1. ഉൽപ്പന്നം കഴിഞ്ഞുview
The NPYSVSSS 4-Way Shower Diverter Thermostatic Valve is designed to provide a superior showering experience with precise temperature control and multi-functionality. Constructed from high-quality brass with a durable tempered glass panel, this concealed mixing valve ensures longevity and ease of maintenance.
പ്രധാന സവിശേഷതകൾ:
- Upgraded Shower Valve Kit: Features a tempered glass panel for easy cleaning and high-quality brass construction for durability.
- Thermostatic Shower Mixing Valve: Offers precise temperature control, safely stopping at 102°F (39°C) to prevent scalding, ideal for families with children or the elderly.
- ഉയർന്ന നിലവാരമുള്ള വസ്തുക്കൾ: Made from solid brass with a multi-layer finish, meeting or exceeding industry standards.
- Maximum Installation Flexibility: Equipped with 1/2" connections and G 1/2 to NPT 1/2 adapters, with detachable water stop fittings for versatile pipeline installation.
2. സജ്ജീകരണവും ഇൻസ്റ്റാളേഷനും
Proper installation is crucial for the optimal performance and safety of your shower diverter. It is recommended that installation be performed by a qualified professional.
ഇൻസ്റ്റലേഷൻ വീഡിയോ ഗൈഡ്:
This video demonstrates the installation process for the 4-way shower diverter thermostatic valve, including component assembly and connection details.
ഘടകം കഴിഞ്ഞുview കൂടാതെ അളവുകൾ:
This image illustrates the main valve body, the tempered glass panel, and the individual control knobs, along with key dimensions for installation planning.
Recommended Piping Installation:
Refer to this diagram for recommended piping configurations, including hot and cold water inlets (NPT 1/2") and four outlets for various shower functions (G 1/2 to NPT 1/2 adapters included).
3. പ്രവർത്തന നിർദ്ദേശങ്ങൾ
Your NPYSVSSS shower diverter allows for simultaneous control of water flow and temperature across multiple shower functions.
Multi-Function Control:
The valve supports up to four functions: rainfall, spray, handheld, and body jets. Each function can be activated and adjusted independently using its dedicated knob. Water flow can be adjusted for each outlet.
Thermostatic Temperature Control:
The thermostatic mixing valve maintains a constant water temperature, preventing sudden changes. To adjust the hot water temperature above the preset 100°F (39°C) safety limit, press the safety button on the temperature control knob and rotate. This feature ensures a safe and comfortable shower.
4. പരിപാലനം
Regular cleaning and proper care will ensure the longevity and aesthetic appeal of your NPYSVSSS shower diverter.
Cleaning the Tempered Glass Panel:
The tempered glass panel is designed to be resistant to dirt and easy to clean. Use a soft cloth and mild, non-abrasive cleaner to wipe the surface. Avoid harsh chemicals or abrasive sponges that could scratch the glass or damage the finish.
Brass Valve Body:
The valve body is made from high-quality brass, which is resistant to corrosion and designed for a long service life. Ensure all connections are secure to prevent leaks. In case of any issues, consult a professional plumber.
5. പ്രശ്നപരിഹാരം
പൊതുവായ പ്രശ്നങ്ങൾക്കുള്ള പൊതുവായ മാർഗ്ഗനിർദ്ദേശം ഈ വിഭാഗം നൽകുന്നു. സങ്കീർണ്ണമായ പ്രശ്നങ്ങൾക്ക്, ദയവായി ഉപഭോക്തൃ പിന്തുണയുമായി ബന്ധപ്പെടുക.
- കുറഞ്ഞ ജല സമ്മർദ്ദം: Check your home's main water supply and ensure all shut-off valves are fully open. Verify that the water stop fittings are completely removed if not needed for your installation.
- പൊരുത്തപ്പെടാത്ത ജല താപനില: Ensure the thermostatic control knob is set correctly. If the issue persists, there might be an imbalance in hot/cold water pressure or a need for professional inspection of the thermostatic cartridge.
- ചോർച്ച: Inspect all connections for tightness. If leaks persist, professional assistance may be required to check internal seals or cartridges.
6 സ്പെസിഫിക്കേഷനുകൾ
| ഫീച്ചർ | വിശദാംശങ്ങൾ |
|---|---|
| മെറ്റീരിയൽ | പിച്ചള |
| ബ്രാൻഡ് | NPYSVSSS |
| എക്സ്റ്റീരിയർ ഫിനിഷ് | Brass, Nickel (Polished Chrome variant) |
| ഇൻലെറ്റ് കണക്ഷൻ തരം | National Pipe Tapered (NPT 1/2") |
| ഔട്ട്ലെറ്റ് കണക്ഷൻ തരം | G 1/2 to NPT 1/2 |
| പരമാവധി പ്രവർത്തന സമ്മർദ്ദം | 145.04 പി.എസ്.ഐ |
| തുറമുഖങ്ങളുടെ എണ്ണം | 4 |
| ഇനത്തിൻ്റെ ഭാരം | 16.29 പൗണ്ട് |
| പാക്കേജ് അളവുകൾ | 20.5 x 9 x 7.25 ഇഞ്ച് |
| ഇനം മോഡൽ നമ്പർ | NPY-002 |
| വലിപ്പം | 4-വഴി |
| നിറം | പോളിഷ് ചെയ്ത Chrome |
| ആകൃതി | ദീർഘചതുരം |
7. വാറൻ്റി വിവരങ്ങൾ
NPYSVSSS provides a 2-year free replacement valve core and accessories warranty. This warranty covers manufacturing defects and ensures that replacement parts are available if needed.
Please retain your proof of purchase for warranty claims. The image indicates a 5-year warranty period, but the product specifications state a 2-year warranty for valve core and accessories. Please refer to the specific warranty details provided with your product packaging for the most accurate information.
8. ഉപഭോക്തൃ പിന്തുണ
If you have any questions, require assistance with installation, or need to make a warranty claim, please do not hesitate to contact us.
ഇമെയിൽ: NPYSVSSS@126.COM
We are committed to providing prompt and active support to resolve any issues you may encounter.
