TSK HD-002 Eyeglass Loupe User Manual

ആമുഖം

This manual provides detailed instructions for the proper use, setup, operation, and maintenance of your TSK HD-002 Eyeglass Loupe.

The HD-002 is designed to provide enhanced magnification for various tasks, featuring multiple interchangeable lenses and integrated LED illumination. It comes equipped with 2 LED lights for excellent workability and five types of interchangeable lenses (1.0X, 1.5X, 2.0X, 2.5X, 3.5X) to suit different magnification needs. The LED light's angle can be adjusted for optimal illumination.

ഉൽപ്പന്ന ഘടകങ്ങൾ

Familiarize yourself with the main components of your TSK HD-002 Eyeglass Loupe:

• Eyeglass frame with integrated LED lights
• Interchangeable magnification lenses (1.0X, 1.5X, 2.0X, 2.5X, 3.5X)
• Battery compartment (for LR44 batteries)
• Lens slot
• LED light adjustment mechanism

ചിത്രം 1: ഓവർview of the TSK HD-002 Eyeglass Loupe, showing the main frame and an attached lens.

ചിത്രം 2: വശം view illustrating the adjustable LED lights and the battery compartment on the frame.

സജ്ജമാക്കുക

1. ബാറ്ററി ഇൻസ്റ്റാളേഷൻ

The TSK HD-002 requires 3 LR44 batteries (included). Follow these steps to install or replace batteries:

1. Locate the battery compartment on the side of the eyeglass frame.
2. ബാറ്ററി കവർ പതുക്കെ സ്ലൈഡ് ചെയ്ത് തുറക്കുക.
3. Insert 3 LR44 batteries, ensuring correct polarity (+/-) as indicated inside the compartment.
4. ബാറ്ററി കവർ സുരക്ഷിതമായി അടയ്ക്കുക.

2. ലെൻസ് അറ്റാച്ച്മെന്റ്

Select the desired magnification lens (1.0X, 1.5X, 2.0X, 2.5X, or 3.5X) based on your task. To attach a lens:

1. Hold the eyeglass frame firmly.
2. Align the chosen lens with the lens slot on the frame.
3. Gently slide the lens into the slot until it clicks into place.

Figure 3: Illustration of the lens attachment mechanism, showing a lens being inserted into the frame.

പ്രവർത്തന നിർദ്ദേശങ്ങൾ

1. Wearing the Loupe

Place the eyeglass loupe on your head like regular eyeglasses. Ensure it sits comfortably and securely.

2. LED ലൈറ്റുകൾ ക്രമീകരിക്കൽ

The HD-002 features two adjustable LED lights. To turn them on/off and adjust their angle:

• Locate the power switch for the LEDs on the frame.
• Toggle the switch to turn the lights on or off.
• Gently pivot the LED light modules up or down to direct the illumination onto your working area.

Figure 4: A user demonstrating the use of the eyeglass loupe, highlighting the illuminated field of view.

3. Changing Magnification Lenses

To change the magnification, gently slide out the currently installed lens from the slot and replace it with another lens of your desired magnification (1.0X, 1.5X, 2.0X, 2.5X, or 3.5X).

മെയിൻ്റനൻസ്

വൃത്തിയാക്കൽ

• Use a soft, lint-free cloth (e.g., microfiber cloth) to clean the lenses.
• For stubborn smudges, a small amount of lens cleaning solution can be applied to the cloth, not directly to the lens.
• പരസ്യം ഉപയോഗിച്ച് ഫ്രെയിം തുടയ്ക്കുകamp cloth if necessary, avoiding direct contact with electronic components.
• ഉരച്ചിലുകളുള്ള ക്ലീനറുകളോ ലായകങ്ങളോ ഉപയോഗിക്കരുത്.

സംഭരണം

When not in use, store the eyeglass loupe and its lenses in a clean, dry place, preferably in a protective case to prevent scratches and dust accumulation.

ബാറ്ററി മാറ്റിസ്ഥാപിക്കൽ

Replace the LR44 batteries when the LED lights dim or stop functioning. Refer to the "Battery Installation" section under Setup for instructions.

ട്രബിൾഷൂട്ടിംഗ്

സ്പെസിഫിക്കേഷനുകൾ

വാറൻ്റിയും പിന്തുണയും

Information regarding product warranty and customer support was not available in the provided data. For warranty details, technical support, or service inquiries, please refer to the official TSK webസൈറ്റ് അല്ലെങ്കിൽ നിങ്ങളുടെ റീട്ടെയിലറെ ബന്ധപ്പെടുക.

നിർമ്മാതാവ്: TSK (ティ・エス・ケイ)
