PowMr POW-LIO51400-16S Stacked Lithium Iron Phosphate Battery User Manual

1 Overview

1.1 Scope

This user manual provides information, operating instructions, and maintenance guidelines for the POW-LIO51400-16S low-voltage residential energy storage battery series. The POW-LIO51 residential energy storage series is a lithium battery system developed by PowMr, designed to be compatible with various inverter brands available in the market.

1.2 Intended Audience

This manual is intended for professional technical personnel involved in the installation, operation, and maintenance of lithium batteries, as well as end-users seeking technical information.

1.3 Manual Usage

1. Before using the product, carefully review this user manual and keep it in a readily accessible location.
2. All information in this user manual, including images and symbols, is proprietary to PowMr. Unauthorized use of any part or all of the content is strictly prohibited for individuals outside the company.
3. Considering the potential for updates and corrections to the manual content, users are advised to use the provided documentation as a reference. For the latest user manual, please refer to the product documentation provided or contact customer service through the official website.

2 Product Introduction

2.1 Introduction

1. The POW-LIO51 residential energy storage series is a battery module developed by PowMr Energy designed for low-voltage lithium battery systems, primarily applied in the home energy storage sector. It achieves high-precision multi-cell voltage and temperature acquisition.
2. The module employs passive balancing, with a maximum balancing current of 300mA, enhancing the overall lifespan of the battery pack.
3. The communication interfaces include CAN, RS485, and dry contact communication methods, enabling parallel communication for up to 16 batteries.
4. Featuring an embedded BMS system, it effectively monitors battery over-temperature, over-voltage, over-current, and other conditions, reducing the risk of battery damage or even fire, thereby ensuring personal and property safety.
5. This manual covers the types, sizes, performance, technical characteristics, warnings, and precautions of the lithium battery system. This specification is applicable exclusively to the battery systems provided by PowMr Energy.

3 Safety Instructions

3.1 Labeling Explanation

To ensure user safety during product use, relevant labeling information with appropriate symbols is provided in this manual. The following lists symbols that may be used in this manual, so please read carefully.

3.2 Installation Tools

Prior to installation, prepare the following tools:

3.3 Precautions

3.3.1 Manual Storage

1. This manual covers crucial information for the POW-LIO51 Home Energy Storage Series. Prior to operating the product, carefully read this manual as it provides essential assistance in acquainting you with the product.
2. Store this manual securely for the convenience of relevant installation and maintenance personnel to refer to during operations.
3. Strictly follow the descriptions in this manual when operating the PowMr Home Energy Storage Series to avoid equipment damage, injuries, property loss, and other potential issues.

3.3.2 Label Protection

1. Warning labels on the POW-LIO51 Home Energy Storage Series contain crucial safety operation information. It is strictly prohibited to intentionally tear or damage them!
2. The product has a nameplate on the casing, providing essential parameter information. It is strictly prohibited to intentionally tear or damage it!

3.3.3 Safety Warning Labels

When conducting installation, routine maintenance, inspections, etc., on the POW-LIO51 Home Energy Storage Series, to prevent unauthorized individuals from approaching, engaging in improper operations, or accidents, adhere to the following conventions:

1. Erect clear signage at the switch locations of the PowMr products to prevent accidents caused by accidental closing.
2. Set warning signs or establish safety warning tape near the operating area to prevent unrelated personnel from approaching.
3. After maintenance or inspection, conduct a thorough on-site safety check.

3.3.4 Personnel Requirements

1. Only personnel with relevant professional qualifications are allowed to perform various operations on this product.
2. Operating personnel should be thoroughly familiar with the composition and working principles of the entire POW-LIO51 Home Energy Storage Series system.
3. Operating personnel should be fully acquainted with the "User Manual" for this product.

