltage odpowiada wymaganiom urządzenia.
1.3 Water Tank and Continuous Drainage Setup
The dehumidifier offers two drainage methods: using the removable water tank or continuous drainage via a hose.
- Opróżnianie zbiornika wody: The unit features a visible 1.7-liter water tank. When the tank is full, the dehumidifier will automatically shut off and an indicator light will illuminate. Remove the tank, empty the water, and reinsert it securely.
- Drenaż ciągły: For long-term operation without manual emptying, attach the included 65 cm drainage hose to the continuous drainage port at the back of the unit. Ensure the hose is positioned to drain water into a suitable receptacle or floor drain.
Wideo 1: Overview of the KNKA D032 Dehumidifier, demonstrating its unpacking, setup, and basic operation, including power connection and drainage options.
2. Instrukcja obsługi
2.1 Panel sterowania ponadview
The dehumidifier features a digital control panel for easy operation. Familiarize yourself with the buttons and display indicators.
2.2 Włączanie/wyłączanie zasilania
Naciśnij przycisk „Zasilanie”, aby włączyć lub wyłączyć urządzenie.
2.3 Setting Humidity Levels
Use the 'Humidity' button to set your desired humidity level between 30% and 80% RH. The unit will automatically maintain this level.
2.4 tryby pracy
- Tryb automatyczny: Maintains humidity between 45% and 65% RH. The LED indicator changes color based on current humidity: Blue (<45% RH), Green (45%-65% RH), Red (>65% RH).
- Tryb uśpienia: Operates at a low noise level with all indicator lights turned off to ensure undisturbed sleep.
- Tryb suszenia prania: Accelerates clothes drying by maintaining humidity between 35% and 40% RH with high fan speed.
2.5 Funkcja timera
Set the 24-hour timer to schedule when the dehumidifier turns on or off, ensuring a dry environment when needed.
2.6 Regulacja prędkości wentylatora
Adjust the fan speed (low/high) to suit your preference and the room's humidity level.
2.7 Blokada dziecięca
Activate the child lock feature to prevent accidental changes to settings. Press and hold the 'Lock' button for 3 seconds to engage or disengage.
3. Główne cechy
3.1 Automatyczne odszranianie
The automatic defrost function ensures stable operation even in cooler temperatures, making the unit suitable for year-round use without performance degradation.
3.2 Przenośność
Designed for easy movement, the dehumidifier is compact (smaller than A4 paper) and features an integrated handle and removable 360° swivel casters. Anti-slip pads provide stability when placed.
4. Konserwacja
4.1 Opróżnianie zbiornika na wodę
Regularly empty the water tank when the 'Water Full' indicator illuminates. Slide out the tank, discard the collected water, and slide it back into place until it clicks securely.
4.2 Czyszczenie filtra
The removable filter and 90° adjustable dust cover help prevent dust accumulation. Clean the filter regularly to maintain optimal dehumidification efficiency. Refer to the detailed cleaning instructions in the full manual for best practices.
5. Rozwiązywanie Problemów
- Appliance Not Functioning:
- Check if the child lock is activated. Press and hold the 'Lock' button for 5 seconds to deactivate.
- Ensure the water tank is correctly installed and not full. Empty and re-install if necessary.
- If the target humidity is lower than the ambient humidity, the unit may temporarily stop.
- In Smart Mode, only fixed settings are possible. For adjustable humidity and fan speed, use Normal Mode.
- Liquid or Oil Odor in Packaging: If the appliance was laid flat during prolonged transport, condensation may have leaked. Allow the unit to stand upright for 24 hours before first use. If the issue persists, contact customer service with a short video and photos.
- Ineffective Dehumidification: Ensure all doors and windows in the room are closed during operation.
- Włączona czerwona kontrolka: This indicates one of three conditions:
- Zbiornik na wodę jest pełny.
- Water tank is incorrectly installed.
- Humidity is above 65% RH.
- Missing Casters and Anti-slip Mat: These accessories are located inside the water tank. Remove them before using the tank.
6. Specyfikacje
| Funkcja | Specyfikacja |
|---|---|
| Marka | KNKA |
| Numer modelu | D032 |
| Kolor | Biały |
| Wymiary produktu (dł. x szer. x wys.) | Wymiary 22.86 x 29.21 x 38.1 cm |
| Waga przedmiotu | 7.44 kilograma |
| Pojemność | 9 litrów na dzień |
| Moc | 150 watów |
| Tworzywo | Akrylonitryl-butadien-styren (ABS) |
| Funkcja automatycznego wyłączania | Tak |
| Liczba prędkości | 2 |
| Pojemność zbiornika na wodę | 1.7 litrów |
| Zalecany obszar użytkowania | Do 25 m² (60 m³) |
| Cechy specjalne | 24-hour timer, automatic defrost, energy-efficient design, memory function, water tank full alarm, child safety lock, touch control, digital display, integrated plug/cable storage, 90° dust cover, removable filter, integrated carry handle, 360° swivel casters with anti-slip pads, dual drainage methods. |
7. Gwarancja i wsparcie
KNKA offers professional technical support for your dehumidifier. If you have any questions or require assistance, please follow these steps:
- Zaloguj się na swoje konto Amazon.
- Navigate to 'My Orders'.
- Locate your order for the KNKA D032 Dehumidifier.
- Click on 'Contact Seller'.
Our support team is ready to assist you with any inquiries or issues you may encounter.
