LG 75UP801C0SB Quick Start Guide

Installation Guide

Follow these steps to safely install your LG TV stand.

Preparation

Step 1: Positioning the TV

Place the TV with its screen facing down onto a flat, padded surface free of any objects. This protects the screen from scratches and damage.

[Illustration: A flat-screen TV is shown being placed face down on a soft, clean surface like a table covered with a cloth.]

Attaching the Stand

Step 2: Assembling the Stand Components

Identify the stand parts. Use the provided screws (M5 x L30) to attach the stand components to the back of the TV. Ensure you use the correct screws as indicated.

[Illustration: Shows the different parts of the TV stand and the screws required for assembly.]

Step 3: Securing the Stand

With the stand components attached, carefully secure the stand to the TV. Two people are recommended for this step to ensure stability and safety.

[Illustration: Two people are shown holding the TV and attaching the assembled stand to the back of the television.]

Step 4: Final Placement

Once the stand is securely attached, the TV is ready to be placed upright on a stable surface.

[Illustration: The TV with the stand attached is shown placed on a table.]

Step 5: Screw Tightening Details

Close-up views show the process of screwing the stand parts into the designated mounting points on the TV's rear panel.

[Illustration: Close-up views of screws being inserted and tightened into the TV's stand mounting points.]

Important Notes for Installation

• Perform assembly according to the figures in this section.
• The illustrations in this section show a general example of stand installation and may differ from the actual product.
• Do not overtighten the screws, as this may cause damage.
• When attaching the stand to the TV, use only the screws provided and indicated for the assembly.
• Do not apply foreign substances (oils, lubricants, etc.) to the screws during stand assembly. This can damage the unit and void the warranty.
• Whenever assembling or disassembling the Stand Set, place the TV screen-down on a flat, padded, object-free surface.

Cable Management: The diagrams indicate areas for cable management to keep connections tidy.

Connections and Usage

This section details how to connect various devices and use the remote control.

Input/Output Ports

The TV features several ports for connecting external devices:

• HDMI IN: For connecting high-definition video and audio sources (e.g., Blu-ray players, game consoles).
• USB IN: For connecting USB storage devices or other USB-compatible peripherals.
• LAN: For wired network connection (Internet).
• OPTICAL DIGITAL AUDIO OUT: For connecting to audio systems or soundbars using an optical cable.
• ANTENNA/CABLE IN: For connecting an antenna or cable TV service.

[Diagrams illustrate typical connections for HDMI, USB, LAN, Optical Audio, and Antenna/Cable inputs.]

Remote Control Usage

Step 1: Inserting Batteries

Open the battery compartment on the remote control and insert batteries as indicated.

Step 2: Operating the Remote

Point the remote control towards the TV's sensor. Use the buttons to navigate menus, adjust settings, and control playback.

[Illustrations show battery insertion and basic remote control operation, including power, volume, and navigation buttons.]

Information: Press the '[❓]' button for help or more information.

Technical Specifications

Detailed specifications for the LG 75UP801C0SB television:

General Information

Dimensions and Weight

Display

Power

Contact Information

For customer support in Brazil:

LG Electronics do Brasil Ltda.
CNPJ: 01.166.372/0008-21
Rua Javari, nº 1004, Distrito Industrial, CEP 69075-110, Manaus/AM, Made in Brazil

Customer Service:
Capitals and Metropolitan Regions: 3003 5454
Other Locations: *0800 727 5454 (Landline calls only)

Visit: www.lg.com/br/business

In case of doubt, consult our help desk.