3.3.5 Power-On Measurement

DANGER After the energy storage battery is installed, there is a high voltage present, and accidental contact with the positive and negative terminals may result in electric shock injuries. Therefore, when conducting power-on measurements, attention should be paid to the following:

1. Take necessary insulation protection measures (such as wearing insulated gloves).
2. Accompanying personnel must be present to ensure personal safety.

3.3.6 Measuring Instruments

WARNING When performing electrical connections and trial operations on the energy storage backup battery, and to ensure that electrical parameters meet requirements, relevant electrical measuring equipment such as multimeters, power meters, etc., should be used. Note the following:

1. Use measuring equipment with a suitable range that conforms to on-site working conditions.
2. Ensure the correct and standardized electrical connections of the instruments to avoid dangers such as electric arcs.

3.3.7 Maintenance and Inspection

WARNING When both the energy storage battery and the inverter are turned off, and electrical connections are confirmed to be disconnected, maintenance or inspection operations can be carried out on the energy storage battery cabinet. Pay attention to the following:

1. Ensure that the energy storage battery will not be accidentally re-energized.
2. Use a multimeter to ensure that the energy storage battery is completely de-energized.
3. For parts near potentially live components during operations, use insulating materials for insulation covering or grounding.
4. It is strictly prohibited to perform maintenance or inspection operations on live equipment! When performing maintenance or inspection on equipment, it must be ensured that at least two personnel are present at the site. Maintenance operations can only be carried out after the equipment is safely de-energized, fully charged, or discharged.

4 Overview of Main Components

*The quantities of the above-packaged contents are based on the standard configuration of POW-LIO51400-16S with a 400Ah capacity. In the case of customized capacities, certain item quantities may vary.

5 Product Introduction

5.1 Overview

The POW-LIO household energy storage series lithium battery module integrates PowMr's high-capacity, high-safety lithium iron phosphate battery cells. It adopts a stacked design with advantages in footprint and vertical space utilization. The module incorporates a high-precision Battery Management System (BMS) unit, monitoring and collecting real-time data on voltage and temperature inside the module. This enables intelligent temperature control at the cell level and smart cell balancing, enhancing system efficiency and battery cycle life. The module features a shock-resistant structure within a cold-rolled sheet metal shell for high safety and reliability, meeting household standards. Additionally, the module is designed for high stability and disturbance resistance, ensuring the safe and reliable operation of the battery system.

5.2 Product Appearance

The product consists of the following components:

• 1: Top Cover
• 2: Base
• 3: Battery
• 4: Low Voltage Switch
• 5: Battery Capacity Indicator Light
• 6: Handle
• 7: Rear Panel
• 8: Output Port
• 9: Back Port Panel

5.3 Battery Port Panel

6 Battery Installation and Wiring

For a complete video guide on installation, wiring, and debugging of the POW-LIO51400-16S, refer to the provided resources.

6.1 Battery Installation

Step 1. Prepare tools: Cross-head screwdriver, multimeter, insulated gloves, rack, Ethernet cable, power cable.

Step 2. Unboxing: Take the battery and other items from the packaging. First, check if the battery's appearance is intact, then verify the completeness of accessories against the accessory list.

Step 3. Assembly: Stack the components in the order of base > battery > top cover.

Attention: The maximum limit for stacking batteries is 4 units. If you need to parallel more than 4 batteries, ensure that each group is stacked with 4 batteries or less.

Step 4. Pre-connection Check: Before connecting in parallel, manually activate the low-voltage switch and use a multimeter to check if the voltage of each battery is consistent. If consistent, close the battery and proceed with wiring.

Step 5. Power Cable Connection: Connect the positive pole (+) of the battery using the positive power cable, and then connect the negative pole (-) using the negative power cable.

Step 6. Parallel Communication Connection: Use a communication cable to connect the RS485B communication interface of adjacent batteries (RS485B battery parallel ports have the same function and are not distinguished).

Step 7. Grounding: Ground all batteries by connecting the ground wire. The ground terminal is located at the bottom left corner of the battery; secure the ground wire terminal in this place.

