WatchGuard AP230W Hardware Guide

Discover the capabilities of the WatchGuard AP230W, a high-performance 2x2 Wi-Fi 6 (802.11ax) access point engineered for indoor wall-mount deployments. This device offers robust wireless connectivity with data rates up to 574 Mbps on the 2.4 GHz band and 1.2 Gbps on the 5 GHz band. It also features a dedicated radio for airspace monitoring, enhancing network security.

The AP230W is designed for seamless integration into modern networks, providing four Ethernet LAN ports for wired connectivity, including one port with PoE/PSE output (802.3af) to power compatible devices. Management is streamlined through WatchGuard Cloud, offering a unified platform for deployment, configuration, and reporting across multiple locations and tenants.

This hardware guide provides comprehensive details on the AP230W's specifications, installation procedures, environmental requirements, and connection options. For setup guidance, visit watchguard.com/start.

Key Features:

• Wi-Fi 6 (802.11ax) technology
• Dual-band operation (2.4 GHz and 5 GHz)
• High data rates: 574 Mbps (2.4 GHz) / 1.2 Gbps (5 GHz)
• Dedicated security scanning radio
• Four Gigabit Ethernet ports (one with PoE/PSE output)
• Centralized management via WatchGuard Cloud
• Indoor wall-mount design
