User Guide for ARAKNE models including: Professional TGB Gaming Mouse
PROFESSIONAL RGB. GAMING MOUSE. ARAKNE. Mouse Parameter. 1. The sensitivity of mouse. 2. Velocity of displacement of the wheel. 3. Double click speed.
ARAKNE QUICK GUIDE PROFESSIONAL RGB GAMING MOUSE ARAKNE P R O F E S S I O N A L R G B GAMING MOUSE Description Dimensions : 124,5mm x 64mm x 42mm Material: ABS Body / Rubber-band 3D wheel Buttons: 9 different keys Weight: 71g without cable Base: Teflon foot stickers Accessories: 4 extra side buttons Mechanical Properties Switching operation force: 60±10gf Key operating force: 70±10gf Center Wheel button operating force: 100±20gf Wheel life of 20 million laps. Switch life: 50 million times Cable length: 1.75 meters Electrical Parameters Operating System : Windows OS Working voltage: DC 5V, 200mA Interface: USB Highest resolution: 10000dpi DPI sampling time: 2ms Refresh rate: 1000Hz Image Processing: 5000 FPS Maximum speed: 100 IPS Acceleration: 20G DPI factory preset: 800 - Red 1600 - Green 2400 - Blue 3600 - Yellow 5000 - Light blue 10000 - Purple ARAKNE P R O F E S S I O N A L R G B GAMING MOUSE Buttons function assign Macro editor User profile setting Setting panels Restore to default Apply to save your settings ARAKNE P R O F E S S I O N A L R G B GAMING MOUSE 1 4 2 3 5 6 7 8 Macro Editor 1 The saved macro list 2 New macro 3 Delete the selected macro 4 The key list of selected macro 5 Modify the actions of selected macro 6 Removed the action from key list 7 Record macro 8 Macro setting ARAKNE P R O F E S S I O N A L R G B GAMING MOUSE 4 1 2 3 RGB Lighting Setting 1 The effects of lighting. 2 Customized the RGB color. 3 The RGB lighting speed. ARAKNE P R O F E S S I O N A L R G B GAMING MOUSE 1 2 3 Mouse Parameter 1. The sensitivity of mouse 2. Velocity of displacement of the wheel 3. Double click speed Polling rate (Hz) The polling rate of a mouse is how often it reports its position to a computer. A higher polling rate can decrease the time lag between when you move the mouse and when the movement appears on the screen. On the other hand, a higher polling rate will use more CPU resources ARAKNE PROFESSIONAL RGB GAMING MOUSEAdobe PDF library 15.00 Adobe Illustrator 24.3 (Macintosh)
