Flexis Air Conditioner, 7.1 kW
Quick Reference Guide
Key Features & Benefits
-
Voice and remote control
Use the SmartHQ™ app to control your air conditioner remotely. Compatible with Google Home and Amazon Alexa for voice control.
-
Healthier air
Features a Self-clean function to prevent dirt accumulation and reduce mould/bacteria growth. Includes a carbon filter and anti-bacterial silver ion coating for enhanced air purification.
-
Sleep mode
Optimizes temperature throughout the night for maximum sleeping comfort.
-
Even airflow
3D Airflow directs air horizontally and vertically for consistent heating and cooling, reaching up to 20 meters.
-
Eco sensor
Detects room occupancy and switches to Energy Saving mode after 20 minutes of inactivity for efficient temperature control.
-
Easy installation and maintenance
Designed for simple installation with easy access to the control board and motor.
Specifications
Capacity
- Cooling capacity: 7.1 kW
- Heating capacity: 7.6 kW
Consumption
Not specified in detail, but efficiency features like Eco sensor are highlighted.
Performance
- Type: DC inverter
- Refrigerant: R32
- Sound power SWL (outdoor): 68dBA
- Sound pressure SPL (indoor): 49/45/39/33dBA
- Sound pressure SPL (outdoor): 55/58dBA
- Working temperature (cooling): -10°C to 46°C
- Working temperature (heating): -15°C to 24°C
Power Requirements
- Supply frequency: 50Hz
- Supply voltage: 220-240V
Product dimensions
Indoor unit
- Depth: 230 mm
- Height: 337 mm
- Width: 1115 mm
Outdoor unit
- Depth: 385 mm
- Height: 762 mm
- Width: 920 mm
Warranty
- Parts and labour: 5 years
Technical Ratings
| Rating | Value (Hot/Average/Cold) |
|---|---|
| COP | 4.02 / 4.00 |
| EER | 4.15 / 4.13 |
| HSPF-RES | 4.534 / 4.103 / 3.627 |
| HSPFCOM | 4.534 / 4.272 / 3.867 |
| Star-Cool | 3.5 / 3.0 / 3.5 |
| Star-Heat | 3.0 / 2.5 / 2.0 |
| TCSPF-COM | 5.617 / 5.678 / 6.032 |
| TCSPF-RES | 5.292 / 4.991 / 5.144 |
Features Summary
- 3D airflow
- Blue fin coils
- Built-in Wi-Fi smart control
- Rotary compressor type
- Concealed LED display
- DC inverter
- DRED (Demand Response) ready
- Google Home compatibility
- Infrared remote control
- Movement sensor
- Refrigerant factory charge: 1.30kg
- Standard controller: YR-HQ
Installation Details
- Indoor unit model: AS71FEBHRA
- Indoor unit weight: 13.0kg
- Liquid line: 6.35mm
- Maximum pipe run: 25m
- Outdoor unit model: 1U71SABFRA
- Outdoor unit weight: 54.0kg
