Superior Print Quality

300 dpi

Supporting the highest resolution in the POS printer market.

Ensuring crisp, clear printing of 1-D and 2-D bar codes, quality texts and images.

Easy to print compliant, scannable barcodes: containing more data in smaller sizes.

Driving sales and loyalty with a greater variety of fonts, more identifiable images on receipts.

200 mm/sec

Reduced TCO and Sustainability

Auto Receipt Resize™: Paper saving solution scaling from 4-inch to 3-inch or 3-inch to 2-inch.

Reducing paper usage up to 53% resulting in less wasted and lower CO2 emission.

Specialized utility to store True Type fonts in the POS printer.

Anywhere Anyfont™ (Unicode) removing the need to write multiple code pages for every language.

Low Maintenance

Capability to check the TPH and Auto cutter's life through the self-test printing via statistic data.

Easy Tracking™ supports a QR code linking to the technical support microsite on a unique label plate found on the bottom of the printer.

USB V2.0 + Serial, Ethernet, Powered USB, Bluetooth or WLAN.

Specifications

Print Characteristics

• Print Method: Direct Thermal
• Print Speed: Up to 200 mm/sec
• Print Resolution: 300 dpi
• Print Width: Up to 73.1 mm
• Sensor: Paper End, Paper Near End, Cover Open

Media Characteristics

• Media Type: Receipt
• Media Width: 80/58 mm
• Media Roll Diameter: Up to 83 mm
• Media Thickness: 0.062~0.075 mm
• Supply Method: Easy Paper Loading

Physical Characteristics

• Dimensions (WxLxD): 147 x 200 x 148 mm (5.79 x 7.87 x 5.82 inch)
• Weight: 1.53 kg (3.36 lbs.)
• Power: EnergyStar Certified, External Power Adaptor 100-240V AV, 50/60Hz
• Drawer Port: 2 ports (Via y-type adaptor)

Performance Characteristics

• NV Image Memory: 1 Mbytes (Mono)
• Receive Buffer: 4 Kbytes
• User Define Buffer: 12 Kbytes

Interface

• Standard: USB V2.0 FS
• Optional: USB V2.0 FS + Ethernet / Serial / Dual Serial / WLAN¹ / Bluetooth² / Powered USB
• WLAN¹: 802.11a/b/g/n(2.4G+5G)
• Bluetooth²: V4.2 Classic / LE, Class 1, MFi certified

Environment Characteristics

• Temperature: Operating: 0~40°C (32 ~ 104°F), Storage: -20~60°C (-4 ~ 140°F)
• Humidity: Operating: 10~80% RH, Storage: 10 ~ 90% RH

Reliability

• Thermal Print Head (TPH): 100 km ***
• Auto Cutter: 3 Million Cuts ***

*** Specified Paper

• TF50KS-E (Paper thickness: 65μm): Nippon Paper industries Co., Ltd.
• PD 150R (Paper thickness: 75µm): New Oji Paper Mfg, Co., Ltd
• PD 160R (Paper thickness: 75µm): New Oji Paper Mfg, Co., Ltd
• P350 (Paper thickness: 62µm): Kansaki Specialty Paper, Inc. (USA)

Software

• Emulation: BXL/POS
• Driver / Utility: Windows Driver, OPOS Driver, JPOS Driver, Linux/Mac CUPS Driver, Virtual COM USB/Ethernet Driver, Utility Program, Web Driver
• SDK/Plugin: iOS SDK, Android SDK, Windows SDK, Windows Runtime SDK, Linux SDK, Xamarin SDK, Cordova Plugin, Chrome SDK

Fonts / Graphics / Symbologies

• Character Size: Font A: 18 x 34, Font B: 12 x 24, KOR, CHN, JPN: 18 x 24
• Characters Per Line: Font A: 48, Font B: 72, KOR, CHN, JPN: 48
• Character Sets: Alphanumeric: 95, Extended Graphics:128 x 35 page, International: 32, Unicode: UTF-8, UTF-16, UTF-32
• Graphics: Supporting user-defined fonts, graphics, formats and logos
• Barcode Symbologies: 1D: Coda Bar, Code 39, Code 93, Code 128, EAN-8, EAN-13, ITF, UPC-A, UPC-E, 2D: Data Matrix, GS1-128, GS1 DataBar Stacked / Omnidirectional / Truncated / Limited / Expanded, PDF417, QR code

Accessories

• Standard: 2 inch Partition (58 mm)
• Optional: External buzzer, B-Melodist, USB A-B Cable 1.8m, Powered USB 0.5m, Powered USB 1.2m
