IMOU LOOC C26E/IPC-C26E Outdoor Wi-Fi Security Camera User Manual

1. Inleiding

This manual provides detailed instructions for the installation, operation, and maintenance of your IMOU LOOC C26E/IPC-C26E Outdoor Wi-Fi Security Camera. Please read this manual carefully before using the product and retain it for future reference. The IMOU LOOC C26E is designed for outdoor surveillance, offering 2MP resolution, Wi-Fi connectivity, and advanced features for enhanced security.

2. Product voorbijview

2.1 Pakketinhoud

The IMOU LOOC C26E/IPC-C26E package includes the following items:

• 1 x IMOU LOOC C26E/IPC-C26E Camera
• 1 x Snelstartgids (QSG)
• 1 x Stroomadapter
• 1 x montagebeugel
• 1 x Schroevenset (voor montage)
• 1 x Position Card (for drilling template)
• 1 x Cable Clip Pack

2.2 Camerafuncties

The IMOU LOOC C26E/IPC-C26E camera offers a range of features to ensure comprehensive outdoor surveillance:

• 2 Megapixel (MP) Resolution: Provides clear 1080p video recording.
• Integrated Microphone and Speaker: Maakt tweerichtingsaudiocommunicatie mogelijk.
• Wi-Fi-connectiviteit: Voor draadloze netwerkverbinding.
• IP65 weerbestendig ontwerp: Ensures reliable operation in various outdoor conditions.
• Infrarood (IR) nachtzicht: Up to 10 meters (33 feet) for clear visibility in complete darkness.
• PIR-bewegingsdetectie: Passive Infrared sensor reduces false alarms by detecting heat signatures.
• White LED Alarm: Activates upon motion detection to deter intruders.
• Ingebouwde sirene: A 110 dB siren can be triggered to scare away unwanted visitors.
• MicroSD-kaartsleuf: Supports local storage up to 128GB (MicroSD card not included).

Figure 2.2.1: IMOU LOOC C26E/IPC-C26E Outdoor Wi-Fi Security Camera. This image shows the overall design of the camera, highlighting its compact and robust build suitable for outdoor use.

3. Installatiehandleiding

3.1 Voordat u begint

• Zorg ervoor dat je wifi-netwerk 2.4 GHz is. De camera ondersteunt geen 5 GHz wifi.
• Zorg dat u de naam van uw Wi-Fi-netwerk (SSID) en wachtwoord bij de hand hebt.
• Download the IMOU Life app from your smartphone's app store (iOS or Android).
• Kies een geschikte montagelocatie die een duidelijk zicht biedt view en bevindt zich binnen het wifi-bereik.

3.2 Eerste camera-instellingen

1. Inschakelen: Connect the camera to the power adapter and plug it into an electrical outlet. The camera's indicator light will turn on.
2. App-installatie: Open the IMOU Life app on your smartphone and create an account or log in.
3. Apparaat toevoegen: Tik op het "+" pictogram in de app om een ​​nieuw apparaat toe te voegen. Scan de QR-code op de camera of de verpakking.
4. Netwerk configuratie: Follow the on-screen prompts in the app to connect the camera to your Wi-Fi network. Ensure your phone is connected to the same 2.4 GHz Wi-Fi network.
5. Apparaatnaam: Assign a name to your camera (e.g., "Front Door Camera", "Backyard Camera").

3.3 De camera monteren

The camera is designed for wall or ceiling mounting. Use the provided mounting bracket and screw pack.

1. Positionering: Hold the position card against the desired mounting surface and mark the screw holes.
2. Boren: Drill pilot holes at the marked positions. Insert wall anchors if mounting on masonry.
3. Bevestig de beugel: Bevestig de montagebeugel met de meegeleverde schroeven aan het oppervlak.
4. Camera bevestigen: Mount the camera onto the bracket and adjust its angle for optimal viewing. Ensure the camera is securely fastened.
5. Kabelbeheer: Use the cable clips to neatly route the power cable, protecting it from damage and weather elements.

