matt E IP-EVCP-T Single Phase Voltage Monitoring and Protection Device
Important Information
Single-phase Voltage monitoring and protection device with built-in isolator in an IP65 enclosure
The matt:e IP-EVCP connection centres provide a simple to install dedicated EV connection centre, with unique built-in PEN fault protection, that allows for the connection of EV charge points to the PME earthing facility without the use of earth electrodes.
Helping to facilitate compliance with BS:7671. 2018 Amendment 1, 2020 Regulation 722.411.4.1.(iv).
The units are available with the additional functionality for load curtailment in line with Regulation 722.311.201, isolating the charge point from the supply once the house consumption rises above the pre-set limit and automatically restores the power to the charge point when the load falls back within a satisfactory level.
Product Features and benefits
- Built in matt:e technology
- NO EARTH ELECTRODES REQUIRED
- Helps reduce disruptive and costly groundworks
- Removes the risk of striking buried services
- Simple wire in wire out connection
- Optional Load management with hard wired CT
- Built in double pole isolator
- IP65 enclosure
- Standard 3 Year parts warranty
- Designed and built in the UK
| Description | Single-phase Voltage Monitoring and Protection Unit |
| Max Load | 32 amps |
| Terminal Capacity | In L/N: 2.5mm2 -25mm2 E: 2.5mm2 —16mm2 Out L/N 2.5mm2 – 10mm2 E: 2.5mm2 – 10mm2 |
| Dimensions ( H x W x D ) | 300mm x 200mm x 129mm |
| Weight | Approximately 3kG |
| Enclosure | ABS-HB Flame Retardant Plastic |
| Ingress Protection | IP65 |
Customer Support
t: 01543 227290 e: info@matt-e.co.uk w: www.matt-e.co.uk
matt:e Ltd, Unit 5 Common Barn Farm Tamworth Road Lichfield WS14 9PX
…Simplifying EV connection
