MPLAB® ICD 4 In-Circuit Debugger

Introduction

The Microchip MPLAB® ICD 4 In-Circuit Debugger is a powerful and cost-effective development tool designed for debugging and programming embedded firmware on Microchip PIC® microcontrollers and dsPIC® digital signal controllers. It facilitates the development process by allowing engineers to emulate and debug code directly on target hardware.

Key Features

Connects to a host PC via high-speed USB 3.0.
Communicates with target devices using RJ-11 connectors and supports JTAG interfaces.
Integrates seamlessly with the MPLAB X Integrated Development Environment (IDE).
Enables real-time debugging, setting breakpoints, monitoring variables, and programming devices.
Supports a wide range of Microchip PIC MCUs and dsPIC DSCs.

Learn More

For detailed specifications, operational guides, and troubleshooting information, please refer to the official Microchip Technology documentation.Visit Microchip.com for more details.