Step 8. Inverter Communication Connection: Use a standard Category 6 cable. Connect one end to the RS485A (or CAN) communication interface of the battery and the other end to the RS485 (or CAN) interface of the inverter. Ensure the pin definition of the inverter communication corresponds to the battery.

Step 9. Final Power Connection: Connect the negative (-) terminal of the last battery module to the battery negative terminal interface of the inverter using a power cable through the output port. Next, use a power cable to connect the positive (+) terminal of the last battery module to the battery positive terminal interface of the inverter through the output port. (After battery parallel connection, the remaining two positive terminal connection ports have the same function and are not distinguished; the same applies to the two negative terminal connection columns).

Step 10. DIP Switch Definition: Define the battery connected to the inverter as 1 (host). Define other batteries sequentially as 2-15.

Attention:

• Define the topmost battery on the rack as the first one, and the bottommost battery as the last one.
• Batteries directly connected to the inverter via communication cables are defined as hosts. The host's DIP switch is set to 1 and needs to be switched before powering on.
• Define other batteries sequentially from 2 to 15. Do not repeat the setting of DIP switch 1.

7 Debugging

7.1 Battery Communication Pin Definitions

RS485A Communication:

• PIN2/7 (white orange): 485-A
• PIN1/8 (orange): 485-B

Note: The default RS485 protocol is Pylontech RS485 (V3.5). For compatibility with other inverters, communication via RS232 with the host computer is needed to change the default protocol.

CAN Communication:

• PIN4 (blue): CANH
• PIN5 (blue & white): CANL

Note: The battery is factory-set with the default CAN protocol (Pylontech CAN V1.2). For compatibility with other inverters, communication via RS232 with the upper computer is needed to change the default protocol.

Tip: For battery and inverter communication, choose either RS485 or CAN.

7.2 RS232 Upper Computer Communication

Refer to the Upper Computer Software Operation Guide for details.

7.3 ADS DIP Switch Definitions

7.4 Battery Parallel Connection DIP Switch Diagram

The following table illustrates DIP switch configurations for parallel connection of 1 to 16 batteries:

7.5 Power-On Sequence

After completing connections between the inverter, battery, and mains power, start each battery one by one. Then, turn on the inverter. After the battery startup, check if the communication between the inverter and the battery is normal. If the battery data is successfully uploaded to the inverter, it indicates successful communication between the inverter and the battery.

7.6 Common Issues and Solutions

7.7 Inverter Matching Information

8 Technical Specifications

9 Precautions

1. Do not immerse the battery in water. When not in use, store it in a cool and dry environment.
2. Avoid placing the battery in a fire or heating it externally to prevent explosions or other hazards.
3. Never invert the polarity of the battery, throw it into a fire, or directly connect it to a power outlet. Short-circuiting the positive and negative terminals is strictly prohibited.
4. Do not mix batteries from different manufacturers or different types.
5. Do not insert batteries that are heating up, swelling, deforming, or leaking into devices for charging or discharging.
6. Prohibit piercing the battery with nails or other sharp objects. Avoid throwing, stepping on, hitting, or impacting the battery.
7. Disassembling or dismantling the battery and its components is strictly prohibited. Any damage resulting from unauthorized disassembly or repair will not be the responsibility of our company.
8. If customers find any signs of heating, swelling, or unusual odors in the purchased battery, do not use it and return it immediately.
9. For prolonged storage, perform a charge-discharge cycle on the battery every three months to maintain optimal performance, ensuring it is stored with a 40%~60% charge.
10. Use the battery within the specified temperature range as outlined in the specifications.
11. Follow the prescribed power-up sequence for both the battery and inverter.
12. It is recommended that the load power of the battery does not exceed the maximum continuous discharge current (100A).
13. If the battery is idle for more than 3 months, periodic manual charging is necessary to prevent complete discharge.

Note: For any technical issues or situations not covered above, please contact technical support promptly.
