Load Ranger 2.4 GHz RF Quick Start Guide

1.0 Unpack Components

1. Remove and set aside the carrying case and wheel pads.
2. Locate the wheel pad power supply between the wheels of the wheel pads and set aside.
3. Locate the carrying case power supply underneath the indicator and printer. Remove it from the case and set aside.

To access the carrying case power supply, lift the handle to remove the compartment cover.

2.0 Setup Wheel Weigh Pads

Figure 1. Wheel Weigh Pad Controls

• POWER: [POWER] button
• SET: [SET] button
• NUM: [NUM] button
• MODE: [MODE] button
• DIAG: [DIAG] button
• Directional arrows: [arrow up], [arrow down], [arrow left], [arrow right]
• Numeric keypad: 0-9, decimal, clear, enter

1. Press the [POWER] button to turn on the first wheel weigh pad.
2. Press the [SET] button during startup. 'EECH' flashes, then 'CAL' displays.
3. Press the [NUM] button until 'SERiAL' displays.
4. Press the [NUM] button to enter the Serial menu. 'iD' displays.
5. Press the [NUM] button to enter the ID settings.
6. Press the [arrow up] or [arrow down] buttons to increase or decrease the selected digit and press the [NUM] button to move between the digits to enter the pad ID number.

The first Pad ID number must be 01 and the remaining pad ID numbers must increment in ascending numeric order. Example: 01, 02, 03. Do not configure two pads with the same ID number.

Figure 2. Wheel Weigh Pad Positioning

An illustration depicting the optimal placement of wheel weigh pads for weighing a vehicle. It shows six rectangular pads arranged in a configuration suitable for a six-wheel vehicle or a multi-axle setup. The pads are labeled 1 through 6.

The default channel number is 27. The wheel weigh pad channel number must match the indicator channel number it will pair with. The Ai-1 indicator supports channels 00 - 38. If using multiple groups of indicators and wheel weigh pads, the channel numbers must be unique for each group.

7. Press the [MODE] button. 'Con.rf' displays.
8. Press the [NUM] button until 'Baud' displays.
9. Press the [NUM] button until 'radio' displays.
10. Press the [NUM] button. 'RF' displays.
11. Press the [NUM] button or [NUM] button until 'On' displays.
12. Press the [NUM] button. 'r.chan' briefly displays.
13. Use the arrow buttons [arrow up/down] to enter a channel number.
14. Press the [OK] button. 'OK' briefly displays then 'Baud' displays.
15. Press the [OK] button twice. 'Save?' displays.
16. Press the [OK] button to save changes.
17. Repeat procedure for all wheel weigh pads in the system.

3.0 Setup Ai-1 Indicator and Pair Wheel Pads

1. Turn off all wheel weigh pads.
2. Press the [POWER] button to turn on the Ai-1 indicator.
3. During startup, press the upper right corner of the screen when the logo displays to enter the Technical Setup menu.

Figure 3. Touch Upper Right Corner of the Display

A visual representation of the Ai-1 indicator's startup screen, highlighting the upper right corner of the display where the user should touch to access the Technical Setup menu.

4. Press the [arrow right] button to go to the second Setup menu page.
5. In the second page, press the [F2] 'Serial Port' button. The Serial Port menu displays.
6. Press the [F5] 'Radio Frequency interface' button. The Radio Frequency interface displays.
7. Press the [F2] 'Channel' button.
8. Enter the required channel number.

The default channel number is 27. The wheel weigh pad channel number must match the indicator channel number it will pair with. The Ai-1 indicator supports channels 00 - 38. If using multiple groups of indicators and wheel weigh pads, the channel numbers must be unique for each group.

Figure 4. Channel Keyboard

A depiction of the on-screen keyboard used for entering channel numbers. It includes a numeric keypad (0-9), special characters like '/', '*', '-', '+', and function keys like 'Esc', 'BkSp', and 'OK'. The display area above shows the current channel range (0-38) and the selected channel (e.g., 27).

9. Press the [OK] button. A 'Channel' prompt displays.

Figure 5. Channel Success Prompt

A pop-up message on the Ai-1 indicator screen confirming that the channel configuration was sent successfully. It typically includes an 'OK' button to acknowledge the message.

10. Press the [OK] button to close the prompt and return to the Radio Frequency interface menu.
11. Press the [OK] button twice.
12. Press the [F1] 'Calibration' button.
13. Press the [F1] 'Scale selection' button.
14. Press the [F1] 'Number of scales' button. The 'Number of Scales' menu displays.
15. Select the number of wheel weigh pads to be used.

Up to 16 scales can be configured for wireless connection with each Ai-1 indicator.

Figure 6. Number of Scales Configuration

A menu screen on the Ai-1 indicator that allows the user to select the number of connected wheel weigh pads (scales). Options are presented with corresponding function keys (e.g., "1 F1", "2 F2", up to "16 F16"). It also includes "Cancel" and "OK" options.

