StarTech.com 15.2m HDMI 2.1 Active Optical Hybrid Cable (AOC)
Product ID: 8K-A-50F-HDMI-CABLE
Product Overview
Image of two silver-colored HDMI connectors with textured grip housings.
This Ultra High Speed HDMI 2.1 Active Optical Hybrid Cable (AOC) is designed for long-distance transmission of 8K 60 Hz video and high-quality audio across office spaces. The HDMI 2.1 AOC features a hybrid construction combining fiber optic cores and copper conductors. This design offloads low-bandwidth signals (EDID/HDCP/eARC) to maintain high bandwidth for 8K 60 Hz video transmission over fiber. The fiber optic inner core and shielded copper conductors significantly reduce EMI, ensuring optimal signal quality over extended distances.
Key Features
- Long Reach: Delivers 8K 60 Hz video over distances exceeding standard copper cables, with fiber optic cores minimizing EMI for optimal signal quality and minimal degradation. The cable is unidirectional.
- Plenum-Rated: Features a CMP-rated cable jacket with flame-retardant properties, ensuring minimal smoke emission in case of fire. Ideal for installation in building plenum spaces (e.g., ceilings, wall cavities) and commercial environments where fire codes must be followed.
- Versatile Performance: Supports full HDMI 2.1 specifications, enabling dynamic HDR10+ with 12-bit processing for vivid picture quality. Includes 7.1 and 32-channel audio with eARC. Suitable for UHD video walls, conference rooms, and dedicated video/media devices. Compatible with HDMI 2.0/1.4/1.2.
- Quality Construction: Equipped with shielded gold-plated connectors rated for 10,000 insertion cycles. The fiber optic core is reinforced with Aramid yarn for tensile strength and tested for 6,000 bend cycles at 120°. Connectors are clearly marked "Source" and "Display" for correct installation.
- High Bandwidth: Supports High Bit Rate 3 (HBR3) for up to 48 Gbps bandwidth, enabling higher refresh rates.
- Advanced Video/Audio: Features High Dynamic Range (HDR10+) for enhanced contrast and lifelike visuals, Enhanced Audio Return Channel (eARC) for uncompressed audio, and Display Stream Compression 1.2a (DSC) for maximum resolution.
- Data Integrity: Includes Forward Error Correction to manage data transfer errors and High-Bandwidth Digital Content Protection (HDCP 2.3) for secure content transmission.
Specifications
Hardware
| Property | Value |
|---|---|
| Warranty | 2 Years |
| Adapter Type | Active |
| Connector Plating | Gold |
| Cable Jacket Type | PVC |
| Cable Shielding | Aluminum Polyester Foil |
| Fire Rating | Plenum |
| Cable Type | Hybrid Active Optical Cable (AOC) |
| Industry Standards | HDMI 2.1 |
| Chipset IDs | ATLX-HT21, ATLX-HR21 |
Performance
| Property | Value |
|---|---|
| Video Revision | HDMI 2.1 |
| Max Data Transfer Rate | 48 Gbit/s |
| Max Digital Resolution | 8K 60 Hz / 4K 120 Hz / 4K 60Hz |
| Audio Specifications | HDMI - 7.1 Channel Audio, HDMI - 32 Channel Audio |
| Mean Time Between Failures (MTBF) | Rated for over 10,000 insertions |
Connectors
| Connector | Type |
|---|---|
| Connector A | HDMI |
| Connector B | HDMI |
Environmental & Appearance
Environment
| Property | Value |
|---|---|
| Power Source | Bus-Powered |
| Operating Temperature | 0°C to 45°C (32°F to 113°F) |
| Storage Temperature | -10°C to 70°C (14°F to 158°F) |
| Humidity | 10%~90% RH |
Appearance
| Property | Value |
|---|---|
| Color | Black |
| Connector Type | Straight |
| Wire Gauge | 28/30 AWG |
| Housing Type | Zinc Alloy |
| Cable Length | 50.0 ft [15.2 m] |
| Outer Cable Diameter | 0.2 in [4.6 mm] |
| Product Length | 50.1 ft [15.3 m] |
| Product Width | 0.8 in [2.0 cm] |
| Product Height | 0.4 in [9.0 mm] |
| Product Weight | 15.5 oz [438.0 g] |
Packaging Information
| Item | Dimensions/Weight |
|---|---|
| Package Length | 9.1 in [23.1 cm] |
| Package Width | 9.4 in [23.8 cm] |
| Package Height | 1.7 in [4.4 cm] |
| Shipping Weight | 1.2 lb [0.5 kg] |
What's in the Box
- 1 - Active Optical HDMI Cable
Warranty: 2 Years
* Product appearance and specifications are subject to change without notice.
Important Notes
This cable is unidirectional and must be installed in a specific direction. Connectors are marked "Source" and "Display". Ensure the connector marked "Display" is connected to the display, TV, or projector.