4. Gebruiksaanwijzing

4.1 Levend View en afspelen

• Live View: Open the IMOU Life app and select your camera to view de live-feed.
• Afspelen: Toegang tot opgenomen footage from the app. Recordings are triggered by motion detection and stored on the MicroSD card (if installed) or cloud storage (if subscribed).

4.2 Bewegingsdetectie en waarschuwingen

Figure 4.2.1: Smart Motion Detection. The camera utilizes PIR technology to detect human-like motion, reducing false alarms from environmental factors. When motion is detected, the camera can send instant alerts to your smartphone.

• Bewegingsdetectie inschakelen: In the IMOU Life app settings for your camera, enable motion detection.
• Gevoeligheid aanpassen: Customize the motion detection sensitivity to minimize false alarms. The PIR sensor helps in accurate detection.
• Detectiezones instellen: Definieer specifieke gebieden binnen de camera view waar bewegingsdetectie actief moet zijn.
• Ontvang waarschuwingen: The app will send push notifications to your smartphone when motion is detected.

4.3 Tweewegcommunicatie

The integrated microphone and speaker allow for two-way communication:

• Start het gesprek: terwijl in leven view, tap the microphone icon in the IMOU Life app to speak through the camera's speaker.
• Luisteren: De microfoon van de camera vangt omgevingsgeluiden op, die je vervolgens via je smartphone kunt horen.

4.4 Nachtzicht

De camera schakelt automatisch over naar de nachtzichtmodus bij weinig licht, waardoor er duidelijke zwart-witfoto's worden gemaakt.tage up to 10 meters (33 feet) using its IR LEDs.

4.5 Actieve afschrikking

Upon detecting motion, the camera can activate its built-in white LED light and 110 dB siren to deter potential intruders. This feature can be configured in the IMOU Life app settings.

5. Onderhoud

5.1 Reinigen

• Regularly clean the camera lens with a soft, dry cloth to ensure optimal image quality.
• Gebruik geen agressieve chemicaliën of schurende reinigingsmiddelen.

5.2 firmware-updates

• Periodically check for firmware updates via the IMOU Life app. Updates often include performance improvements and security enhancements.
• Ensure the camera has a stable power supply and internet connection during firmware updates.

Figure 5.3.1: IP65 Weatherproof Design. The camera is built to withstand outdoor elements, including rain and dust, ensuring continuous operation in various weather conditions.

5.3 Bescherming tegen weersinvloeden

While the camera is IP65 rated for weather resistance, ensure its power connections are protected from direct exposure to heavy rain or prolonged moisture to prevent damage.

6. Probleemoplossing

6.1 Connectiviteitsproblemen

• Camera offline: Check if the camera is powered on and if your Wi-Fi router is working correctly. Ensure the camera is within range of your Wi-Fi signal.
• Verbinding met wifi mislukt: Verify your Wi-Fi password. Ensure your router is broadcasting a 2.4 GHz network. Try resetting the camera and repeating the setup process.

6.2 Problemen met bewegingsdetectie

• Geen bewegingswaarschuwingen: Check if motion detection is enabled in the app and if notification permissions are granted for the IMOU Life app on your phone.
• Te veel valse alarmen: Adjust the motion detection sensitivity settings in the app. Define specific detection zones to exclude areas with frequent irrelevant motion (e.g., trees swaying).

6.3 Problemen met de beeldkwaliteit

• Wazig beeld: Maak de cameralens schoon. Zorg ervoor dat er geen obstakels voor de lens zitten.
• Slecht nachtzicht: Ensure the IR LEDs are not obstructed. Check for reflective surfaces close to the camera that might interfere with IR illumination.

7. Specificaties

8. Garantie en ondersteuning

IMOU cameras are guaranteed by Dahua TP and are subject to their RMA (Return Merchandise Authorization) warranty policy. This process is designed to facilitate and expedite any necessary repairs or replacements.

For detailed warranty information, technical support, or service requests, please refer to the official IMOU webwebsite of neem rechtstreeks contact op met hun klantenservice. Bewaar uw aankoopbewijs als aankoopbewijs voor garantieclaims.

Opmerking: These devices do not have a WEB interface. The IMOU series records data only after motion detection (no continuous recording). Recordings typically last 1 to 1.5 minutes, depending on the duration of motion in front of the camera.