16. Press the [OK] button.
17. Ensure all wheel pads that have been configured following the steps in section 1, are turned on.
18. Press the [F3] 'WWS configuration' button.
19. Press the [F2] 'Get WWS configuration' button.
20. The 'Gravity value setting' pop-up displays.
21. Enter the gravity value for the area the wheel weigh pads will be used.

Figure 7. Set Gravity Value

A pop-up window on the Ai-1 indicator for setting the gravity value. It displays a typical gravity range (e.g., 9.75001 ~ 9.84999) and an input field where the user enters the specific gravity value for their location (e.g., 9.80390). It includes a numeric keypad and an "OK" button.

22. Press the [OK] button to close the pop-up and continue.
23. The 'Get WWS configuration' pop-up displays. Wait while configuration information is retrieved from wheel weigh pads.

Figure 8. Get WWS configuration Pop-Up

A pop-up window indicating the process of retrieving configuration information from the wheel weigh pads. It shows the system name (WWS 1) and a progress indicator.

24. Once configuration information is retrieved, the configuration session terminates.

Figure 9. Get WWS configuration Pop-Up

A pop-up window confirming that the configuration session has terminated successfully after retrieving information from the wheel weigh pads. It includes an "OK" button.

25. Press the [OK] button to close the pop-up.
26. Press the [Esc] button.
27. The 'Setup changed' pop-up displays.

Figure 10. Setup Changed Pop-Up

A pop-up message asking the user if they want to save the changes made during the setup before restarting the indicator. Options are "Cancel", "No", and "Yes".

28. Press [Yes] to save settings and complete setup.
29. (Optional) If indicator and wheel weigh pad units are different, a pop-up may display to update units.

Figure 11. Different Unit Pop-Up

An optional pop-up that appears if the units or decimal settings on the indicator differ from those on the weigh pads. It prompts the user to match the database unit/decimals to the scale. Options are "No" and "Yes".

30. Press [Yes] to match units, or [No] without changing.
31. The indicator reboots to Weigh mode.

4.0 Initial Setup Parameters

The following parameter windows may display during initial setup before the indicator reboots to Weigh mode:

• The 'Backup of the Configuration' window -- Press [Yes] to backup all settings.
• The 'Password' window displays -- Press [Yes] or [No], depending on password requirements.
• The 'Technical Setup' window displays -- Press [Yes] to convert the indicator units to match the wheel weigh pad units.

5.0 Applications

The Load Ranger wheel weigh pads can be arranged to serve multiple applications. The adjustment from one scenario to another is made quickly and easily with the wireless and portability features of the Load Ranger system. This section highlights several of the arrangements available.

5.1 Wireless Setup

A wireless system allows for weighing with up to 16 connected wheel weigh pads per Ai-1 indicator. The wireless system is connected by following Section 2.0 through Section 3.0.

Typically wireless setup is configured for 2, 3, 4, 5 or 6 pads.

Wireless setup with an Ai-1 indicator is not limited to 2 to 6 platforms. The following illustrations show only the most common applications.

Two Platform Applications

Two platform applications include weighing axles of the vehicle individually or trailers with only one axle.

Figure 12. Two Platform Application

An illustration showing two wheel weigh pads positioned under the wheels of a single axle vehicle or trailer.

Three Platform Applications

Three platform applications include weighing small planes, three-wheeled vehicles or trailers with a support pin.

The size and capacity of the third platform can differ from those of the other platforms.

Figure 13. Three Platform Application

An illustration showing three wheel weigh pads positioned for a three-wheeled vehicle or a trailer with a support pin.

Four Platform Applications

Four platform applications include weighing two-axle vehicles, trailers, containers or other items with four support points.

Figure 14. Four Platform Application

An illustration showing four wheel weigh pads positioned for a two-axle vehicle or trailer, with two pads under each axle.

Five Platform Applications

Five platform applications include weighing two-axle trailers with a support pin. A sixth platform can be used when weighing both directions.

The size and capacity of the fifth platform can differ from those of the other platforms.

Optional sixth platform.

Figure 15. Five Platform Application

An illustration showing five wheel weigh pads positioned for a two-axle trailer, with two pads under the front axle and three under the rear axle (or vice-versa). It mentions an optional sixth platform for weighing in both directions and notes that the fifth platform's capacity can differ.

Six Platform Applications

Six platform applications include weighing three-axle vehicles or structures with six support points.

Figure 16. Six Platform Application

An illustration showing six wheel weigh pads positioned for a three-axle vehicle or structure, with two pads under each axle.

5.2 Charging Platforms

The power connection port is located on the underside of the wheel weigh pad.

For large weigh pads, the port is located on the black junction box at the wheel side (see Figure 17).

For small weigh pads, the port is located on the junction box at the handle-end of the platform and is the port closest to the handle (see Figure 18).

Figure 17. Large Weigh Pad

A view of a large Rice Lake wheel weigh pad, indicating the location of the "Charging Port" on the underside, near the junction box at the wheel side.

Figure 18. Small Weigh Pad

A view of a small Rice Lake wheel weigh pad, indicating the location of the "Charging Port" on the underside, on the junction box at the handle-end, closest to the handle.
